TERA CONTRIBUTIONS TO PARTNER Ugo Amaldi University of Milano Bicocca and TERA Foundation PARTNER UA 17.10.08 1 CNAO status PARTNER UA 17.10.08 2 The CNAO Foundation builds with INFN in Pavia the Centre designed by TERA


slide-1
SLIDE 1

1

TERA CONTRIBUTIONS TO PARTNER

Ugo Amaldi University of Milano Bicocca and TERA Foundation

PARTNER – UA – 17.10.08

slide-2
SLIDE 2

2

CNAO status

PARTNER – UA – 17.10.08

slide-3
SLIDE 3

3

The CNAO Foundation builds with INFN in Pavia the Centre designed by TERA on the basis of PIMMS.

Total investment: 100 M€, 80% from Health Ministry

Medical Director: Roberto Orecchia Technical Director: Sandro Rossi PIMMS/TERA Hospital building

MedAustron will build in Wiener-Neustadt a centre based on the construction drawings and the specifications bought from CNAO A French-Italian consortium has obtained the same drawings for an ETOILE proposal

High-tech building

25 m

slide-4
SLIDE 4

4

Hospital Building

CNAO status in October 2008

PARTNER – UA – 17.10.08

slide-5
SLIDE 5

The synchrotron in February 2008

5

Dipole Quadrupoles RF cavity Sources Injection line PARTNER – UA – 17.10.08

slide-6
SLIDE 6

6

The synchrotron area in October 2008

PARTNER – UA – 17.10.08

slide-7
SLIDE 7

7

The vertical beam in October 2008

PARTNER – UA – 17.10.08

slide-8
SLIDE 8

TERA programmes  1. Cyclinacs : UA  2. AQUA = Advanced Quality Assurance: Fabio Sauli

8

PARTNER – UA – 17.10.08

slide-9
SLIDE 9

9

Cyclinac Programme

PARTNER – UA – 17.10.08

slide-10
SLIDE 10

10

Cyclinac = Cyclotron + Linac for Image Guided HadronTherapy

PARTNER – UA – 17.10.08

chopped beam at 200-400 Hz modules

  • f LIGHT

RF generation computer controlled source (synchro)cyclotron

Fast cycling beam for tumour multi-painting RF generators

slide-11
SLIDE 11

11

Properties of the cyclinac beam

(*) With movable absorbers

The energy is changed by adjusting the RF pulses to the modules

1 second Yes No Synchrotron

  • No

Yes Cyclotron Time needed for varying the energy Energy variation by electronic means Beam always present during treatments Accelerator 1 millisecond Yes Yes Cyclinac 50-100 ms (*)

Fast cycling

The cyclinac beam is ideal to paint many times moving tumours in 3D without variable absorbers

PARTNER – UA – 17.10.08

slide-12
SLIDE 12

12

12

Module tested at LNS, Catania – 2003 NIM paper

1.3 m

Project value 15.7 MV/m measured 27 MV/m 73 MeV with 3.5 MW

Bridge coupler Half cells

Prototype by the INFN-CERN-TERA Collaboration : 1998-2002

3 GHz proton linac

PARTNER – UA – 17.10.08

slide-13
SLIDE 13

13

IDRA = Institute for Diagnostics and Radiotherapy : a proton cyclinac

30 MeV cyclotron by IBA R A D I O P H A R M A C Y P R O T O N T H E R A P Y ≤230 MeV 30 MeV 70 MeV Linac for Image Guided Hadron Therapy = LIGHT

18 m

A.D.A.M. SA, Application of Detectors and Accelerators to Medicine, a CERN spin-off company will build LIGHT, and has an agreement with IBA for the delivery of the rest and the overall control

PARTNER – UA – 17.10.08

slide-14
SLIDE 14

14

Next project: CABOTO= CArbon BOoster for Therapy in Oncology

p p p/C p/C p/C

300 MeV/u Carbon ions

SCENT = Superconducting cyclotron by LNS/IBA (250 MeV protons and 3600 MeV carbon ions) commercialized by IBA 5 m 1st phase: 32 cm protons 17 cm carbon ions 2nd Phase 32 cm protons 32 cm carbon ions

435 MeV/u Carbon ions

22 m modulator

2 modules

slide-15
SLIDE 15

SCENT + CABOTO = Carbon BOoster for Therapy in Oncology

15

PMQ RF power 120 cm PMQ PMQ

First accelerating module

PMQ RF power 120 cm PMQ PMQ

First accelerating module

PARTNER – UA – 17.10.08

This is the « CABOTO 3 GHz » design project which is a modification of IDRA’s design

slide-16
SLIDE 16

16

CABOTO at 12 GHz would consume less power)

WP 25 « CABOTO 12 GHz » design project in which the PARTNER ESR will work Collaboration: CERN/CLIC SC EBIS source by DREEBIT – Dresden 300-400 Hz – 107 C/pulse SC Synchrocyclotron 230 MeV/u H2

+ and C+6

@ 300-400 Hz 400 MV – 12 GHz linac ≤ 1 μs pulses

5 m

≤ 15 m 230 MeV/u 430 MeV/u

PARTNER – UA – 17.10.08

slide-17
SLIDE 17

17

Design of two 12 GHz accelerating structures and possibly construction/tests together with the CLIC = Compact LInac Collider group

  • A. SCL

very similar to LIGHT for IDRA

  • B. ACS

studied by TERA (R. Zennaro and A. Citterio)

50-60 mm 50-60 mm PARTNER – UA – 17.10.08

slide-18
SLIDE 18

18

AQUA Programme

PARTNER – UA – 17.10.08

slide-19
SLIDE 19

The detectors of AQUA (for CNAO and later A.D.A.M.)

19

PARTNER – UA – 17.10.08

slide-20
SLIDE 20

IN-beam-PET system first implemented in GSI by W. Enghardt et al

20 20

On-line determination of the dose delivered First time in 110 years! W.E. Statements for ENVISION: Two problems.

  • 1. Radioactivity wash-out
  • 2. Background that could be partially cured by

Time of Flight (TOF) - WP1 of ENVISION

In-beam-PET detectors GSI- Darmstadt

MC simulated measured

PARTNER – UA – 17.10.08

slide-21
SLIDE 21

Main alternative: Resistive Plate Chambers = RPCs

21

PARTNER – UA – 17.10.08

Other solutions based on solid detectors will be studied in parallel Time resolution : 0.1 ns 2 chamber coincidence within less than 0.2 ns corresponds to fix the source of the two-photon coincidence within less than 10 cm

slide-22
SLIDE 22

What material? What thickness?

PROBLEMS: EFFICIENCY: Large coverage INSULATORS: Control the surface THIN SHEETS: Mounting technique PMQ 101

  • P. Fonte

PARTNER – UA – 17.10.08

22

slide-23
SLIDE 23

23

Large angular coverage with ‘cheap’ gas chambers

Optimization of the mechanical design in the transverse and longitudinal directions

PARTNER – UA – 17.10.08

slide-24
SLIDE 24

24

Apply the ‘old’ technology of diamond deposition

CHEMICAL VAPOR DEPOSITION OF DIAMOND-LIKE LAYERS ( SURMET Co, Burlington USA)

  • R. Bouclier et al NIM. A369(1996)328

SURFACE RESISTIVITIES 1014 TO 1015 /☐ UNIFORMITY OF RESISTIVITY OVER LARGE AREAS (25x25 cm2):

PARTNER – UA – 17.10.08

slide-25
SLIDE 25

ESR of PARTNER will work on this novel development: WP 20

25

Mounting of the special glasses 0.2 mm

PARTNER – UA – 17.10.08

Objectives: Choice of the best electrons Measurement of time and space resolutions Measurement of efficiency/gap Gas choices, long term behaviour (?) Tolerance to other radiations (neutrons...)

slide-26
SLIDE 26

26

THE END
