Coloring graphs without subdivisions of K5

Xingxing Yu

Orlando, Florida

May 18, 2019

Xingxing Yu Coloring

The Four Color Theorem

◮ The Four Color Theorem (Appel and Haken 1977): If G is a

planar graph then χ(G) ≤ 4.

Xingxing Yu Coloring

The Four Color Theorem

◮ The Four Color Theorem (Appel and Haken 1977): If G is a

planar graph then χ(G) ≤ 4.

◮ In 1997, Roberston, Sanders, Seymour, and Thomas gave a

simpler and cleaner proof.

Xingxing Yu Coloring

The Four Color Theorem

◮ The Four Color Theorem (Appel and Haken 1977): If G is a

planar graph then χ(G) ≤ 4.

◮ In 1997, Roberston, Sanders, Seymour, and Thomas gave a

simpler and cleaner proof.

◮ Theorem (Ringel and Youngs 1968): If G is embeddable in a

surface other than the sphere with Euler characteristic χ∗ then χ(G) ≤ 7 + √49 − 24χ∗ 2

• .

Xingxing Yu Coloring

The Four Color Theorem

◮ The Four Color Theorem (Appel and Haken 1977): If G is a

planar graph then χ(G) ≤ 4.

◮ In 1997, Roberston, Sanders, Seymour, and Thomas gave a

simpler and cleaner proof.

◮ Theorem (Ringel and Youngs 1968): If G is embeddable in a

surface other than the sphere with Euler characteristic χ∗ then χ(G) ≤ 7 + √49 − 24χ∗ 2

• .

◮ Conjecture (Tutte 1966): Every 2-edge-connected graph

without Petersen minor has a nowhere-zero 4-flow.

Xingxing Yu Coloring

Characterizations of planar graphs

◮ Theorem (Kuratowski 1930): A graph is planar iff it contains

no K3,3-subdivision or K5-subdivision.

Xingxing Yu Coloring

Characterizations of planar graphs

◮ Theorem (Kuratowski 1930): A graph is planar iff it contains

no K3,3-subdivision or K5-subdivision.

◮ Theorem (Wagner 1937): A graph is planar iff it contains no

K3,3-minor or K5-minor.

Xingxing Yu Coloring

Graphs containing no TK3,3

◮ Theorem (Wagner 1937): If G contains no K3,3-subdivision

then G is planar, or G ∼ = K5, or G admits a cut of size at most 2.

Xingxing Yu Coloring

Graphs containing no TK3,3

◮ Theorem (Wagner 1937): If G contains no K3,3-subdivision

then G is planar, or G ∼ = K5, or G admits a cut of size at most 2.

◮ If G does not contain K3,3-subdivision then χ(G) ≤ 5.

Xingxing Yu Coloring

Hadwiger’s conjecture

◮ Theorem (Wagner 1937): If G does not contain K5-minor and

G is edge-maximal then G admits a clique cut of size at most 3, or G is planar, or is the Wagner graph. As a consequence, if G does not contain K5-minor then χ(G) ≤ 4.

Xingxing Yu Coloring

Hadwiger’s conjecture

◮ Theorem (Wagner 1937): If G does not contain K5-minor and

G is edge-maximal then G admits a clique cut of size at most 3, or G is planar, or is the Wagner graph. As a consequence, if G does not contain K5-minor then χ(G) ≤ 4.

◮ Conjecture (Hadwiger, 1943): For any k ≥ 1, if G does not

contain Kk+1-minor then χ(G) ≤ k.

Xingxing Yu Coloring

Hadwiger’s conjecture

◮ Theorem (Wagner 1937): If G does not contain K5-minor and

G is edge-maximal then G admits a clique cut of size at most 3, or G is planar, or is the Wagner graph. As a consequence, if G does not contain K5-minor then χ(G) ≤ 4.

◮ Conjecture (Hadwiger, 1943): For any k ≥ 1, if G does not

contain Kk+1-minor then χ(G) ≤ k.

◮ Hadwiger’s conjecture is known to be true for k ≤ 5, but

remains open for k ≥ 6.

Xingxing Yu Coloring

Hadwiger’s conjecture

◮ Theorem (Wagner 1937): If G does not contain K5-minor and

G is edge-maximal then G admits a clique cut of size at most 3, or G is planar, or is the Wagner graph. As a consequence, if G does not contain K5-minor then χ(G) ≤ 4.

◮ Conjecture (Hadwiger, 1943): For any k ≥ 1, if G does not

contain Kk+1-minor then χ(G) ≤ k.

◮ Hadwiger’s conjecture is known to be true for k ≤ 5, but

remains open for k ≥ 6.

◮ The case k = 5 is significantly more complex than the cases

for k ≤ 4.

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Conjecture (Haj´

• s 1961): For any integer k ≥ 1, if G does not

contain Kk+1-subdivision then χ(G) ≤ k.

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Conjecture (Haj´

• s 1961): For any integer k ≥ 1, if G does not

contain Kk+1-subdivision then χ(G) ≤ k.

◮ Haj´

• s’ conjecture is known to be true for k ≤ 3,

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Conjecture (Haj´

• s 1961): For any integer k ≥ 1, if G does not

contain Kk+1-subdivision then χ(G) ≤ k.

◮ Haj´

• s’ conjecture is known to be true for k ≤ 3,

◮ Catlin (1979): Haj´

• s’ conjecture is false for every k ≥ 6.

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Conjecture (Haj´

• s 1961): For any integer k ≥ 1, if G does not

contain Kk+1-subdivision then χ(G) ≤ k.

◮ Haj´

• s’ conjecture is known to be true for k ≤ 3,

◮ Catlin (1979): Haj´

• s’ conjecture is false for every k ≥ 6.

◮ Erd˝

• s and Fajtlowicz (1981): Haj´
• s’ conjecture is false for

almost all graphs.

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Conjecture (Haj´

• s 1961): For any integer k ≥ 1, if G does not

contain Kk+1-subdivision then χ(G) ≤ k.

◮ Haj´

• s’ conjecture is known to be true for k ≤ 3,

◮ Catlin (1979): Haj´

• s’ conjecture is false for every k ≥ 6.

◮ Erd˝

• s and Fajtlowicz (1981): Haj´
• s’ conjecture is false for

almost all graphs.

◮ Thomassen (2005): Haj´

• s’ conjecture is false for many
• bvious reasons.

Xingxing Yu Coloring

Fox-Lee-Sudakov conjecture

◮ Let σ(G) denotes the largest t such that G contains

Kt-subdivision, and

Xingxing Yu Coloring

Fox-Lee-Sudakov conjecture

◮ Let σ(G) denotes the largest t such that G contains

Kt-subdivision, and

◮ Let

H(n) := max{χ(G)/σ(G) : G is a graph with |V (G)| = n}.

Xingxing Yu Coloring

Fox-Lee-Sudakov conjecture

◮ Let σ(G) denotes the largest t such that G contains

Kt-subdivision, and

◮ Let

H(n) := max{χ(G)/σ(G) : G is a graph with |V (G)| = n}.

◮ Theorem (Fox, Lee, and Sudakov, 2012):

H(n) = Θ(√n/ log n).

Xingxing Yu Coloring

Fox-Lee-Sudakov conjecture

◮ Let σ(G) denotes the largest t such that G contains

Kt-subdivision, and

◮ Let

H(n) := max{χ(G)/σ(G) : G is a graph with |V (G)| = n}.

◮ Theorem (Fox, Lee, and Sudakov, 2012):

H(n) = Θ(√n/ log n).

◮ Conjecture (Fox, Lee, and Sudakov, 2012): There is a

constant c > 0 such that every graph G with χ(G) = k satisfies σ(G) ≥ c√k log k.

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Theorem (K¨

uhn and Osthus, 2002): Haj´

• s’ conjecture holds

for large k and graphs with large girth.

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Theorem (K¨

uhn and Osthus, 2002): Haj´

• s’ conjecture holds

for large k and graphs with large girth.

◮ Haj´

• s’ conjecture remains open for the cases k = 4 and

k = 5.

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Theorem (K¨

uhn and Osthus, 2002): Haj´

• s’ conjecture holds

for large k and graphs with large girth.

◮ Haj´

• s’ conjecture remains open for the cases k = 4 and

k = 5.

◮ Find structure of graphs containing no K5-subdivision or

K6-subdivision.

Xingxing Yu Coloring

Haj´

• s conjecture

◮ Theorem (K¨

uhn and Osthus, 2002): Haj´

• s’ conjecture holds

for large k and graphs with large girth.

◮ Haj´

• s’ conjecture remains open for the cases k = 4 and

k = 5.

◮ Find structure of graphs containing no K5-subdivision or

K6-subdivision.

◮ Find structure of a minimum counterexample to Haj´

• s’

conjecture.

Xingxing Yu Coloring

Graphs containing no TK5

◮ Theorem (He, Wang, and Y. 2017): If G does not contain

K5-subdivision then G is planar or G admits a cut of size at most 4. (This was conjectured independently by Kelmans 1979 and Seymour 1977.)

Xingxing Yu Coloring

Graphs containing no TK5

◮ Theorem (He, Wang, and Y. 2017): If G does not contain

K5-subdivision then G is planar or G admits a cut of size at most 4. (This was conjectured independently by Kelmans 1979 and Seymour 1977.)

◮ Corollary. Any counterexample to the Haj´

• s conjecture on

4-coloring must have a cut of size at most 4.

Xingxing Yu Coloring

Structure of Haj´

• s graph

A graph G is said to be a Haj´

• s graph if

(i) G is not 4-colorable, (ii) G contains no K5-subdivision, and (iii) subject to (i) and (ii), |V (G)| is minimum.

Xingxing Yu Coloring

Structure of Haj´

• s graph

◮ Theorem (Y. and Zickfeld, 2004). Every Haj´

• s graph is

4-connected. G1 G2 G′

1

G′

2

Xingxing Yu Coloring

Structure of Haj´

• s graph

◮ Theorem (Watkins and Mesner 1967): Let G be a 2-connected

graph and y1, y2, y3 be three distinct vertices in G. Then G does not have a cycle containing {y1, y2, y3} if and only if

y1 y2 y3 y1 y2 y3 y1 y2 y3 Xingxing Yu Coloring

Coloring using 4-cuts

a b c d x y z a b c d x y z a b c d x y z

Xingxing Yu Coloring

K −

4 in Haj´

• s graph

◮ Let G be a Haj´

• s graph and x1, x2, y1, y2 ∈ V (G) such that

G[{x1, x2, y1, y2}] ∼ = K −

4 and y1y2 /

∈ E(G).

y1 y2 x1 x2

Xingxing Yu Coloring

K −

4 in Haj´

• s graph

y1 y2 x1 x2

Xingxing Yu Coloring

K −

4 in Haj´

• s graph

y1 y2 x1 x2 y3

Xingxing Yu Coloring

K −

4 in Haj´

• s graph

y1 y2 x1 x2 y3

Xingxing Yu Coloring

K −

4 in Haj´

• s graph

◮ Conjecture (Lov´

asz, 1975): For every positive integer k there exists a positive integer f (k) with the following property: If G is f (k)-connected and x, y ∈ V (G) are distinct then G contains an x-y path P such that G − P is k-connected.

Xingxing Yu Coloring

K −

4 in Haj´

• s graph

◮ Conjecture (Lov´

asz, 1975): For every positive integer k there exists a positive integer f (k) with the following property: If G is f (k)-connected and x, y ∈ V (G) are distinct then G contains an x-y path P such that G − P is k-connected.

◮ True for k = 1 (Tutte), and k = 2 (Kriesell; Gould, Chen and

Y.)

Xingxing Yu Coloring

K −

4 in Haj´

• s graph

◮ Conjecture (Lov´

asz, 1975): For every positive integer k there exists a positive integer f (k) with the following property: If G is f (k)-connected and x, y ∈ V (G) are distinct then G contains an x-y path P such that G − P is k-connected.

◮ True for k = 1 (Tutte), and k = 2 (Kriesell; Gould, Chen and

Y.)

◮ Open for k ≥ 3.

Xingxing Yu Coloring

Disjoint paths

◮ G has disjoint paths from x1 to x2 and from y1 to y2.

• r

planar y1 y2 x1 x2 x1 x2 y1 y2

Xingxing Yu Coloring

Nonseparating paths

◮ G − X is a chain of blocks.

y1 y2 x1 x2 v1

Xingxing Yu Coloring

Nonseparating paths

y1 y2 x1 x2 v1 u1 u2

Xingxing Yu Coloring

Nonseparating paths

y1 y2 x1 x2 v1 v2 u1 u2

Xingxing Yu Coloring

Nonseparating paths

y1 y2 x1 x2 v1 v2 u1 u2

Xingxing Yu Coloring

Nonseparating paths

planar v1 v2 u1 u2

Xingxing Yu Coloring

Wheels in planar graphs

◮ Theorem (Xie, Xie, Y. and Yuan 2018+): Suppose G is a

Haj´

• s graph and S is a 4-cut in G. Then for each component

C of G − S with |V (C)| ≥ 2, G[C ∪ S] cannot be embedded in a closed disc with S on the boundary of the disc.

Xingxing Yu Coloring

Wheels in planar graphs

planar non-planar

Xingxing Yu Coloring

Wheels in planar graphs

Xingxing Yu Coloring

Wheels in planar graphs

Xingxing Yu Coloring

Wheels in planar graphs

Xingxing Yu Coloring

Wheels in planar graphs

x y z w u x y z w v

Xingxing Yu Coloring

Wheels in planar graphs

p q r s t u v w p q r s t

Xingxing Yu Coloring

Structure of Haj´

• s graphs with K −

4

◮ y1, y2 /

∈ X and G − X is 2-connected.

y1 y2 x1 x2

Xingxing Yu Coloring

Structure of Haj´

• s graphs with K −

4

◮ |{y1, y2} ∩ V (X)| = 1 and G − X is 2-connected. y1 x1 x2 y2

Xingxing Yu Coloring

Structure of Haj´

• s graphs with K −

4

y1 x1 x2 y2 u1 u2

Xingxing Yu Coloring

Structure of Haj´

• s graphs with K −

4

y1 x1 x2 y2

Xingxing Yu Coloring

Thank You
