The dynamical system of mixing layers

J P Parker, C P Caulfield, R R Kerswell

February 6, 2019

Dynamical systems (for fluid dynamics)

Write down a vector X that fully describes the state of the system at a given time. The system probably also depends on one or more parameters R (Re, Ra, Ri...). Then there is some function F that describes the evolution of the system: dX dt = F(X, R)

2 of 27

Geometrical picture

The state vector X probably has (infinitely?) many components, but we can consider just two, and draw a diagram.

X1 X2

Lines then show how states evolve, following ‘trajectories’. Continuity means nearby trajectories are similar. We can use ideas from topology to understand the system.

3 of 27

Special trajectories

Certain states have special properties: equilibrium point (steady state), periodic orbit (limit cycle), etc. These can be stable or unstable, and finding them builds up a picture

• f the system around them.

X1 X2

4 of 27

Special trajectories

Certain states have special properties: equilibrium point (steady state), periodic orbit (limit cycle), etc. These can be stable or unstable, and finding them builds up a picture

• f the system around them.

X1 X2

5 of 27

Special trajectories

Certain states have special properties: equilibrium point (steady state), periodic orbit (limit cycle), etc. These can be stable or unstable, and finding them builds up a picture

• f the system around them.

X1 X2

6 of 27

The problem with linear stability

Linear stability analysis for an equilibrium point tells us a series of ‘eigenvalues’. If the eigenvalue is positive, the point is unstable in the corresponding eigenvector.

7 of 27

The problem with linear stability

Linear stability analysis for an equilibrium point tells us a series of ‘eigenvalues’. If the eigenvalue is negative, the point is stable in the corresponding eigenvector.

8 of 27

The problem with linear stability

Linear stability analysis for an equilibrium point tells us a series of ‘eigenvalues’. If the eigenvalue is negative, the point is stable in the corresponding eigenvector.

9 of 27

The problem with linear stability

This is only true locally.

10 of 27

The problem with linear stability

This is only true locally.

11 of 27

Bifurcations

We are interested in when the system changes qualitatively as parameters are varied, so-called ‘bifurcation points’. Bifurcation diagrams aim to capture this behaviour.

X1 R

X1 X2 X1 X2

12 of 27

An example: Plane Poiseuille flow

A classical system in fluid dynamics is ‘plane Poiseuille flow’: flow between two parallel plates, driven by a pressure difference. The simple analytic state is stable for Re < 5772 but turbulence is

• bserved for Re 1000.

Re Energy 5772

This is called ‘subcritical transition to turbulence’.

13 of 27

Kelvin-Helmholtz Instability

movie Re = 500, Pr = 1, Rib = 0.16, 3D

Out[70]=

• 1.0
• 0.5

0.5 1.0

• 4
• 2

2 4

u b

14 of 27

Kelvin-Helmholtz in the ocean

van Haren & Gostiaux (2010)

15 of 27

Richardson number

The Richardson number Rib quantifies (non-dimensionally) the ratio of buoyancy forces to flow shear. The Miles-Howard theorem tells us that our system is stable if Rib > 1/4. ‘Stratification stabilises flows’.

16 of 27

Methodology

◮ First we try some small perturbations to the base flow at a few

different parameter values, to get a feel for the behaviour.

◮ If any of these appear to be converging to some steady state, we

use Newton’s method (Newton 1669) to find the exact solution.

◮ Once one steady state has been found, this can be reconverged at

different parameter values using branch continuation.

◮ We can then test the stability of the states found, and notice any

bifurcation points.

17 of 27

Results (Re = 4000)

18 of 27

Results (Re = 4000)

'Hopf' bifurcation

19 of 27

Results (Re = 4000)

20 of 27

Results (Re = 4000)

21 of 27

Region 1

22 of 27

Region 2

23 of 27

Region 3

24 of 27

Region 4

25 of 27

Region 5

26 of 27

Summary

◮ The complex behaviour can be understood as a two-dimensional

system.

◮ Transition is possible above critical Richardson number ◮ Seems likely that transition is possible above Richardson 1/4. ◮ Possible that this leads to full turbulence in 3D flows. ◮ States only go just past 1/4.
