GNSS Signal Quality Monitoring in Finland (GNSS-Finland)

Presenter: Dr. Zahidul Bhuiyan Department of Navigation and Positioning

Finnish Geospatial Research Institute National Land Survey of Finland

GNSS-Finland Project – In a Nutshell

▪ Main Objective: To monitor GNSS signal quality information in Finland as perceived by Finnish National Reference Network (FinnRef) of 47 stations ▪ Project Duration: 5 months (February’2019 – June’2019) ▪ Project Funder: Finnish Transport and Communications Authority (Traficom) ▪ Project Coordinator: Finnish Geospatial Research Institute, National Land Survey of Finland

GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar 2

Background Information

▪ GNSS-Signal Quality Evaluation in Finland – a preliminary study was conducted in 2017 in order to portray an overall picture of user requirements for GNSS signal quality monitoring in Finland ▪ Over 2000 persons were contacted – 398 responded to web-survey and 4 in-person interviews were conducted ▪ The results showed that a significant majority of the respondents would benefit or definitely benefit from knowing the current status

• f

GNSS/EGNOS over Finland ▪ Final Report on ”GNSS Signal Quality Evaluation in Finland – Preliminary Study” can be downloaded from Ministry of Transport and Communications’ website.

3 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

End Users Perspective on Benefits of the GNSS-Finland service

▪

It would provide users a cost-effective and reliable source of information as compared to more expensive commercial services

▪

It would help to identify areas affected by intentional signal jamming, if there is any

▪

It would help users to plan the most optimum time and place to perform their GNSS- enabled field operations in Finland, by avoiding expected signal degradation or disruption time windows

▪

It would help users to effectively know the magnitude of the errors in the measurements already taken

▪

It would help users build new applications and services based on this information

▪

It would help users to notify their own customers of upcoming or ongoing disruptions

▪

Potential for outreach to uninformed users, thus helping to increase the uptake of EGNSS-enabled solutions into their products and services.

4 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

Rationale for GNSS-Finland Project

• GNSS-Finland will use the Finnish National GNSS network

“FinnRef” for monitoring GNSS signal quality over Finland. Once implemented, the service can offer near real-time updates about the GNSS status and historical trends.

• Similar services exist in other countries, however we need a

service dedicated to and owned by Finland.

• GNSS information is also not monitored at this level of detail

from other national agencies

• Critical infrastructures that depends on GNSS for its

positioning or timing requirements should be equipped with interference monitoring, detection, and alert service, and also should have alternative non-GNSS back-up solution

5 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

Finnish National Reference Network (FinnRef)

▪ 47 CORS → Basis for the national reference frame, EUREF-FIN, few stations also serve as IGS stations, and also co-located with EGNOS RIMS ▪ All GNSS and multiple frequencies are observed ▪ Real-time positioning service ‘FINPOS’ uses FinnRef data to provide DGNSS, Network RTK measurement data ▪ Data format available in RINEX and real-time streams (RTCM MSM (GPS+GLO+GAL+BDS)

6 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

User Interface: GNSS Data analysis

GNSS-Finland: Process Flow

RTCM messages Raw observations

Signal strength Doppler Pseudoranges Carrier-phase Health Flags

PVT computation

Quality Measurement Index

• Signal strength degradation
• Position deviation
• Signal level fault
• System level fault

True position FinnRef stations (47)

7 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

GNSS-Finland: Architectural Overview

RTCM service FinnRef stations (47) GNSS-Finland service

Windows console app C++

Connector

Data transfer library C++ <=> Java

Server

Server application Java

Database

Postgres

Frontend

Web application JavaScript (ES6)

Users

8 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

Features of GNSS-Finland (1/2)

▪ The core software is implemented in C++, Java and JavaScript utilizing Spring Framework and React.js library ▪ The data storage is based on PostgreSQL and PostGIS. ▪ Connects to the real-time RTCM data streams for all FinnRef stations ▪ Reads and decodes the retrieved messages in near real time ▪ Provides transparent interaction between GNSS Finland Service and the back-end Server ▪ Supports RTCM 3.x data standard, NTRIP over TCP/IP communication protocol ▪ Performs PVT computation for all stations (have not yet tested for all 47 stations)

9 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

Features of GNSS-Finland (2/2)

▪ Can offer GPS-only and Galileo-only PVT solution ▪ Position deviation at individual FinnRef station ▪ Periodically sends data to the server ▪ Interference detection algorithm based on the degradation on the received GNSS signal strength ▪ Two levels of users:

• 1. General User: can view generic monitoring information
• 2. Authenticated User: will have access to a more sophisticated

service (mostly intended for public regulatory authorities) ▪ Provision for automatic alerting to authenticated user in case of any anomaly detection on GNSS signals

10 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

▪ Overall Signal Quality status over Finland using color-coded FinnRef stations ▪ Green – GNSS signal quality is excellent, ▪ Yellow – GNSS signal quality is satisfactory, ▪ Red – GNSS signal quality is poor. ▪ Grey – Station data is not processed.

GNSS-Finland Service (Main View)

11 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

▪ Shows site-specific monitoring information in more details:

▪ Position deviation ▪ Average C/N0 of all tracked satellites ▪ Number of visible satellites ▪ Number of satellites used in position fix ▪ Doppler

GNSS-Finland Service (Station view): Position Accuracy Tab

12 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

▪ Shows average C/N0 for all GPS satellites and Galileo satellites separately ▪ Interference monitoring status: ‘No interference detected’ / ‘Interference detected!’

GNSS-Finland Service (Station View): Signal Quality Tab (1/2)

13 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

14 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

▪ A simulated interference scenario in order to test interference detection algorithm

GNSS-Finland Service (Station View): Signal Quality Tab (2/2)

▪ GNSS signal quality monitoring for other signals – GLONASS, BeiDou ▪ Signal quality monitoring for multiple frequencies: GPS L1, L5, Galileo E1, E5, etc. ▪ EGNOS signal quality monitoring ▪ DGNSS correction data monitoring ▪ Automatic email alert to authorized user for signal anomaly detection (in case of global-scale jamming or spoofing detection) ▪ Historic trend analysis of GNSS data at a given time frame at a given station ▪ Ionospheric status monitoring ▪ Automatic fault classification: (system-specific fault, signal-specific fault, service-level fault, etc.) ▪ Possibility to include any new CORS station within the GNSS-Finland service

Future Steps

15 GNSS Signal Quality Monitoring in Finland @’GNSS Interference’ Seminar

State-of-the-art Services in the World

List of References 1 [ALBERDING] Germany https://www.alberding.eu/en/GNSSStatus.html 2 [Leica SpiderQC] Sweden http://leica-geosystems.com/products/gnss-systems/software/leica-spiderqc 3 [Leica GNSS QC] Sweden http://hds.leica-geosystems.com/en/Leica-GNSS-QC- Software_29436.htm?pagemode=print 4 [DLR – SWACI] Germany http://swaciweb.dlr.de/data-and-products/public/tec/tec-eu/?L=1 5 [SeSolstorm] Norway http://sesolstorm.kartverket.no/ 6 [SGO] Finland http://www.sgo.fi/index.php 7 [ESSP-EGNOS] EU https://egnos-user-support.essp-sas.eu/new_egnos_ops/index.php 8 [SWEPOS] Sweden https://swepos.lantmateriet.se/ 9 [ROB] Belgium http://gnss.be/ 10 [EDCN] EU the project was shut down some months ago as EUROCONTROL stopped funding it 11 [EUREF] EU http://epncb.oma.be/ 12 [Trimble GNSS planning] USA http://www.gnssplanningonline.com/ 13 [US Coast Guard NavCen] USA http://www.navcen.uscg.gov/?pageName=GPSmain 14 [AUGUR] EU http://augur.ecacnav.com/augur/app/home 15 [NOAA Space Weather Prediction Center] USA http://www.swpc.noaa.gov/ 16 [EuGSC] EU https://www.gsc-europa.eu/system-status/Constellation-Information

Thank you Questions?
