THE BENEFITS OF BUILDING WITH TIMBER - SWAP STEEL, CONCRETE, AND BRICKS FOR WOOD! PRESENTED BY: WERNER SLABBERT WHAT IS A TIMBER HOME? WHAT IS A TIMBER HOME? Carbon Footprint Definitions. The Carbon Footprint Story. Comparing Carbon Footprint

slide-1
SLIDE 1

THE BENEFITS OF BUILDING WITH TIMBER - SWAP STEEL, CONCRETE, AND BRICKS FOR WOOD!

PRESENTED BY:

WERNER SLABBERT

slide-2
SLIDE 2

WHAT IS A TIMBER HOME?

slide-3
SLIDE 3

WHAT IS A TIMBER HOME?

slide-4
SLIDE 4

Carbon Footprint Definitions. The Carbon Footprint Story. Comparing Carbon Footprint of Different Materials. Energy Efficiency Definitions. How to apply energy efficiency? Comparing Energy Efficiency in Homes? Other Advantages of Timber Homes. World Wide Trends.

slide-5
SLIDE 5

Carbon Footprint Definitions

slide-6
SLIDE 6

CARBON FOOTPRINT DEFINITIONS.

What is carbon footprint?

Carbon foot printing is a sub-set of a broader measure, the ecological footprint, which itself is a measure of the human demand on the Earth’s ecosystem and compares that demand to the Earth’s ecological capacity to regenerate resources and provide

  • services. Carbon foot printing calculates ‘the amount of GHG

emissions caused by a particular activity or entity’ (British Standards Institution (BSI), 2008). This is commonly also referred to as global warming potential (GWP) and is measured in tonnes (or kilograms)

  • f carbon dioxide equivalent (CO2eq.).
slide-7
SLIDE 7

CARBON FOOTPRINT DEFINITIONS.

What is embodied energy?

Embodied energy is the energy consumed by all of the processes associated with the production of a building, from the mining and processing of natural resources to manufacturing, transport and product delivery.

slide-8
SLIDE 8

CARBON FOOTPRINT DEFINITIONS.

How does a tree store carbon?

slide-9
SLIDE 9

CARBON FOOTPRINT OF TIMBER.

Where does a tree store the carbon?

Timber is a negative carbon footprint building material.

For every 1 m³ of pine at least 1 tonne of carbon is stored in the cellulose fibre

  • f the timber.
slide-10
SLIDE 10

CARBON FOOTPRINT TREND.

Is carbon pollution really a BIG deal?

slide-11
SLIDE 11

CARBON FOOTPRINT EFFECTS.

Its not only about energy efficiency of your home; have you ever asked yourself what the environmental impact was of the material used to build your home?

slide-12
SLIDE 12

Comparing Carbon Footprint of Different Materials CARBON EMISSIONS FROM THE CEMENT INDUSTRY

  • The cement industry accounts for around 5% of global CO2

emissions.

  • Cement production is growing by 2,5% annually, and is

expected to rise from 2,55 billion tons in 2006 to 4,4 billion tons by 2050.

slide-13
SLIDE 13

CARBON FOOTPRINT STORY Comparing Carbon Footprint of Different Materials

ORIGIN Cement Timber

CO²

Iron Ore

slide-14
SLIDE 14

TRANSPORT Cement Timber

CO²

CARBON FOOTPRINT STORY Comparing Carbon Footprint of Different Materials

slide-15
SLIDE 15

MANUFACTORING Cement Timber

CO²

CARBON FOOTPRINT STORY Comparing Carbon Footprint of Different Materials

slide-16
SLIDE 16

TRANSPORT TO DISTRIBUTION Cement Timber

CO²

CARBON FOOTPRINT STORY Comparing Carbon Footprint of Different Materials

slide-17
SLIDE 17

DISTRIBUTION Cement Timber

CO²

CARBON FOOTPRINT STORY Comparing Carbon Footprint of Different Materials

slide-18
SLIDE 18

TRANSPORT TO SITE Cement Timber

CO²

CARBON FOOTPRINT STORY Comparing Carbon Footprint of Different Materials

slide-19
SLIDE 19

LET’S COMPARE DIFFERENT MATERIALS. COMPARING BRICK & MORTAR HOMES TO TIMBER FRAME HOMES – 100m²

REF – timber.net.au, ‘The Australian Timber Database’ CO²

slide-20
SLIDE 20

LET’S COMPARE DIFFERENT MATERIALS. COMPARING BRICK & STEEL TO TIMBER – 300m²

REF - NZ Wood is a major promotional and development programme to promote New Zealand forests and wood resources to improve our economy, society and our whole way of life.

CONCRETE TIMBER STEEL

CO²

slide-21
SLIDE 21

FINAL SITE Brick & Mortar Timber

CO²

CARBON FOOTPRINT STORY Comparing Carbon Footprint of Different Materials

slide-22
SLIDE 22

The Carbon Footprint Story

SO HOW MUCH DID YOUR HOME DAMAGE THE EARTH??

Final Home

CO² ¡

slide-23
SLIDE 23

SUSTAINABILITY

For every tree that is used 3 new trees are planted in sustainable plantation.

slide-24
SLIDE 24

Energy Efficiency Definitions

slide-25
SLIDE 25

ENERGY EFFICIENCY DEFINITIONS.

What is Energy Efficiency?

“Is simply the process of doing more with less to accomplish the same tasks and functions as before while using less energy”.

slide-26
SLIDE 26

ENERGY EFFICIENCY DEFINITIONS.

What is R-Value?

Measurement of the thermal resistance of a material. The HIGHER the R-Value, of a material, the GREATER its insulating effectiveness. Around most of the world, R-values are given in SI units(physical units), typically square-meter kelvin per watt or (m2·K/W)

slide-27
SLIDE 27

ENERGY EFFICIENCY DEFINITIONS.

How we calculate heat loss?

To find the heat loss per square meter, simply divide the temperature difference by the R-Value. i.e.: If the interior of a home is at 20 °C, and the roof cavity is at 10 °C, the temperature difference is 10 C° (= 10 K difference). Assuming a ceiling insulated to an R–Value of 2 (R = 2.0 m2K/W), the energy will be lost at a rate of 10 K/ 2 K·m2/W = 5 watts/per hr for every square meter of ceiling.

slide-28
SLIDE 28

ENERGY EFFICIENCY DEFINITIONS.

For the exact same temperature difference but with insulation of an R-Value of 1 the calculation will be as follows : If the interior of a home is at 20 °C, and the roof cavity is at 10 °C, the temperature difference is 10 C° (= 10 K difference). Assuming a ceiling is insulated to an R–Value of 1 (R = 1.0 m2K/W), the energy will be lost at a rate of 10 K/1 K·m2/W = 10 watts/per hr for every square meter of ceiling.

slide-29
SLIDE 29

HOW TO APPLY ENERGY EFFICIENCY IN YOUR HOME.

Energy Loss without Insulation:

≈ 25% Roof Walls ≈ 30% Glazing Thermal bridges ≈ 10% Ground Floor ≈ 10% ≈ 10% ≈ 15% Air renewal Summer Winter Principle of insulation ≈ 25% Roof Walls ≈ 30% Glazing Thermal bridges ≈ 10% Ground Floor ≈ 10% ≈ 10% ≈ 15% Air renewal Summer Winter Principle of insulation

slide-30
SLIDE 30

HOW TO APPLY ENERGY EFFICIENCY IN YOUR HOME.

Roof Insulation:

slide-31
SLIDE 31

HOW TO APPLY ENERGY EFFICIENCY IN YOUR HOME.

Floor Insulation:

slide-32
SLIDE 32

HOW TO APPLY ENERGY EFFICIENCY IN YOUR HOME.

Wall Insulation:

slide-33
SLIDE 33

HOW TO APPLY ENERGY EFFICIENCY IN YOUR HOME.

Building Envelope Sealing:

slide-34
SLIDE 34

HOW TO APPLY ENERGY EFFICIENCY IN YOUR HOME.

Window Insulation:

slide-35
SLIDE 35

LET’S COMPARE DIFFERENT HOMES. BRICK & MORTAR HOMES vs TIMBER FRAME HOMES

slide-36
SLIDE 36

OTHER REASONS WHY TIMBER HOMES ARE MORE CONVENTIONAL THAN OTHER METHODS:

  • Timber Homes are much quicker to build. i.e.: quicker turn

around on investment.

slide-37
SLIDE 37

OTHER REASONS WHY TIMBER HOMES ARE MORE CONVENTIONAL THAN OTHER METHODS:

  • Suspended Timber Homes may be built on difficult slanting

building sites and are in many cases cheaper than brick & mortar and concrete homes.

slide-38
SLIDE 38

OTHER REASONS WHY TIMBER HOMES ARE MORE CONVENTIONAL THAN OTHER METHODS:

  • In terms of durability, a correctly built timber frame structure has a

significant life span, a strength-to-weight ratio that outperforms conventional building materials, and good performance under fire conditions.

slide-39
SLIDE 39

OTHER REASONS WHY TIMBER HOMES ARE MORE CONVENTIONAL THAN OTHER METHODS:

  • For every cubic metre of timber, one ton of carbon is absorbed

from the atmosphere.

slide-40
SLIDE 40

OTHER REASONS WHY TIMBER HOMES ARE MORE CONVENTIONAL THAN OTHER METHODS:

  • This type of construction is unique in that it has the potential for carbon-

neutrality, or even a negative carbon footprint, and is supported by trees, a renewable and sustainable resource if harvested from responsibly managed plantations.

slide-41
SLIDE 41

OTHER REASONS WHY TIMBER HOMES ARE MORE CONVENTIONAL THAN OTHER METHODS:

  • With the solid backing of centuries of use, timber, as a building

material, has stood the test of time. This reliability underpins its natural design flexibility, potential carbon neutrality, and gentle ecological footprint for a truly modern, forward-thinking construction material that is poised to serve an ever-growing market of environmentally conscious and responsible individuals.

slide-42
SLIDE 42

WORLD WIDE TRENDS

slide-43
SLIDE 43

WORLD WIDE TRENDS:

  • “Timber frame is expected to account for 27% of new housing in the

UK by 2017, according to a new report.”

REF: http://www.structuraltimberawards.co.uk/news/timber-frame-heading-for-27-new-housing-market-share/

  • “Back into the woods: global construction trends show that people

are returning to wooden houses.”

REF: Ideologist and creator of Dores Factory Egons Garklavs tells his recent observations in global construction trends that people are returning to wooden houses.

  • “The quarterly European Architectural Barometer survey of 1,200

architects across six European nations showed most architects expect the use of timber frames to increase over the next five years.”

REF : http://www.building.co.uk/timber-frame-building-set-to-increase-say-architects/5041252.article

slide-44
SLIDE 44

WORLD WIDE TRENDS:

  • “Most European countries are strong advocates for the implementation
  • f the Kyoto protocol and thus all new buildings in Europe will

undergo an energy audit and be attributed an energy rating, so that buyers have the ability to distinguish energy efficient from energy inefficient buildings. It is estimated that one-third to one-half of all GHG emissions are attributable to building construction and operation costs.

REF : UK Timber Frame Association. 1-http://www.timber-frame.org/ 2-http://communiques.gouv.qc.ca/gouvqc/communiques/GPQF/Avril2006/20/c9105.html 3-Ürge-Vorsatz et al. 2007. Appraisal of policy instruments for reducing buildings’ CO2emissions. Building Research and Information. Volume 35. Number 4. July/August 2007. 4-Lowe, Robert. 2007. Editorial: Addressing the challenges of climate change for the built

  • environment. Building Research and Information. Volume 35. Number 4. July/August 2007.
slide-45
SLIDE 45

Courtesy of Eco Log Homes

slide-46
SLIDE 46

Courtesy of Eco Log Homes

slide-47
SLIDE 47
slide-48
SLIDE 48
slide-49
SLIDE 49
slide-50
SLIDE 50

WHY ARE TIMBER

HOMES NOT THE NORM AS OPPOSED TO THE EXCEPTION???????????

slide-51
SLIDE 51

THANK YOU!
