The new Grafton bridge Grafton Business Liaison Group 14 August - PowerPoint PPT Presentation

Mar 03, 2023 •26 likes •136 views

The new Grafton bridge Grafton Business Liaison Group 14 August 2018 Recent traffic changes Challenges during construction: Footpath design matching current requirements with existing buildings Unexpected services found

The new Grafton bridge Grafton Business Liaison Group 14 August 2018
Recent traffic changes Challenges during construction: • Footpath design matching current requirements with existing buildings • Unexpected services found • Modification required to the low voltage power relocation • Obtaining a stable platform/foundation on which to build the road • Mitigating dust, managing vibration. Roads & Maritime Services 3
August 2018 (weather permitting) Roads & Maritime Services 4
August-September 2018 (weather permitting) Roads & Maritime Services 5
September-October 2018, weather permitting Roads & Maritime Services 6
October-December (weather permitting) Roads & Maritime Services 7
December 2018-January 2019 (weather permitting) Roads & Maritime Services 8
January-March 2019 (weather permitting) Roads & Maritime Services 9
March-April 2019 (weather permitting) Roads & Maritime Services 10
Conclusion • Next meeting • Further questions? Artist’s impression of the new Grafton bridge 11
Contact information For more information about the project please contact: Phone: 1800 918 759 (toll free) Email: graftonbridgecommunity@fultonhogan.com.au Mail: PO Box 546 Grafton NSW 2460 Visit the Community Display Centre at: • Corner of Duke and Pound streets Grafton • Open Monday to Friday 8.30 am to 4.30 pm 12
