Team University of Gttingen Team University of Gttingen In brightest day, in darkest night, No pathogen shall escape my sight. New antibiotics I will find, My enemies forever I bind! Team University of Gttingen Team University of

slide-1
SLIDE 1

Team University of Göttingen

slide-2
SLIDE 2

Team University of Göttingen

In brightest day, in darkest night, No pathogen shall escape my sight. New antibiotics I will find, My enemies forever I bind!

slide-3
SLIDE 3

Team University of Göttingen

slide-4
SLIDE 4

Team University of Göttingen

slide-5
SLIDE 5

The beast and its Achilles’ heel

A novel target to fight multi-resistant pathogenic bacteria

slide-6
SLIDE 6

The beast and its Achilles’ heel

A novel target to fight multi-resistant pathogenic bacteria

slide-7
SLIDE 7

Green Coli´s appartment

Laboratory

slide-8
SLIDE 8
slide-9
SLIDE 9

The threat

The US Threat Report: Yearly 2 million persons infected by resistant bacteria 23,000 deaths yearly

slide-10
SLIDE 10

Staphylococcus aureus

Bacteria on 25-30% of all humans Harmless for healthy individuals Can cause illness in weak or immune- suppressed individuals Is relatively easy to treat with antibiotics

slide-11
SLIDE 11

Staphylococcus aureus

Bacteria on 25-30% of all humans Harmless for healthy individuals Can cause illness in weak or immune- suppressed individuals Is relatively easy to treat with antibiotics

But…

slide-12
SLIDE 12

Antibiotic resistances

  • S. aureus is a paradigm for bacteria that

acquire antibiotic resistances Some strains are even untreatable

slide-13
SLIDE 13

Antibiotic resistances

  • S. aureus is a paradigm for bacteria that

acquire antibiotic resistances Some strains are even untreatable So why not just develop new antibiotics? Known targets have been exhausted

slide-14
SLIDE 14

Antibiotic resistances

So why not just develop new antibiotics? Known targets have been exhausted

slide-15
SLIDE 15

Green Coli´s appartment

Laboratory

slide-16
SLIDE 16

Human practice

slide-17
SLIDE 17

Green Coli begins

slide-18
SLIDE 18

Green Coli begins

slide-19
SLIDE 19

Our aim

Antibiotic Detector Potential Substances Substance works! Not working!

slide-20
SLIDE 20

Green Coli´s appartment

Laboratory

slide-21
SLIDE 21

Our lab

slide-22
SLIDE 22

Essential No homolog in humans Pleiotropic Conserved in pathogens

  • Dr. Sven Halbedel,

Robert-Koch-Institute Wernigerode

Targets for antibiotics have to fulfill certain criteria

slide-23
SLIDE 23

c-di-AMP

Streptococcus pneumoniae Listeria monocytogenes Staphylococcus aureus Mycobacterium tuberculosis

Cyclic di-AMP, a novel essential signaling nucleotide

DAC

slide-24
SLIDE 24

Construction of an antibiotic screening system in E. coli - based on known c-di- AMP sensors Identification of new c-di-AMP sensors for an alternative screening system Characterization of diadenylate cyclases for in vitro and in silico screening

Our project: Tackling c-di-AMP as a target for antibiotics

slide-25
SLIDE 25

Construction of an antibiotic screening system in E. coli - based on known c-di- AMP sensors Identification of new c-di-AMP sensors for an alternative screening system Characterization of diadenylate cyclases for in vitro and in silico screening

Our project: Tackling c-di-AMP as a target for antibiotics

Reporter Team!

slide-26
SLIDE 26

Identified in Mycobacterium Transcriptional repressor Binds to DarR operator c-di-AMP stimulates binding

DNA-binding c-di-AMP

N C

DarR binding sequence ATACTACGGAGTAT

DarR, a transcription factor sensing c-di-AMP

slide-27
SLIDE 27

A c-di-AMP reporter system based on DarR

slide-28
SLIDE 28

Output Output

A c-di-AMP reporter system based on DarR

Biobricks we used: BBa_J23117; BBa_J23110; BBa_B0034; BBa_B0015; BBa_E0240

slide-29
SLIDE 29

Our new biobricks: BBa_K1045000 DarR operator BBa_K1045001 DarR repressor Output

A c-di-AMP reporter system based on DarR

Output

slide-30
SLIDE 30

A long, long way to the DarR reporter system darR gfp

DarR reporter system in pSB1C3

Strong promoter Operator Weak promoter BBa_K1045017

slide-31
SLIDE 31

A long, long way to the DarR reporter system

darR gfp

DarR reporter system in pSB1C3

Strong promoter

  • perator

Weak promoter

slide-32
SLIDE 32
  • E. coli + BBa_K1045013
  • E. coli + BBa_K1045017

Testing the DarR reporter system

DarR is expressed and active as a repressor in E. coli

slide-33
SLIDE 33

“I‘m total tally ly happy py that at the the iGEM Team m Gött ttingen ngen deci cided ded to to develop elop an in vivo vo scr creen ening ing system tem!“

  • Prof. Dr. Heike Brötz-Österhelt,

HHU Düsseldorf

It’s worth to improve the reporter system!

slide-34
SLIDE 34

Construction of an antibiotic screening system in E. coli - based on known c-di- AMP sensors Identification of new c-di-AMP sensors for an alternative screening system Characterization of diadenylate cyclases for in vitro and in silico screening

Our project: Tackling c-di-AMP as a target for antibiotics

Array Team!

slide-35
SLIDE 35

Cooperation with iGEM Team Groningen (Netherlands)

Microarray: RNA from different Bacillus subtilis strains wild type c-di-AMP overproducer

Identification of c-di-AMP-responsive genes in B. subtilis

slide-36
SLIDE 36

ydaO riboswitch

A c-di-AMP-binding riboswitch regulates ydaO transcription

Promoter Riboswitch ydaO ORF

ON OFF

slide-37
SLIDE 37

Expression analysis of ydaO

ydaO expression was up-regulated at low c-di-AMP levels

1 2 3 4 5 6 Fold change

low c-di-AMP/high c-di-AMP ydaO control

slide-38
SLIDE 38

A riboswitch reporter system

slide-39
SLIDE 39

A riboswitch reporter system

Biobricks we used: BBa_E0020 Output Output

slide-40
SLIDE 40

Our new biobricks: BBa_K1045004; BBa_K1045005; BBa_K1045006; BBa_K1045007 ydaO riboswitch with different flanking regions

A riboswitch reporter system

Output Output

slide-41
SLIDE 41

The ydaO promoter from Bacillus works in E. coli

Testing the riboswitch reporter system

  • E. coli transformed with BBa_K1045002
  • c-di-AMP

+ c-di-AMP

slide-42
SLIDE 42

Construction of an antibiotic screening system in E. coli - based on known c-di- AMP sensors Identification of new c-di-AMP sensors for an alternative screening system Characterization of diadenylate cyclases for in vitro and in silico screening

Our project: Tackling c-di-AMP as a target for antibiotics

DAC Team!

slide-43
SLIDE 43

DAC with N-terminal affinity-tag

Characterization of

  • L. monocytogenes DAC

Our new biobricks: BBa_K1045003 Lmo DAC

slide-44
SLIDE 44

Purification of DAC

10 mg/ml

DAC was purified in high amounts!

Co

slide-45
SLIDE 45

Activity of DAC in vivo

0,05 0,1 0,15

control + DAC c-di-AMP

[µmol/mg protein] ND

DAC is highly active in vivo

DAC

slide-46
SLIDE 46

Activity of DAC in vitro

DAC is active in vitro

10 20 100 200 300

c-di-AMP [μM]

incubation time [min]

5 μM DAC; pH 8

DAC

slide-47
SLIDE 47

DAC domain

Crystallization of DAC

slide-48
SLIDE 48

DAC domain

Crystallization of the DAC domain

The first st crysta tals ls!

slide-49
SLIDE 49

A 2 2.8 Å di diffr fraction action pat attern rn!! !!

The first crystals!

DAC domain

Crystallization of DAC

slide-50
SLIDE 50

The first crystals! A 2.8 Å diffraction pattern!!

DAC domain

Crystallization of DAC

?

slide-51
SLIDE 51

A crys ystal al struc ucture!! ture!!! Crystallization of DAC

slide-52
SLIDE 52

Three ways to find new antibiotics

in silico in vitro in vivo DAC

slide-53
SLIDE 53
  • DarR

“With th this enzyme me, , I I wan ant to to sc screen my my su subs bstan ance ce libr brary ary!“

  • Prof. Dr. Stephen Benkovic,

Pennsylvania State University

An in vitro screening system for

  • Prof. Dr. Benkovic…?
slide-54
SLIDE 54

Registry # Name New Biobricks

BBa_K1045001

DarR Protein, Inversed

BBa_K1045000

DarR operator

BBa_K1045004

YdaO Riboswitch with regulative flanking regions

BBa_K1045005

YdaO Riboswitch only with 3`flanking region

BBa_K1045006

YdaO Riboswitch only with 5` flanking region

BBa_K1045007

YdaO Riboswitch without flanking regions

BBa_K1045003

Diadenylate cyclase domain of L. monocytogenes cdaA

Improved Biobricks

BBa_K1045011

BBa_J23117 cyclic di amp acterim reverse

BBa_K1045010

BBa_B0034 reverse

BBa_K1045009

BBa_B0015 reverse

Composite Parts

BBa_K1045017

composite part BBa_B0015 reverse-DarR reverse - BBa_B0034 reverse-BBa_J23117 reverse-BBa_J23110-DarR operator - Bba_E0240 (DarR reporter system, weak promoter)

BBa_K1045002

CFP Reporter under control of the c-di-AMP-dependent YdaO Riboswitch

Intermediate Parts

BBa_K1045012

composite part BBa_J23110 with DarR operator

BBa_K1045015

composite part BBa_B0034 reverse-BBa_J23117 reverse-BBa_J23110-DarR operator - BBa_E0240 (6.1)

BBa_K1045016

composite part BBa_B0015 reverse-DarR reverse

BBa_K1045014

composite part BBa_J23117 reverse-BBa_J23110-DarR operator - Bba_E0240

BBa_K1045013

composite part BBa_J23110-DarR operator - Bba_E0240

Our biobricks

slide-55
SLIDE 55

Green Coli´s appartment

Laboratory

slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58

Perspectives

High-throughput screening-system Thousands of substances can be tested in one run Potential candidates can be further investigated Saves human lives through new antibiotics

slide-59
SLIDE 59

Our sponsors

slide-60
SLIDE 60

Acknowledgements

Annette Garbe

  • Dr. Piotr Neumann
  • Dr. Achim Dickmanns

Our Supervisors

slide-61
SLIDE 61

The beast and its Achilles’ heel

Thank you for your interest!

slide-62
SLIDE 62

The beast and its Achilles’ heel

Thank you for your interest! Keep The Green Light Glowing!

slide-63
SLIDE 63

The beast and its Achilles’ heel

Thank you for your interest! Keep The Green Light Glowing!
