CS4501: Introduction to Computer Vision

Structure from Motion and Optical Flow

Various slides from previous courses by: D.A. Forsyth (Berkeley / UIUC), I. Kokkinos (Ecole Centrale / UCL). S. Lazebnik (UNC / UIUC), S. Seitz (MSR / Facebook), J. Hays (Brown / Georgia Tech), A. Berg (Stony Brook / UNC), D. Samaras (Stony Brook) . J. M. Frahm (UNC), V. Ordonez (UVA), Steve Seitz (UW).

• More on Epipolar Geometry
• Essential Matrix
• Fundamental Matrix

Last Class

• More on Epipolar Geometry
• Essential Matrix
• Fundamental Matrix
• Optical Flow

Today’s Class

Estimating depth with stereo

• Stereo: shape from “motion” between two views
• We’ll need to consider:
• Info on camera pose (“calibration”)
• Image point correspondences

scene point

• ptical

center image plane

Potential matches for x have to lie on the corresponding line l’. Potential matches for x’ have to lie on the corresponding line l.

Key idea: Epipolar constraint

x x ’ X x ’ X x ’ X

• Epipolar Plane – plane containing baseline (1D family)
• Epipoles

= intersections of baseline with image planes = projections of the other camera center

• Baseline – line connecting the two camera centers

Epipolar geometry: notation

X x x ’

• Epipolar Lines - intersections of epipolar plane with image

planes (always come in corresponding pairs)

Epipolar geometry: notation

X x x ’

• Epipolar Plane – plane containing baseline (1D family)
• Epipoles

= intersections of baseline with image planes = projections of the other camera center

• Baseline – line connecting the two camera centers

Epipolar Geometry: Another example

Credit: William Hoff, Colorado School of Mines

Example: Converging cameras

Geometry for a simple stereo system

• First, assuming parallel optical axes, known camera

parameters (i.e., calibrated cameras):

Simplest Case: Parallel images

• Image planes of cameras are

parallel to each other and to the baseline

• Camera centers are at same height
• Focal lengths are the same
• Then epipolar lines fall along the

horizontal scan lines of the images

• Assume parallel optical axes, known camera parameters (i.e.,

calibrated cameras). What is expression for Z? Similar triangles (pl, P, pr) and (Ol, P, Or):

Geometry for a simple stereo system

Z T f Z x x T

r l

=

• +

l r

x x T f Z

• =

disparity

Depth from disparity

image I(x,y) image I´(x´,y´) Disparity map D(x,y) (x´,y´)=(x+D(x,y), y) So if we could find the corresponding points in two images, we could estimate relative depth…

Matching cost disparity Left Right scanline

Correspondence search

• Slide a window along the right scanline and

compare contents of that window with the reference window in the left image

• Matching cost: SSD or normalized correlation

Left Right scanline

Correspondence search

SSD

Left Right scanline

Correspondence search

• Norm. corr

Basic stereo matching algorithm

• If necessary, rectify the two stereo images to transform

epipolar lines into scanlines

• For each pixel x in the first image
• Find corresponding epipolar scanline in the right image
• Examine all pixels on the scanline and pick the best match x’
• Compute disparity x–x’ and set depth(x) = B*f/(x–x’)

Failures of correspondence search

Textureless surfaces Occlusions, repetition Non-Lambertian surfaces, specularities

Active stereo with structured light

• Project “structured” light patterns onto the object
• Simplifies the correspondence problem
• Allows us to use only one camera

camera projector

• L. Zhang, B. Curless, and S. M. Seitz. Rapid Shape Acquisition Using Color Structured

Light and Multi-pass Dynamic Programming. 3DPVT 2002

Kinect and Iphone X Solution

• Add Texture!

Kinect: Structured infrared light

http://bbzippo.wordpress.com/2010/11/28/kinect-in-infrared/

iPhone X

Basic stereo matching algorithm

• If necessary, rectify the two stereo images to transform

epipolar lines into scanlines

• For each pixel x in the first image
• Find corresponding epipolar scanline in the right image
• Examine all pixels on the scanline and pick the best match x’
• Compute disparity x–x’ and set depth(x) = B*f/(x–x’)

Effect of window size

• Smaller window

+ More detail

• More noise
• Larger window

+ Smoother disparity maps

• Less detail

W = 3 W = 20

Results with window search

Window-based matching Ground truth Data

Better methods exist...

Graph cuts Ground truth

For the latest and greatest: http://www.middlebury.edu/stereo/

• Y. Boykov, O. Veksler, and R. Zabih, Fast Approximate Energy

Minimization via Graph Cuts, PAMI 2001

When cameras are not aligned: Stereo image rectification

• Reproject image planes onto a common
• plane parallel to the line between optical centers
• Pixel motion is horizontal after this transformation
• Two homographies (3x3 transform), one for each input image

reprojection

• C. Loop and Z. Zhang. Computing Rectifying Homographies for Stereo Vision. IEEE
• Conf. Computer Vision and Pattern Recognition, 1999.

Rectification example

Credit: William Hoff, Colorado School of Mines

Back to the General Problem

Credit: William Hoff, Colorado School of Mines

Back to the General Problem

Credit: William Hoff, Colorado School of Mines

Back to the General Problem

Credit: William Hoff, Colorado School of Mines

Back to the General Problem

Credit: William Hoff, Colorado School of Mines

Back to the General Problem

Credit: William Hoff, Colorado School of Mines

Back to the General Problem

Credit: William Hoff, Colorado School of Mines

Back to the General Problem

Brief Digression: Cross Product as Matrix Multiplication

• Dot Product as matrix multiplication: Easy

!" !$ !% & '" '$ '% = !"'" + !$'$ + !%'% !" !$ !% '" '$ '% * = !"'" + !$'$ + !%'%

• Cross Product as matrix multiplication:

Credit: William Hoff, Colorado School of Mines

Back to the General Problem

The Essential Matrix

The Essential Matrix

Credit: William Hoff, Colorado School of Mines

Essential Matrix (Longuet-Higgins, 1981)

X

x x ’

Epipolar constraint: Calibrated case

• Intrinsic and extrinsic parameters of the cameras are known, world

coordinate system is set to that of the first camera

• Then the projection matrices are given by K[I | 0] and K’[R | t]
• We can multiply the projection matrices (and the image points) by the

inverse of the calibration matrices to get normalized image coordinates:

X t R x K x X, I x K x ] [ 0] [

pixel 1 norm pixel 1 norm

= ¢ ¢ = ¢ = =

X

x x’ = Rx+t

Epipolar constraint: Calibrated case

R t

The vectors Rx, t, and x’ are coplanar

= (x,1)T

[ ]

÷ ÷ ø ö ç ç è æ 1 x I

[ ]

÷ ÷ ø ö ç ç è æ 1 x t R

Epipolar constraint: Calibrated case

] ) ( [ = ´ × ¢ x R t x

! x T[t×]Rx = 0

X

x x’ = Rx+t

b a b a ] [

´

= ú ú ú û ù ê ê ê ë é ú ú ú û ù ê ê ê ë é

• =

´

z y x x y x z y z

b b b a a a a a a

Recall:

The vectors Rx, t, and x’ are coplanar

Epipolar constraint: Calibrated case

] ) ( [ = ´ × ¢ x R t x

! x T[t×]Rx = 0

X

x x’ = Rx+t

! x TE x = 0

Essential Matrix (Longuet-Higgins, 1981) The vectors Rx, t, and x’ are coplanar

X

x x ’

Epipolar constraint: Calibrated case

• E x is the epipolar line associated with x (l' = E x)
• Recall: a line is given by ax + by + c = 0 or

! x TE x = 0

ú ú ú û ù ê ê ê ë é = ú ú ú û ù ê ê ê ë é = = 1 , where y x c b a

T

x l x l

X

x x ’

Epipolar constraint: Calibrated case

• E x is the epipolar line associated with x (l' = E x)
• ETx' is the epipolar line associated with x' (l = ETx')
• E e = 0 and ETe' = 0
• E is singular (rank two)
• E has five degrees of freedom

! x TE x = 0

Epipolar constraint: Uncalibrated case

• The calibration matrices K and K’ of the two

cameras are unknown

• We can write the epipolar constraint in terms of

unknown normalized coordinates:

X

x x ’

ˆ ˆ = ¢ x E x T

x K x x K x ¢ ¢ = ¢ =

• 1

1

ˆ , ˆ

Epipolar constraint: Uncalibrated case

X

x x ’

Fundamental Matrix

(Faugeras and Luong, 1992)

ˆ ˆ = ¢ x E x T

x K x x K x ¢ ¢ = ¢ =

• 1

1

ˆ ˆ

1

with

• ¢

= = ¢ K E K F x F x

T T

Epipolar constraint: Uncalibrated case

• F x is the epipolar line associated with x (l' = F x)
• FTx' is the epipolar line associated with x' (l = FTx')
• F e = 0 and FTe' = 0
• F is singular (rank two)
• F has seven degrees of freedom

X

x x ’

ˆ ˆ = ¢ x E x T

1

with

• ¢

= = ¢ K E K F x F x

T T

Estimating the Fundamental Matrix

• 8-point algorithm
• Least squares solution using SVD on equations from 8 pairs of correspondences
• Enforce det(F)=0 constraint using SVD on F
• 7-point algorithm
• Use least squares to solve for null space (two vectors) using SVD and 7 pairs of

correspondences

• Solve for linear combination of null space vectors that satisfies det(F)=0
• Minimize reprojection error
• Non-linear least squares

Note: estimation of F (or E) is degenerate for a planar scene.

8-point algorithm

• 1. Solve a system of homogeneous linear equations

a. Write down the system of equations

= ¢ x x F

T

!!"#

$$ + !&"# $' + !# $( + &!"# '$ + &&"# '' + &# '( + !"# ($ + &"# (' + # (( = 0

A, = !$!$′ !$&$′ !$ &$!$′ &$&$′ &$ !$′ &$′ 1 ⋮ !0!1

"

⋮ !0&0′ ⋮ !0 ⋮ &0!0′ ⋮ &0&0′ ⋮ &0 ⋮ !0′ ⋮ &0′ ⋮ 1 #

$$

#

$'

#

$(

#

'$

⋮ #

((

=0

8-point algorithm

• 1. Solve a system of homogeneous linear equations

a. Write down the system of equations b. Solve f from Af=0 using SVD

Matlab:

[U, S, V] = svd(A); f = V(:, end); F = reshape(f, [3 3])’;

Optical Flow

Slides by Juan Carlos Niebles and Ranjay Krishnan

From images to videos

• A video is a sequence of frames captured over time
• Now our image data is a function of space (x, y) and time (t)

Why is motion useful?

Why is motion useful?

Optical flow

• Definition: optical flow is the apparent motion of

brightness patterns in the image

• Note: apparent motion can be caused by lighting

changes without any actual motion

• Think of a uniform rotating sphere under fixed lighting
• vs. a stationary sphere under moving illumination

GOAL: Recover image motion at each pixel from

• ptical flow

Source: Silvio Savarese

Picture courtesy of Selim Temizer - Learning and Intelligent Systems (LIS) Group, MIT

Optical flow

Vector field function of the spatio-temporal image brightness variations

Estimating optical flow

• Given two subsequent frames, estimate the apparent motion field

u(x,y), v(x,y) between them

• Key assumptions
• Brightness constancy: projection of the same point looks the same in

every frame

• Small motion: points do not move very far
• Spatial coherence: points move like their neighbors

I(x,y,t–1) I(x,y,t)

Source: Silvio Savarese

Key Assumptions: small motions

Key Assumptions: spatial coherence

* Slide from Michael Black, CS143 2003

Key Assumptions: brightness Constancy

* Slide from Michael Black, CS143 2003

I(x +u, y + v,t) ≈ I(x, y,t −1)+ Ix ⋅u(x, y)+ Iy ⋅v(x, y)+ It

• Brightness Constancy Equation:

I(x, y,t −1) = I(x +u(x, y), y + v(x, y),t)

Linearizing the right side using Taylor expansion: I(x,y,t–1) I(x,y,t) » + × + ×

t y x

I v I u I Hence,

Image derivative along x

→ ∇I ⋅ u v

[ ]

T + It = 0

I(x +u, y + v,t)− I(x, y,t −1) = Ix ⋅u(x, y)+ Iy ⋅v(x, y)+ It

Source: Silvio Savarese

The brightness constancy constraint

Filters used to find the derivatives

!" !# !$

• How many equations and unknowns per pixel?

The component of the flow perpendicular to the gradient (i.e., parallel to the edge) cannot be measured edge (u,v) (u’,v’) gradient (u+u’,v+v’)

If (u, v ) satisfies the equation, so does (u+u’, v+v’ ) if

• One equation (this is a scalar equation!), two unknowns (u,v)

∇I ⋅ u' v'

[ ]

T = 0

Can we use this equation to recover image motion (u,v) at each pixel?

Source: Silvio Savarese

The brightness constancy constraint

∇I ⋅ u v

[ ]

T + It = 0

The aperture problem

Actual motion

Source: Silvio Savarese

The aperture problem

Perceived motion

Source: Silvio Savarese

The barber pole illusion

http://en.wikipedia.org/wiki/Barberpole_illusion

Source: Silvio Savarese

The barber pole illusion

http://en.wikipedia.org/wiki/Barberpole_illusion

Source: Silvio Savarese

What we will learn today?

• Optical flow
• Lucas-Kanade method

Reading: [Szeliski] Chapters: 8.4, 8.5

[Fleet & Weiss, 2005] http://www.cs.toronto.edu/pub/jepson/teaching/vision/2503/opticalFlow.pdf

Solving the ambiguity…

• How to get more equations for a pixel?
• Spatial coherence constraint:
• Assume the pixel’s neighbors have the same (u,v)
• If we use a 5x5 window, that gives us 25 equations per pixel
• B. Lucas and T. Kanade. An iterative image registration technique with an application to stereo
• vision. In Proceedings of the International Joint Conference on Artificial Intelligence, pp. 674–

679, 1981.

Source: Silvio Savarese

• Overconstrained linear system:

Lucas-Kanade flow

Source: Silvio Savarese

• Overconstrained linear system

The summations are over all pixels in the K x K window

Least squares solution for d given by

Source: Silvio Savarese

Lucas-Kanade flow

Conditions for solvability

• Optimal (u, v) satisfies Lucas-Kanade equation

Does this remind anything to you?

When is This Solvable?

• ATA should be invertible
• ATA should not be too small due to noise

– eigenvalues l1 and l 2 of ATA should not be too small

• ATA should be well-conditioned

– l 1/ l 2 should not be too large (l 1 = larger eigenvalue)

Source: Silvio Savarese

• Eigenvectors and eigenvalues of ATA relate to

edge direction and magnitude

• The eigenvector associated with the larger eigenvalue points in

the direction of fastest intensity change

• The other eigenvector is orthogonal to it

M = ATA is the second moment matrix ! (Harris corner detector…)

Source: Silvio Savarese

Interpreting the eigenvalues

l1 l2 “Corner” l1 and l2 are large, l1 ~ l2 l1 and l2 are small “Edge” l1 >> l2 “Edge” l2 >> l1 “Flat” region

Classification of image points using eigenvalues of the second moment matrix:

Source: Silvio Savarese

Edge

– gradients very large or very small – large l1, small l2

Source: Silvio Savarese

Low-texture region

– gradients have small magnitude

– small l1, small l2

Source: Silvio Savarese

High-texture region

– gradients are different, large magnitudes

– large l1, large l2

Source: Silvio Savarese

Errors in Lukas-Kanade

What are the potential causes of errors in this procedure?

• Suppose ATA is easily invertible
• Suppose there is not much noise in the image
• When our assumptions are violated

– Brightness constancy is not satisfied – The motion is not small – A point does not move like its neighbors

• window size is too large
• what is the ideal window size?

* From Khurram Hassan-Shafique CAP5415 Computer Vision 2003

– Can solve using Newton’s method (out of scope for this class) – Lukas-Kanade method does one iteration of Newton’s method

• Better results are obtained via more iterations

Improving accuracy

• Recall our small motion assumption
• This is not exact

– To do better, we need to add higher order terms back in:

• This is a polynomial root finding problem

It-1(x,y) It-1(x,y) It-1(x,y)

* From Khurram Hassan-Shafique CAP5415 Computer Vision 2003

Iterative Refinement

• Iterative Lukas-Kanade Algorithm

1. Estimate velocity at each pixel by solving Lucas- Kanade equations 2. Warp I(t-1) towards I(t) using the estimated flow field

• use image warping techniques

3. Repeat until convergence

* From Khurram Hassan-Shafique CAP5415 Computer Vision 2003

When do the optical flow assumptions fail?

In other words, in what situations does the displacement of pixel patches not represent physical movement of points in space?

• 1. Well, TV is based on illusory motion

– the set is stationary yet things seem to move

• 2. A uniform rotating sphere

– nothing seems to move, yet it is rotating

• 3. Changing directions or intensities of lighting can make things seem to move

– for example, if the specular highlight on a rotating sphere moves.

• 4. Muscle movement can make some spots on a cheetah move opposite direction of motion.

– And infinitely more break downs of optical flow.

Questions?

83
