Testing GNSS Systems and Devices

David Pearce

slide-2
SLIDE 2
  • Military / Aerospace
  • UAVs
  • Electronic Warfare
  • C4ISR

Simplifying the integration of Position, Navigation, and Timing technologies into mission-critical systems.

2 1/13/2017 GNSS Testing

  • High-End Commercial Apps
  • Datacenters
  • Robotics/Telematics
  • IDM
  • GIS Data Mining
slide-3
SLIDE 3

Testing GPS Systems & Integration

slide-4
SLIDE 4

4

GNSS Test Methods

1/13/2017 GNSS Testing

slide-5
SLIDE 5

5 1/13/2017 GNSS Testing

GNSS Test Methods

Simulation Record/ Replay Live Sky True real life constellation replication X X X Repeatable tests X X Replay fixed scenarios ”that has already happened” X X Modify parameters during test X Scenarios that have ”not yet happened” X Simulate events (satellite drop out, change received signal strength, etc) X Simulate multipath X Simulate noise and test sensitivity X Simulate leap second X Test performance with future systems X

slide-6
SLIDE 6
  • Sensitivity
  • Acquisition
  • Tracking
  • Re-aquisition
  • Time to First Fix (TTFF)
  • Location Accuracy
  • Stationary
  • Dynamic
  • Trajectories
  • Time Transfer
  • Leap Second

6 1/13/2017 GNSS Testing

Basic Test Cases

slide-7
SLIDE 7
  • 1. Receiver warm-up time
  • 2. Acquisition time
  • 3. Settling time for code and carrier

tracking

  • 4. Navigation data read time
  • 5. Time to compute the navigation

solution

  • 6. Time the retrieve the system time

reference

  • Almanac
  • Orbit and status information for EVERY satellite
  • Each satellite transmits the entire almanac
  • Ionospheric model
  • Leap second information
  • 1/25 of the Almanac data is transmitted in the navigation message
  • Takes 25 complete navigation messages to receive entire almanac (12.5

minutes)

  • Considered valid for 180 days
  • Ephemeris
  • Orbital information for each satellite
  • Each satellite only transmits its own data
  • Considered valid for about 4 hours

Time to First Fix

Almanac Ephemeris Position/Time Cold Start No No No Warm Start Yes No Yes Hot Start Yes Yes Yes Understand cold vs warm vs hot start is critical when generating GPS RF

1/13/2017 GNSS Testing 7

slide-8
SLIDE 8
  • Time accuracy
  • Leap second handling

8 1/13/2017 GNSS Testing

Time Transfer

slide-9
SLIDE 9
  • Multipath
  • Interference
  • Signal fading

9 1/13/2017 GNSS Testing

Impairments to GPS

slide-10
SLIDE 10

Test Susceptibility to Jamming and Spoofing

slide-11
SLIDE 11
  • In either case, after detection, there are various mitigation techniques
  • Types of GPS/GNSS Interferers:

What is IDM and GPS Spoofing?

11 1/13/2017 GNSS Testing

Interference Detection and Mitigation for improving resiliency of PNT

Accidental / Unintentional Jamming Intentional Jamming (easy to do) Intentional Spoofing (harder to do) Jamming Easy to Detect Spoofing Difficult to Detect!

slide-12
SLIDE 12
  • Interference: radio-frequency signals

that interfere with the ability of the GNSS receiver to extract GNSS signal information from the background noise

  • Jamming: Intentional Interference
  • PPD: Personal Privacy Device

12 1/13/2017 GNSS Testing

Jamming & Interference

slide-13
SLIDE 13

Jammer Types

  • Majority of PPD jammers are chirp

jammers

  • GPS L1 Frequency – 1.57542GHz
  • Common Sweep Period – 9us
  • Bandwidth 1kHz (CW) – 44.9MHz, 20MHz

is typical

  • Also available
  • Narrowband Jammers
  • CW Jammers
  • Location Based Jammers

Simulating Jammers

  • CW – choose frequency based on

GNSS constellation

  • Simulates the CW type jammer
  • Noise – set bandwidth around center

frequency

  • Simulates the narrowband jammer
  • Sweep – set sweep time 4µs – 20µs
  • Simulates the chirp jammer
  • All GNSS frequency bands can be

simulated

13 1/13/2017 GNSS Testing

Testing Jamming

slide-14
SLIDE 14
  • Receiver alone
  • Example setup:
  • Simulator used for GNSS signals + jamming signals
  • When the jamming signal is applied navigation is lost

Use Case 1: Jamming a Receiver for Navigation

1/13/2017 GNSS Testing 14

slide-15
SLIDE 15
  • Testing a Geo-PNT (Receiver with IMU + timing outputs)
  • Example Setup:
  • Simulator used as a jamming source with live sky signals
  • When the jamming signal is applied, the IMU allows navigation to continue

Use Case 2: Jamming a Receiver+ IMU for Navigation

15 1/13/2017 GNSS Testing

slide-16
SLIDE 16
  • Testing a Timing Receiver
  • Monitor the 1PPS signal
  • Using a frequency counter monitor the 1PPS signal of the device-under-test against a stable 1PPS reference
  • 1PPS signal is stable until the receiver is jammed (900 seconds after the start of test)
  • The 1PPS becomes unstable as the receiver tries to overcome the jamming signal

Use Case 3: Jamming a Timing Receiver

1/13/2017 GNSS Testing 16

slide-17
SLIDE 17

Spoofing requires replicating attributes:

1. TIME SYNC Signal matched to satellite transmission 2. POSITION Accuracy requires real-time tracking of victim location 3. POWER Level controlled in real-time to match receiver

Why is Spoofing so difficult?

17 1/13/2017 GNSS Testing

An “perfect” spoofer would be indistinguishable from the Live Sky signal!

slide-18
SLIDE 18
  • Malfunction? Fault?
  • Position drift?
  • Time sync drift?
  • Does it issue an ALERT
  • r does it just FAIL SILENTLY?
  • Which is worse?

Hardening GPS/GNSS Systems

18 1/13/2017 GNSS Testing

What happens to your system if GPS/GNSS is spoofed?

slide-19
SLIDE 19

GNSS Simulators

19 1/13/2017 GNSS Testing

slide-20
SLIDE 20

20 1/13/2017 GNSS Testing

GNSS: Multi-Frequency, Multi-Constellation

GPS GLONASS Galileo Beidou

SBAS WAAS EGNOS GAGAN MSAS L1/L1C L2/L2C L5 E5 E6

Frequency Bands Constellations

E1 B1 B2 B3 L1 L2 1 2 3 4

Regional

QZSS

L1 L2C L5 L5

IRNSS

Global

slide-21
SLIDE 21

GSG-5/6 Series GNSS Simulators

21 1/13/2017 GNSS Testing

Affordable Easy to Use Accurate Powerful

slide-22
SLIDE 22
  • Powerful
  • Up to 64 independent satellite channels
  • GPS L1, L2, C/A, P-Code, P(p-Y), L2C and L5
  • GLONASS L1 and L2
  • Galileo E1 and E5a/E5b
  • Beidou B1, B2
  • SBAS (EGNOS, WAAS, MSAS, GAGAN)
  • QZSS L1 C/A, SAIF, L2C, L5
  • IRNSS L5
  • White noise generation
  • Multipath, interference and jammer simulation
  • Utilizes RINEX navigation data, and optional ALM and e.g. NMEA files as inputs
  • Logs RINEX obervation data, almanac, NMEA and more
  • High accuracy time base
  • Programming interface for automated testing
  • Accurate, variable output level from –65 to –160 dBm, and more

GSG Family of GNSS Simulators

22 1/13/2017 GNSS Testing

slide-23
SLIDE 23
  • Affordable
  • Modular architecture sets new industry

performance/price standards

  • High performance R&D lab simulator features
  • Priced to support efficient production applications

and use as a common engineering tool

  • Easy to use
  • Create versatile scenarios
  • Full I/O control from intuitive front panel User

Interface

  • GSG StudioView™ PC-based software with Google

Maps interface

  • Remote operation via a web-based interface or via

SCPI commands

23 1/13/2017 GNSS Testing

GSG Family of GNSS Simulators

slide-24
SLIDE 24

24 1/13/2017

Vulnerability Test System

GNSS Testing

slide-25
SLIDE 25
  • Simulation allows full testing of systems with integrated an GPS/GNSS

receiver

  • Mission-critical applications require a high degree of operational

validation when transitioning to a new receiver

  • A simulator capable of performing the necessary tests for the application

will greatly simplify the integration of an GNSS receiver

Summary

25 1/13/2017 GNSS Testing
