The goal this research is to investigate the use RTK heave as a replacement of MRU heave Heave is a major contributor to errors in depth measurements. Heave is a major contributor to errors in depth measurements. In the past, manual or automatic

slide-1
SLIDE 1
slide-2
SLIDE 2

The goal this research is to investigate the use RTK heave as a replacement of MRU heave

slide-3
SLIDE 3

Heave is a major contributor to errors in depth measurements.

slide-4
SLIDE 4

Heave is a major contributor to errors in depth measurements.

slide-5
SLIDE 5

In the past, manual or automatic smoothing of the data was the only practical way of partially correcting wave-induced errors.

slide-6
SLIDE 6

The MRU accuracy in Heave is : +/- 5 cm

slide-7
SLIDE 7

Rover Base The RTK vertical accuracy: +/- 1 cm

slide-8
SLIDE 8

MRU heave may suffer from drift due to turn or acceleration

Why

Testing the new method of measuring heave

slide-9
SLIDE 9

sampling rate of MRU is higher than RTK  RTK may suffer from outage due to bad communication, could be overcome by PPK

Remember

slide-10
SLIDE 10

R2Snoic MBES project

slide-11
SLIDE 11

R2Snoic MBES project: Three surveying lines Total length of 2 km Average depth: 15 m

slide-12
SLIDE 12

applying

correction s

reading parameters raw data review (Phase I) swath-based editing (Phase II) area-based editing (Phase III)

slide-13
SLIDE 13

Two ways of processing:

Heave MRU Tide RTK Heave RTK Tide RTK

slide-14
SLIDE 14

Two ways of processing:

Heave MRU Tide RTK

slide-15
SLIDE 15

Two ways of processing:

Heave RTK Tide RTK

slide-16
SLIDE 16

applying corrections reading parameters raw data review (Phase I) swath-based editing (Phase II) area-based editing (Phase III)

Heave based comparison Area based comparison

slide-17
SLIDE 17

Hm and Hr plot for the first survey line of R2Sonic project

slide-18
SLIDE 18

Hm and Hr plot for the second survey line of R2Sonic project

slide-19
SLIDE 19

Hm and Hr plot for the third survey line of R2Sonic project

slide-20
SLIDE 20

Hm and Hr correlation for the first survey line of R2Sonic project

slide-21
SLIDE 21

Hm and Hr correlation for the second survey line of R2Sonic project

slide-22
SLIDE 22

Hm and Hr correlation for the third survey line of R2Sonic project

slide-23
SLIDE 23

Standard Deviation between Hm and Hr for the three lines

Line Standard Deviation (m) 1 0.02 2 0.03 3 0.02

slide-24
SLIDE 24

applying corrections reading parameters raw data review (Phase I) swath-based editing (Phase II) area-based editing (Phase III)

Area based comparison

slide-25
SLIDE 25
slide-26
SLIDE 26

Soundings profile for two surfaces Sm and Sr

slide-27
SLIDE 27

0.006 and the standard deviation is 0.218

slide-28
SLIDE 28

there are high correlation between both Hm and Hr . In other words RTK heave could be used as a replacement of MRU heave

slide-29
SLIDE 29

Appling the same test on single beam echo sounder Appling the same test in rough seas to see how the RTK heave will follow the MRU heave

slide-30
SLIDE 30
  • Dr. Mohamed Mohasseb

Hassan Halwanee Mohamed Elmelegy Tamer Nada Ahmed Naguib Egyptian Navy. Dr.Ashraf Elasal Pat Sanders

  • Prof. Dr. Saad Mesbah

Hydrographic Survey Research Group

slide-31
SLIDE 31
