The Higgs Boson as a Probe of New Physics Ian Lewis University of Kansas March 17, 2016 Ian Lewis (University of Kansas) 1 July 4, 2012 ATLAS and CMS announce discovery of a new particle. Consistent with long sought-after Higgs

slide-1
SLIDE 1

March 17, 2016 Ian Lewis (University of Kansas) 1

The Higgs Boson as a Probe of New Physics

Ian Lewis University of Kansas

slide-2
SLIDE 2

March 17, 2016 Ian Lewis (University of Kansas) 2

July 4, 2012

  • ATLAS and CMS announce discovery of a new

particle.

– Consistent with long sought-after Higgs boson.

"We have reached a milestone in our understanding of Nature".

  • -- CERN Director General Rolf Heuer
slide-3
SLIDE 3

March 17, 2016 Ian Lewis (University of Kansas) 3

Long Search

  • 50+ years of work by theorists.
  • 25+ years of work by thousands of experimentalists.
slide-4
SLIDE 4

March 17, 2016 Ian Lewis (University of Kansas) 4

  • as
slide-5
SLIDE 5

March 17, 2016 Ian Lewis (University of Kansas) 5

Standard Model Complete

Quarks: charge +2/3 (up type) and -1/3 (down type) Leptons: charge -1 and 0

slide-6
SLIDE 6

March 17, 2016 Ian Lewis (University of Kansas) 6

Role of the Higgs

  • Higgs is the source
  • f fundamental

mass in the Standard Model.

– Important for

understanding fundamental laws of nature.

slide-7
SLIDE 7

March 17, 2016 Ian Lewis (University of Kansas) 7

Masses

  • Many massive

particles in Standard Model

  • Massive Gauge

bosons.

– W/Z.

  • Photon and gluon

are massless.

  • What is the matter

with mass?

  • Natural units
slide-8
SLIDE 8

March 17, 2016 Ian Lewis (University of Kansas) 8

What's the matter with mass?

  • Maxwell's equations:
  • Invariant under the transformation:
  • Add mass, break gauge invariance:
  • Why photon is massless.
slide-9
SLIDE 9

March 17, 2016 Ian Lewis (University of Kansas) 9

The Need to Explain Masses

  • Have masses for gauge bosons.
  • What is source of gauge invariance breaking?
  • Explicit breaking:

– Equations of theory explicitly break an invariance.

  • Spontaneous breaking:

– Lowest lying energy state (vacuum) of theory

breaks invariance.

slide-10
SLIDE 10

March 17, 2016 Ian Lewis (University of Kansas) 10

Ferromagnetism

  • Before magnetization:
  • After magnetization:
  • Spontaneous

symmetry breaking.

slide-11
SLIDE 11

March 17, 2016 Ian Lewis (University of Kansas) 11

Higgs Mechanism

  • Introduce a Higgs.
  • Write fundamental equations (with Higgs) invariant

under all transformations.

  • Vacuum breaks gauge invariance.

– Higgs obtains a nonzero value throughout space.

  • Vacuum expectation value,

– Particles interact with Higgs vacuum, gaining mass.

slide-12
SLIDE 12

March 17, 2016 Ian Lewis (University of Kansas) 12

Standard Model Higgs Boson

  • Introduce complex Higgs with four degrees of

freedom.

  • Three degrees of freedom absorbed into weak

force carriers ( ) giving them masses.

  • One degree of freedom left, the physical Higgs

boson, h.

slide-13
SLIDE 13

March 17, 2016 Ian Lewis (University of Kansas) 13

Large Hadron Collider (LHC) Overview

  • 17 mile ring outside

Geneva, Switzerland.

  • Colliding protons at a

center of mass energy

  • f 7-14 TeV.

– ~10 mph less than

speed of light.

– ~1 GJ of energy stored

at 14 TeV (Aircraft carrier traveling ~20 mph)

  • Purpose is to discover

new physics at the TeV scale.

slide-14
SLIDE 14

Hadron Collider

  • Hadrons (like a proton) are made of quarks and gluons.
  • LHC collides two protons at very high energy (7-14 TeV).
  • Constituents of proton annihilate at a typical energy of

~ 1 TeV:

slide-15
SLIDE 15

March 17, 2016 Ian Lewis (University of Kansas) 15

LHC

slide-16
SLIDE 16

March 17, 2016 Ian Lewis (University of Kansas) 16

Compact Muon Solenoid (CMS)

slide-17
SLIDE 17

March 17, 2016 Ian Lewis (University of Kansas) 17

Detecting Final State

slide-18
SLIDE 18

March 17, 2016 Ian Lewis (University of Kansas) 18

Amount of Data Produced

  • Over 600 million collisions per second per

experiment.

– Amount of data produced is 1 petabyte per second – Could fill ~200,0000 DVDs per second – Comparable to total amount of digital data produced

worldwide.

  • Experiments store and analyze less.

– Around 30 petabytes per year. – ~6,000,000 DVDs per year stored to be analyzed

  • Very successful!
slide-19
SLIDE 19

March 17, 2016 Ian Lewis (University of Kansas) 19

Higgs Discovery!

  • July 4, 2012 (mass of Tin atom)
  • Created around 650,000 Higgs through 2015.
slide-20
SLIDE 20

March 17, 2016 Ian Lewis (University of Kansas) 20

Higgs production rate is small

Higgs rate is small, need to dig signal out of all the other Standard Model processes.

slide-21
SLIDE 21

March 17, 2016 Ian Lewis (University of Kansas) 21

Higgs Production

  • Masses in Standard Model come from Higgs

mechanism.

– Completely predictive. – Vacuum expectation value

  • Protons made mostly of light quarks and

gluons.

slide-22
SLIDE 22

March 17, 2016 Ian Lewis (University of Kansas) 22

Quantum Effects to the Rescue

  • Top quark can mediate coupling to gluon.
  • Dominant production mode at the LHC.
slide-23
SLIDE 23

March 17, 2016 Ian Lewis (University of Kansas) 23

Higgs Production Rates

Other subdominant processes depend on W/Z and top quark couplings. What about decay?

slide-24
SLIDE 24

March 17, 2016 Ian Lewis (University of Kansas) 24

  • WW and ZZ probes gauge boson mass generating mechanism.
  • Decays to di-photon at 0.2% of the time
slide-25
SLIDE 25

March 17, 2016 Ian Lewis (University of Kansas) 25

Di-Photon

  • Higgs discovered using quantum production

and decay modes!

slide-26
SLIDE 26

March 17, 2016 Ian Lewis (University of Kansas) 26

Masses and Higgs Couplings

  • Remarkably Standard

Model like.

  • Have measured Higgs

rates to 20-40%.

slide-27
SLIDE 27

March 17, 2016 Ian Lewis (University of Kansas) 27

  • 2023 : 10 times current data
  • 2030s: 100 times current data

13 TeV LHC started in 2015

  • M. Lamont, Moriond 2015
slide-28
SLIDE 28

March 17, 2016 Ian Lewis (University of Kansas) 28

Future Higgs Boson Measurements

slide-29
SLIDE 29

March 17, 2016 Ian Lewis (University of Kansas) 29

What do Higgs Measurements Tell Us?

  • Consider very massive new physics.

– Standard Model leading order in a power expansion of

energies.

– Precision measurements bound next order in

expansion:

  • Then measuring rates to ~5% give new physics

scale at the TeV scale.

slide-30
SLIDE 30

March 17, 2016 Ian Lewis (University of Kansas) 30

Higgs is Central

  • Production and decay modes quantum effects.

– Sensitive to new physics

  • Expect new physics to be related to Higgs boson

properties.

– Source of fundamental mass just starting to be

probed.

– Standard Model is simplest realization of mechanism

  • Explains mass, but where does the Higgs

vacuum expectation value come from?

– Consider a simple harmonic oscillator.

slide-31
SLIDE 31

March 17, 2016 Ian Lewis (University of Kansas) 31

Harmonic Oscillator Example

  • Stored Potential energy:

– Invariant under

  • Force equation:
slide-32
SLIDE 32

March 17, 2016 Ian Lewis (University of Kansas) 32

Deformed Harmonic Oscillator

  • Stored Potential energy:

– Invariant under

  • Shift to a minimum:

– Invariance not manifest at

minimum:

slide-33
SLIDE 33

March 17, 2016 Ian Lewis (University of Kansas) 33

Higgs Potential

  • Higgs potential:
  • Have minimum:
  • Expand about vacuum:
slide-34
SLIDE 34

March 17, 2016 Ian Lewis (University of Kansas) 34

Higgs Self-Interactions

  • Higgs Potential:
  • Potential has two parameters, everything determined:
slide-35
SLIDE 35

March 17, 2016 Ian Lewis (University of Kansas) 35

  • Need to measure potential to test Standard Model
  • Double Higgs production sensitive to trilinear coupling:
  • Probing Higgs potential, source of mass.
  • All couplings known in Standard Model.

Measuring Higgs Potential

slide-36
SLIDE 36

March 17, 2016 Ian Lewis (University of Kansas) 36

Future Measurements of Potential

  • Measurement at LHC with 3000 ab-1 (2030s)

– ATLAS: observe at 1.3 σ significance

  • Bound

– CMS: Observe at 1.9 σ significance

  • Small rate, may be sensitive to new physics.
  • Particularly new physics that alters Higgs

potential.

ATL-PHYS-PUB-2014-019 CMS PAS FTR-15-002

slide-37
SLIDE 37

March 17, 2016 Ian Lewis (University of Kansas) 37

Extended Scalar Sector

  • Standard Model Higgs source of all fundamental

mass.

– Can have multiple sources of gauge invariance breaking. – Two Higgses are possible, sometimes required.

  • New source of new gauge invariance breaking

contribute to W/Z masses.

– Alter Higgs couplings to W/Z

  • What about scalar bosons that don't contribute to

gauge invariance breaking?

– Can even probe new scalars unrelated to gauge

invariance breaking.

slide-38
SLIDE 38

March 17, 2016 Ian Lewis (University of Kansas) 38

New Scalar

  • Consider a new scalar with no Standard Model

charges

  • After gauge invariance breaking, the Higgs

boson has no charge.

  • The two can mix quantum mechanically.
  • Changes Higgs couplings
slide-39
SLIDE 39

March 17, 2016 Ian Lewis (University of Kansas) 39

Higgs Couplings

  • Write equations in gauge invariant way.
  • Rotate into mass eigenstate basis
  • Original particles are superpositions of mass

eigenstates.

  • Higgs precision measurements: ATLAS, JHEP11(2015)206
slide-40
SLIDE 40

March 17, 2016 Ian Lewis (University of Kansas) 40

New Scalar Potential

  • Any new scalar will alter potential

– S has no couplings to anything else in Standard Model

  • New potential

– Interaction terms: – Expansion about vacuum – New Higgs Interactions.

slide-41
SLIDE 41

March 17, 2016 Ian Lewis (University of Kansas) 41

Higgs and Scalar Interactions

  • Comes from:
slide-42
SLIDE 42

March 17, 2016 Ian Lewis (University of Kansas) 42

Double Higgs Resonance

  • New Double Higgs

production process.

  • Resonant production and

decay of scalar S.

– Enhance rate.

slide-43
SLIDE 43

March 17, 2016 Ian Lewis (University of Kansas) 43

Large Enhancements

  • Ratio of double

Higgs rate with S included to double Higgs rate in Standard Model

  • Dashed lines

excluded due to theoretical constraints.

Chen, Dawson, IL PRD91 (2015) 074012

slide-44
SLIDE 44

March 17, 2016 Ian Lewis (University of Kansas) 44

Altering the Higgs potential

  • Implications of new scalars:

– Many more minima in the potential.

  • One Higgs: Minimize with respect to Higgs.
  • Multiple scalars: Minimize with respect to all scalars
  • Global minimum must have correct gauge invariance

breaking.

– Scalar S cannot give masses to W and Z. – Higgs vacuum expectation value has to be the same as in

Standard Model.

slide-45
SLIDE 45

March 17, 2016 Ian Lewis (University of Kansas) 45

Double Higgs Resonance

  • Require minimum with

Standard Model Higgs vacuum expectation value is global minimum.

– Places constraints on

parameters in the scalar potential,

– Affect S-h-h coupling

slide-46
SLIDE 46

March 17, 2016 Ian Lewis (University of Kansas) 46

Large Enhancements

Chen, Dawson, IL PRD91 (2015) 074012

  • Ratio of double

Higgs rate with S included to double Higgs rate in Standard Model

  • Dashed lines

have incorrect vacuum expectation value for Higgs.

slide-47
SLIDE 47

March 17, 2016 Ian Lewis (University of Kansas) 47

Bounds With Current Data

  • Ratio of double

Higgs rate with S to Standard Model prediction.

– Area within

green and magenta curves are theoretical bounds.

  • Current bounds

not enough

Chen, Dawson, IL PRD91 (2015) 074012

slide-48
SLIDE 48

March 17, 2016 Ian Lewis (University of Kansas) 48

Extrapolated bounds

  • Ratio of double

Higgs rate with S to Standard Model prediction.

– Area within

green and magenta curves are theoretical bounds.

  • Need 2023 data
  • Scenario where

scalar only has couplings through Higgs.

Chen, Dawson, IL PRD91 (2015) 074012

slide-49
SLIDE 49

March 17, 2016 Ian Lewis (University of Kansas) 49

Higher Order Corrections

  • Everything previous was at LO in coupling constant perturbation theory.

– SM double Higgs production very large corrections at higher order in

perturbation theory.

– Similar size of corrections for model with new scalar.

slide-50
SLIDE 50

March 17, 2016 Ian Lewis (University of Kansas) 50

Higher Order Corrections

  • Ratio of rates largely do not depend on if those

rates are calculated at higher orders.

Dawson, IL PRD92 (2015) 094023

slide-51
SLIDE 51

March 17, 2016 Ian Lewis (University of Kansas) 51

New Physics

  • We know there has to be new physics.
  • Energy budget of the universe:
  • Dark matter may be a secluded sector
slide-52
SLIDE 52

March 17, 2016 Ian Lewis (University of Kansas) 52

Higgs and Dark Matter Sector

  • Particles that do not couple with Standard

Model are strongly motivated.

  • Higgs is possible probe into these scenarios.

– If dark matter sector have Scalars, can write

couplings to Higgs.

slide-53
SLIDE 53

March 17, 2016 Ian Lewis (University of Kansas) 53

Dark Forces

  • Dark matter sector may not be simple.

– Possible for dark matter to have dark forces.

  • Z, photon, and dark force mediator may have

same quantum number:

– is the dark force messenger particle. – Obtains couplings to Standard Model

slide-54
SLIDE 54

March 17, 2016 Ian Lewis (University of Kansas) 54

Connection to Higgs

  • New physics can also give rise to Higgs

coupling:

  • Exotic Higgs decay to four leptons:
slide-55
SLIDE 55

March 17, 2016 Ian Lewis (University of Kansas) 55

LHC Search

  • With 300 fb
  • 1:

– Exclusion: – Discovery:

  • Stronger than current bounds.
slide-56
SLIDE 56

March 17, 2016 Ian Lewis (University of Kansas) 56

Search for

  • Complementary to low energy searches look up to

masses ~1 GeV.

  • Observable within next decade.

Davoudiasl, Lee, IL, Marciano Phys. Rev. D88 (2013) 015022

Mass of Dark Z 2 σ (Exclusion) 3 σ (Observation) 5 σ (Discovery) 5 GeV 78 fb

  • 1

180 fb

  • 1

490 fb

  • 1

10 GeV 100 fb

  • 1

230 fb

  • 1

640 fb

  • 1
slide-57
SLIDE 57

March 17, 2016 Ian Lewis (University of Kansas) 57

Conclusions

  • LHC had a very successful first run.

– Culminated in discovery of a Higgs boson

  • Higgs boson discovery helps us to begin to understand the origin of

fundamental mass in the Standard Model.

  • LHC has turned back on at higher energies.

– Still expect new physics, and have some hints. – Strong motivation this new physics is related to Higgs physics.

  • Higgs measurements sensitive to new physics.

– Test the origin of the fundamental masses of particles. – Help us search for new sources or changes in the breaking of gauge

invariance.

– Search for sector decoupled from rest of the Standard Model. – Can use as a complementary search for a light dark sector. – Interesting new physics scenarios probed in next run.

slide-58
SLIDE 58

March 17, 2016 Ian Lewis (University of Kansas) 58

Thank You
