Supervision of the Rotor Bars Breakage Evolution through the Output Voltage of Coil Sensors Placed Outside Induction Motors
POLITEHNICA University of Bucharest EPM_NM Laboratory Virgiliu FIRETEANU Alexandru-Ionel CONSTANTIN
SLIDE 2 Powerpoint Templates
Contents
- 2D Finite element model
- Fault analysis for rated load motor operation
- Supervision on the evolution of the rotor bar
breakage for rated load motor operation
- Breakage bars supervision for no-load motor
- peration
- Conclusions
SLIDE 3 Powerpoint Templates
2D Finite element model
Electromagnetic field model Computation domain Electric circuit model Induction motor data
- 7.5 kW
- 3000 rpm
- 3 x 400 V
, 50 Hz
Ox1 coil Ox coil Uox Uox1 Uox_ox1 Squirrel cage Phase U Phase V Phase W
SLIDE 4 Powerpoint Templates
Fault analysis for rated load motor
Models analyzed
with the resistivity of all bars 0.48e-7 Ωm
with one broken bar - resistivity 0.48 Ωm
SLIDE 5 Powerpoint Templates
Fault analysis for rated load motor
Harmonics of phase current IU Time variation of phase currents in healthy motor, HE
Rms values of phase currents for healthy motor: IU = 10.25 A IV = 10.25 A IW = 10.25 A Rms values of phase currents for faulty motor: IU = 9.777 A IV = 9.766 A IW = 9.786 A
SLIDE 6 Powerpoint Templates Time variation and harmonics of the electromagnetic torque
Mean values: MHE = 31.35 Nm MFA = 29.94 Nm
Fault analysis for rated load motor
Healthy motor, HE Faulty motor, FA
SLIDE 7 Powerpoint Templates
Fault analysis for rated load motor
Time variation and harmonics of the electromagnetic force acting on the rotor -
Mean values: ForceHE = 0.075 N and ForceFA = 277.7 N
faulty motor, FA
SLIDE 8 Powerpoint Templates Map and lines of the magnetic field outside the motor
Fault analysis for rated load motor
Healthy motor, HE
SLIDE 9 Powerpoint Templates Time dependence and harmonics of the magnetic flux density in the centre point of Ox coil
Fault analysis for rated load motor
Radial component Bx
- f the magnetic flux density
Azimuthal component By
- f the magnetic flux density
SLIDE 10 Powerpoint Templates
Fault analysis for rated load motor
Uox_ox1 time dependence, healthy motor (a) and faulty motor (b)
SLIDE 11 Powerpoint Templates
Fault analysis for rated load motor
Time dependence and harmonics of the Uox_ox1 voltage
Rms values: Uox_ox1HE = 2.513 mV Uox_ox1FA = 1130 mV Healthy motor, HE Faulty motor, FA
SLIDE 12 Powerpoint Templates
Evolution of the rotor bar breakage, rated load operation
with the resistivity of all bars 0.48e-7 Ωm
with one broken bar - resistivity 1.05x0.48e-7 Ωm
with one broken bar - resistivity 1.2x0.48e-7 Ωm
with one broken bar - resistivity 1.5x0.48e-7 Ωm
with one broken bar - resistivity 0.48 Ωm Rms values of Uox_ox1 voltage and rms faulty/rms healthy Evolution of the Uox_ox1 rms voltage during breakage. Early detection of the bar breakage. HE FA1 FA2 FA3 FA rms Uox_ox1 [mV] 2.513 48.16 171.9 371.4 1130 FA/HE
68.40 147.8 449.7
SLIDE 13
Powerpoint Templates Uox_ox1 harmonics during FA1-FA2-FA3 bar breakage evolution
Evolution of the rotor bar breakage, rated load operation
SLIDE 14
Powerpoint Templates Amplitudes of Uox_ox1 harmonics and the values of efficiency, FA?/HE
Evolution of the rotor bar breakage, rated load operation
f[Hz] 160 200 260 300 560 FA2 [mV] 11.12 104.0 3.838 40.65 6.621 FA2/HE 29126 31878 49678 56825 27511 f[Hz] 160 200 260 300 560 FA3[mV] 22.87 239.3 8.145 84.73 13.31 FA3/HE 59867 73394 105414 118458 55279 f[Hz] 200 260 300 560 580 FA [mV] 704.1 36.55 231.5 54.95 183.2 FA/HE 215899 473114 323624 228310 249936 FA2 FAULTY STATE, 20 % INCREASE OF BAR RESISTIVITY FA3 FAULTY STATE, 50 % INCREASE OF BAR RESISTIVITY FA FAULTY STATE, BROKEN BAR
SLIDE 15
Powerpoint Templates Amplitudes of Uox_ox1 harmonics and the values of efficiency, FA?/FA1
Evolution of the rotor bar breakage, rated load operation
f[Hz] 840 1010 1130 1140 1310 FA2 [mV] 4.707 3.512 1.562 2.796 4.530 FA2/FA1 3.914 4.298 4.417 4.052 4.420 f[Hz] 920 1010 1020 1120 1310 FA3[mV] 7.020 9.559 10.36 4.291 9.906 FA3/FA1 10.50 11.70 9.705 11.14 9.663 f[Hz] 610 820 1120 1130 1170 FA [mV] 26.31 27.44 23.38 30.22 54.79 FA/FA1 114.8 99.19 60.70 85.48 128.9 FA2 FAULTY STATE, 20 % INCREASE OF BAR RESISTIVITY FA3 FAULTY STATE, 50 % INCREASE OF BAR RESISTIVITY FA FAULTY STATE, BROKEN BAR
SLIDE 16
Powerpoint Templates
Breakage bars supervision for no-load motor operation
Time dependence and harmonics of the Uox_ox1 voltage
Healthy motor, HE Faulty motor, FA Rms values: Uox_ox1HE = 1.231 mV Uox_ox1FA = 130.1 mV
SLIDE 17
Powerpoint Templates
Breakage bars supervision for no-load motor operation
Rms values: Uox_ox1HE = 1.231 mV Uox_ox1FA = 130.1 mV f[Hz] 200 260 300 560 580 FA [mV] 704.1 36.55 231.5 54.95 183.2 FA/HE 215899 473114 323624 228310 249936 f[Hz] 500 600 1100 1200 1500 FA [mV] 45.67 39.92 37.60 23.44 18.55 FA/HE 4654 5986 20779 7120 6977 Rms values: Uox_ox1HE = 2.513 mV Uox_ox1FA = 1130 mV RATED LOAD MOTOR OPERATION NO-LOAD MOTOR OPERATION RATED LOAD MOTOR OPERATION NO-LOAD MOTOR OPERATION
SLIDE 18 Powerpoint Templates
- The supervision of the rotor bars breakage, respectively
the early detection of the broken bars fault in the squirrel-cage induction motors through the
voltage of a system that consist in two identical series connected coils, is proved to be a very efficient method.
- The rms value of the system output voltage and the
amplitude of particular harmonics of this voltage are very sensitive to the change of the resistance of bars.
- The efficiency of the rotor bar breakage supervision is
much more important for rated-load motor operation than for no-load operation.
Conclusions
