The Irish 3.6 GHz award

Webinar Thursday 26th October, 11 am – 12 noon (GMT)

(c) DotEcon Ltd 2017

slide-2
SLIDE 2

Why the 3.6 GHz band is interesting

  • 5G use
  • Lots of spectrum in one band for the first time
  • Strong demand, but also unprecedented supply
  • Complex auction design issues, especially if

regionalisation is used

(c) DotEcon Ltd 2017

slide-3
SLIDE 3

3.6GHz auctions since 2014

Where When Belgium Mar 2015 Beauty contest with single applicant Spain Mar 2016 20 MHz national block (alongside 2.6GHz in a sealed bid) Hungary Jun 2016 16 blocks of 2x5MHz in 3.4-3.6 GHz and 40 blocks

  • f 5 MHZ TDD at 3.4-3.6 GHz in sealed bid

Slovakia Aug 2016 National licences in 3.4-3.6 GHz Four 5 MHz TDD blocks and one 2x5 MHz FDD block Montenegro Apr 2017 FWA Czech Rep July 2017 Five 40MHz blocks at 3.6-3.8 GHz Highly competitive Slovakia Oct 2017 Regional auction of 40MHz blocks of 3.6-3.8 GHz 16 winners

(c) DotEcon Ltd 2017

slide-4
SLIDE 4

Available spectrum in Ireland

  • 350 MHz available in two categories
  • 3410 – 3435 MHz (25 MHz) in a single A-lot
  • 3475 – 3800 MHz (325 MHz) in 65 B-lots of 5 MHz each
  • TDD band plan
  • 15-year licences

(c) DotEcon Ltd 2017

slide-5
SLIDE 5

Regionalisation

  • Usually a headache for auction design
  • Possible FWA use or migration of existing FWA
  • perators’ business plans may need regionalisation
  • Complete flexibility of licence boundaries is

impossible and some tailoring to likely demand will be needed

(c) DotEcon Ltd 2017

slide-6
SLIDE 6

Irish 3.6 GHz regionalisation

  • 9 regions (4 rural, 5 cities)
  • Aligned with National Broadband Plan
  • Smaller bidders might need a consortium
  • r to use the secondary market

(c) DotEcon Ltd 2017

slide-7
SLIDE 7

Issues arising out of regionalisation

  • Aggregation risks
  • Switching between regions
  • Do we need it?
  • How do we design sufficiently flexible switching rules?
  • Frequency fragmentation across regions
  • Reasons for coordination of frequencies across

winners

(c) DotEcon Ltd 2017

slide-8
SLIDE 8

Addressing these issues

Aggregation risks Switching flexibility CCA Relaxed bidding

Frequency fragmentation Assignment

  • ption pruning

algorithm

Frequency coordination for small winners Alliance bidding for frequencies

(c) DotEcon Ltd 2017

slide-9
SLIDE 9

Combinational clock auction

  • Irish 3.6 GHz award uses a similar CCA format as the

2012 Multiband Spectrum Award

  • Bids are always for packages of lots, so regional

aggregation risks overcome

  • Rules provide for flexible switching through activity

rules based on revealed preference

  • Eligibility point scheme fairly unimportant

(c) DotEcon Ltd 2017

slide-10
SLIDE 10

CCA rules

  • Main stage
  • Determines how many lots in the A/B categories each

bidder wins, but not specific frequencies

  • Open clock rounds
  • Supplementary bids round (with multiple bids)
  • Winner determination taking all bids
  • Second price (minimum revenue core pricing)
  • 150 MHz competition cap in any region
  • Assignment stage to determine frequencies
  • Single round of bidding
  • Mutually exclusive frequency options
  • Bidding alliances possible

(c) DotEcon Ltd 2017

slide-11
SLIDE 11

Frequency alignment principles

  • Minimise ’untidiness’ of frequency allocations

across regions …

  • A winner getting the same number of lots

everywhere gets common frequencies across regions

  • Give choices about location across the whole band

(c) DotEcon Ltd 2017

slide-12
SLIDE 12

Generating frequency options

Arrange bidders on a tree to keep frequencies tidy Permute branches of tree to move bidders around the band Use any unsold lots as padding to tidy up further Present

  • ptions to

each bidder and collect bids

Step 1 Step 2 Step 3

(c) DotEcon Ltd 2017

slide-13
SLIDE 13

Defining ‘untidiness’ when splitting up the band

  • Regional Bandwidth Variation (RBV), defined for a bidder
  • r group of bidders to be
  • the greatest number of B-Lots assigned in a region less
  • the smallest number of B-Lots assigned in a region

Region 1 Region 2 Bidder A Bidder B

RBV=4

(c) DotEcon Ltd 2017

slide-14
SLIDE 14

Simple example

First find the partitions of all bidders that minimises RBV:

  • Partition {A}, {B,C,U} has RBV = 1 + 1 = 2
  • Partition {B}, {A,C,U} has RBV = 4 + 4 = 8
  • Partition {A,B}, {C,U} has RBV = 3 + 3 = 6
  • …and so on

(c) DotEcon Ltd 2017

slide-15
SLIDE 15

Step 1: Partitions of bidders

{A}, {B,C,U} {A}, {B}, {C,U} {B}, {A,C,U} {A}, {C}, {B,U} {C}, {A,B,U} {A}, {U}, {B,C} {U}, {A,B,C} {B}, {C}, {A,U} {A,B}, {C,U} {B}, {U}, {A,C} {A,C}, {B,U} {C}, {U}, {A,B} {A,U}, {B,C} {A}, {B}, {C}, {D} {B,C}, {A,U} {B,U}, {A,C} {C,U}, {A,B}

Cases with lowest Total RBV of 2 Tie break rule:

  • Greatest number of groups
  • Smallest largest group
  • Random

Largest group of size 2, so take this one

(c) DotEcon Ltd 2017

slide-16
SLIDE 16

Step 1: Tree of successive splittings

{A,B,C,U} {A,U} {B,C} {A} {U} {B} {C} Minimum RBV Smallest largest group Pairs split to singles (trivial in this example)

(c) DotEcon Ltd 2017

slide-17
SLIDE 17

Step 2: Swapping order of branches

{A,B,C,U} {A,U} {B,C} {A} {U} {B} {C} {A,B,C,U} {A,U} {B,C} {U} {A} {B} {C} {A,B,C,U} {A,U} {B,C} {A} {U} {C} {B} {A,B,C,U} {A,U} {B,C} {U} {A} {C} {B} {A,B,C,U} {B,C} {A,U} {B} {C} {A} {U} {A,B,C,U} {B,C} {A,U} {C} {B} {A} {U} {A,B,C,U} {B,C} {A,U} {B} {C} {U} {A} {A,B,C,U} {B,C} {A,U} {C} {B} {U} {A}

A,U,B,C U,A,B,C A,U,C,B U,A,C,B B,C,A,U C,B,A,U B,C,U,A C,B,U,A

Creates only 8 of the possible 24 orderings of 4 bidders

(c) DotEcon Ltd 2017

slide-18
SLIDE 18

Step 3: Using unsold lots to improve alignment

  • Measure of frequency misalignment for a bidder:
  • Gap between lowest block in any region and highest block in any

region less

  • The maximum number of B-Lots assigned to the bidder in any region

Misalignment = 4 – 4 = 0 Misalignment = 6 – 4 = 2 Misalignment = 8 – 4 = 4

(c) DotEcon Ltd 2017

slide-19
SLIDE 19

Step 3: Move unsold blocks to pad

1 2 3 4 een them. However, we can reduce Bidder 3’s Misalignment by placing one

0 + 0 + 1 + 0 = 1

een them. However, we can reduce Bidder 3’s Misalignment by placing one 1 2 3 4

0 + 0 + 0 + 0 = 0 Unallocated lots only moved to the extent this reduces misalignment

(c) DotEcon Ltd 2017

slide-20
SLIDE 20

Alliances

  • Possibility of network sharing, joint equipment purchase
  • etc. might arguably require coordination of frequencies

across winners

  • An Alliance is a group of winners participating in the

Assignment Stage as one

  • Lead member bids for all
  • Total number of B lots across all members combined for

generation of frequency options

  • Lead member tells ComReg who gets which frequencies
  • Not allowed if the total spectrum to be awarded to the

Alliance would exceed the spectrum cap of 150 MHz in any region

  • Anti-collusion rules maintained for main stage of CCA

(c) DotEcon Ltd 2017

slide-21
SLIDE 21

Auction results

(c) DotEcon Ltd 2017

slide-22
SLIDE 22

Lessons learned

  • Regional structure allowed demand from operators
  • ther than the incumbent MNOs
  • Auction design more complex as a result …
  • … but bidder experience fairly simple
  • Prices below level of key mobile bands due to large

amount of supply

(c) DotEcon Ltd 2017

slide-23
SLIDE 23

Forthcoming 3.6 GHz auctions

  • Latvia
  • France
  • Greece
  • Italy
  • Austria
  • Switzerland
  • Belgium

(c) DotEcon Ltd 2017
