Agenda Item 3.3a RAIM Prediction Service Introduction GNSS is considered a main navigation infrastructure. GNSS is now becoming a critical component of surveillance system, such as ADS-B Unpredicted outages of GNSS services can cause

slide-1
SLIDE 1

Agenda Item 3.3a RAIM Prediction Service

slide-2
SLIDE 2

Introduction

  • GNSS is considered a main navigation infrastructure.
  • GNSS is now becoming a critical component of

surveillance system, such as ADS-B

  • Unpredicted outages of GNSS services can cause

undesired interruptions on aircraft operations

2

slide-3
SLIDE 3

GNSS

  • GNSS: Global Navigation Satellite System
  • GNSS = System Satellite Constellation +

Augmentations + Aircraft Receivers

3

slide-4
SLIDE 4

What is RAIM?

  • Receiver Autonomous Integrity Monitoring (RAIM)

provides integrity monitoring of GNSS satellites for aviation applications.

  • RAIM utilizes redundancy of satellite signal

measurements combined with aircraft barometric altitude equipment to detect any faulty satellite signal based on satellite geometry and probability analysis.

4

slide-5
SLIDE 5

True Position Estimated Positions, No Faulty Satellites Estimated Positions, 1 Faulty Satellite

Checks the integrity of the position fix:

  • Includes local errors, such as

interference

  • Based on the consistency of

measurements

Requires:

  • no data from outside the satellite

receiver

  • redundant satellite measurements

A “rule of thumb”:

  • 5+ satellites to detect a problem
  • 6+ satellites to detect & isolate

problem

Most analyses assume only 1 faulty satellite Multiple failures may be more difficult to detect

What is RAIM?

slide-6
SLIDE 6

Operational Requirements

  • ICAO Annex 10 and ICAO Doc 9613 PBN Manual

require States and Air Navigation Service Providers (ANSPs) to provide timely warnings of GNSS RAIM

  • utages.

6

slide-7
SLIDE 7

Operational Requirements

7

ICAO APANPIRG 22 – September 2011 Conclusion 22/24 – Endorsement of minimum Technical and Operational Requirements for a Regional RAIM Prediction System

That, the States in the Asia/Pacific Region be encouraged to participate in the Regional RAIM Prediction System and the Minimum Technical and Operational Requirements for ASIA/PAC Regional RAIM Prediction System provided be adopted.

slide-8
SLIDE 8

Operational Requirements

  • RAIM prediction results are needed daily by pilots,

flight dispatchers, air traffic controllers and airspace planners.

  • The use of appropriate RAIM prediction services is

considered a necessary part of GNSS approvals.

  • RAIM prediction is required for en-route, terminal

area, and approach operations.

8

slide-9
SLIDE 9

Thailand’s Progress

  • As of September 2013, AEROTHAI has finished the

procurement and testing of the RAIM prediction system.

  • AEROTHAI’s RAIM Prediction System utilizes the same

engine as EUROCONTROL’s AUGUR RAIM Prediction Service.

  • The service can be accessed at www.netra.aero
  • Expect trial operations for Bangkok FIR in Oct 2013.
  • Expect full operations for Bangkok FIR in Oct 2014.

9

slide-10
SLIDE 10

Login Page

slide-11
SLIDE 11

Welcome Page

11

slide-12
SLIDE 12

RAIM Prediction Process Diagram

Satellite Positions

slide-13
SLIDE 13

GPS Status: Current NANUs

slide-14
SLIDE 14

14

Visibility Tool

(skyplot)

slide-15
SLIDE 15

Visibility: Inputs

slide-16
SLIDE 16

Visibility: Satellite Sky Plot

slide-17
SLIDE 17

Visibility: GPS Visibility Table

slide-18
SLIDE 18

18

Aerodrome Tool

slide-19
SLIDE 19

RAIM Predictions: by Aerodrome

slide-20
SLIDE 20

RAIM Predictions: by Aerodrome

slide-21
SLIDE 21

RAIM Aerodrome Prediction: Summary

slide-22
SLIDE 22

RAIM Aerodrome Prediction: Details

slide-23
SLIDE 23

RAIM Aerodrome Prediction: Outage Chart

slide-24
SLIDE 24

24

Route Tool

slide-25
SLIDE 25

RAIM Route Prediction

slide-26
SLIDE 26

26

RAIM Route Prediction: Waypoint Selection

slide-27
SLIDE 27

27

RAIM Route Prediction: Waypoint Selection

slide-28
SLIDE 28

28

RAIM Route Prediction: Waypoint Selection

slide-29
SLIDE 29

RAIM Route Prediction: Route Creation

slide-30
SLIDE 30

30

RAIM Route Prediction: Summary

slide-31
SLIDE 31

31

RAIM Route Prediction: Details by Legs

slide-32
SLIDE 32

32

RAIM Route Prediction: Details by Outage

slide-33
SLIDE 33

33

RAIM Route Prediction: Outage Chart

slide-34
SLIDE 34

34

RAIM Aerodrome Prediction: Outage Chart
