SLIDE 1

Stream Reasoning For Linked Data

M. Balduini, J-P Calbimonte, O. Corcho,
D. Dell'Aglio, and E. Della Valle

http://streamreasoning.org/events/sr4ld2014

Stream Reasoning introduction

Emanuele Della Valle emanuele.dellavalle@polimi.it http://emanueledellavalle.org

SLIDE 2

http://streamreasoning.org/events/sr4ld2014

Share, Remix, Reuse — Legally

§ This work is licensed under the Creative Commons Attribution 3.0 Unported License. § Your are free:

to Share — to copy, distribute and transmit the work
to Remix — to adapt the work

§ Under the following conditions

Attribution — You must attribute the work by inserting

– “[source http://streamreasoning.org/events/sr4ld2014]” at the end of each reused slide – a credits slide stating

These slides are partially based on “Streaming Reasoning for Linked Data

2014” by M. Balduini, J-P Calbimonte, O. Corcho, D. Dell'Aglio, and

E. Della Valle, http://streamreasoning.org/events/sr4ld2013

§ To view a copy of this license, visit http://creativecommons.org/licenses/by/3.0/

2

SLIDE 3

http://streamreasoning.org/events/sr4ld2014

Agenda

§ It's a streaming world § Continuous semantics § Data Stream Management Systems and Complex Event Processors § Stream Reasoning § Research Challenges § Approaches § Structure of the tutorial § More on Stream Reasoning at ISWC 2014

3

SLIDE 4

http://streamreasoning.org/events/sr4ld2014

4

It‘s a streaming World! 1/3

[source http://y2socialcomputing.files.wordpress.com/2012/06/social-media-visual-last-blog-post-what-happens-in-an-internet-minute-infographic.jpg ]

SLIDE 5

http://streamreasoning.org/events/sr4ld2014

It‘s a streaming World! 2/3

§ Oil operations § Traffic § Financial markets § Social networks § Generate data streams!

5

SLIDE 6

http://streamreasoning.org/events/sr4ld2014

It's a streaming World! 2/2

§ What is the expected time to failure when that turbine's barring starts to vibrate as detected in the last 10 minutes? § Is public transportation where the people are? § Who are the best available agents to route all these unexpected contacts about the tariff plan launched yesterday? § Who is driving the discussion about the top 10 emerging topics ?

E. Della Valle, S. Ceri, F. van Harmelen, D. Fensel It's a Streaming World! Reasoning

upon Rapidly Changing Information. IEEE Intelligent Systems 24(6): 83-89 (2009) 6

SLIDE 7

http://streamreasoning.org/events/sr4ld2014

Requirements 1/8

A system able to answer those queries must be able to § handle massive datasets

A typical oil production platform is equipped

with about 400.000 sensors

Telecom data is the most pervasive data

source in urban are, in Milano there are 1.8 million mobile users

A global contact centre of a Telecom
perator counts 500 millions of clients
Facebook alone has 1.1 billion
f active users

7

SLIDE 8

http://streamreasoning.org/events/sr4ld2014

Requirements 2/8

A system able to answer those queries must be able to § process data streams on the fly

The sensors on typical oil production

platform generates 10,000 observations per minute with peaks of 100,000 o/m

The mobile users in Milano generates

20,000 call/sms/data connections per minute with peaks of 80,000 c/m

A global contact centre receives

10,000 contacts per minute with peaks of 30,000 c/m

Facebook, as of May 2013, observes

3 millions "I like" per minute

8

SLIDE 9

http://streamreasoning.org/events/sr4ld2014

Requirements 3/8

A system able to answer those queries must be able to § cope with heterogeneous dataset

The sensors on typical oil production

have been deployed over 10 years by 10s of different producers

Tens of data sources are normally

needed to make sense of an urban phenomena

A global contact centre consists in 100s
f offices owned by different subsidiary

companies engaged yearly

Each social network has its own

data model, APIs, …

9

SLIDE 10

http://streamreasoning.org/events/sr4ld2014

Requirements 4/8

A system able to answer those queries must be able to § cope with incomplete data

10s of sensors and networking links

broke down daily

Coverage is incomplete
Only standard cases are covered by

fully machine processable data records 100s of contacts per minute are manage ad-hoc

Conversations happen outside the

social networks, too!

10

SLIDE 11

http://streamreasoning.org/events/sr4ld2014

Requirements 5/8

A system able to answer those queries must be able to § cope with noisy data

Sensor out-of-operating range
Faulty sensors
Agents misunderstand, get tired, …
Irony, sarcasm, …

11

SLIDE 12

http://streamreasoning.org/events/sr4ld2014

Requirements 6/8

A system able to answer those queries must be able to § provide reactive answers

detection of dangerous situations

must occur within minutes

recommendations to citizens must

be performed in few seconds

routing a contact through each step of

the decision tree must take less than a second

Search autocompleting may need

to be updated every few minutes

12

SLIDE 13

http://streamreasoning.org/events/sr4ld2014

Requirements 7/8

A system able to answer those queries must be able to § support fine-grained information access

Identify a turbine among thousands
Locate a bus among thousands
Contact an agent among thousands
Identify an opinion maker among

thousands of influencers for a topic

13

SLIDE 14

http://streamreasoning.org/events/sr4ld2014

Requirements 8/8

A system able to answer those queries must be able to § integrate complex domain models of

perational and control process
various city aspects
contact management, contract types,

agent skills, contactor profiles, …

topics, user profiles, …

14

SLIDE 15

http://streamreasoning.org/events/sr4ld2014

Requirements (wrap up)

A system able to answer those queries must be able to § handle massive datasets § process data streams on the fly § cope with heterogeneous dataset § cope with incomplete data § cope with noisy data § provide reactive answers § support fine-grained information access § integrate complex domain models

15

SLIDE 16

http://streamreasoning.org/events/sr4ld2014

What are data streams anyway?

§ Formally:

Data streams are unbounded sequences of time-varying data

elements

§ Less formally:

an (almost) “continuous” flow of information

§ Assumption

recent information is more relevant as it describes the

current state of a dynamic system

time

16

SLIDE 17

http://streamreasoning.org/events/sr4ld2014

The continuous nature of streams

§ The nature of streams requires a paradigmatic change*

from persistent data

– to be stored and queried on demand – a.k.a. one time semantics

to transient data

– to be consumed on the fly by continuous queries – a.k.a. continuous semantics § * This paradigmatic change first arose in DB community [Henzinger98]

17

SLIDE 18

http://streamreasoning.org/events/sr4ld2014

Continuous Semantics

§ Continuous queries registered over streams that, in most

f the cases, are observed trough windows

window input streams streams of answer

Registered ¡ Con-nuous ¡ Query ¡

18

Dynamic ¡ System

SLIDE 19

http://streamreasoning.org/events/sr4ld2014

Example

§ Input

Smoke and Temperature sensors in many areas

§ Query

Alert me when there is a fire, i.e. smoke and temp>50

§ DSMS formulation

Stream the areas where smoke is detected over two windows
pen on smoke and temperature streams

Select IStream(Smoke.area) From Smoke[Rows 30 Slide 10], Temp[Rows 50 Slide 5] Where Smoke.area = Temp.area AND Temp.value > 50

§ CEP formulation

Rise a fire event in an area when smoke and high

temperature events are received within 1 minute define Fire(area: string, measuredTemp: double) from Smoke(area=$a) and each Temp(area=$a and val>50) within 1min. where area=Smoke.area and measuredTemp=Temp.value

19

SLIDE 20

http://streamreasoning.org/events/sr4ld2014

DSMS/CEP State of the Art

§ Gianpaolo Cugola, Alessandro Margara: Processing flows of information: From data stream to complex event

processing. ACM Comput. Surv. 44(3): 15 (2012)

§ Content

Type of models compared

– Functional and processing – Deployment and interactions – Data, Time, and Rule – Language

# of systems surveyed:

– Academic: 24 – Industrial: 9 – Total: 33

To learn more:

– http://home.dei.polimi.it/margara/papers/survey.pdf

20

SLIDE 21

http://streamreasoning.org/events/sr4ld2014

21

DSMS/CEP Market Players

[source https://ctrlaltcep.files.wordpress.com/2013/01/cepmarket1212.png ]

SLIDE 22

http://streamreasoning.org/events/sr4ld2014

Existing solutions Requirement DSMS CEP massive datasets data streams heterogeneous dataset incomplete data noisy data reactive answers fine-grained information access complex domain models

22

✗ ✗ ✗

SLIDE 23

http://streamreasoning.org/events/sr4ld2014

§ Given ontology O and query Q, use O to rewrite Q as Q’ so that, for any set of ground facts A contained in multiple databases:

answer(Q,O,A) = answer(Q’,,A)

– The answer of the query Q using the ontology O for any set of ground facts A is equal to answer of a query Q’ without considering the ontology O

§ Use mapping M to map Q’ to multiple SQL queries to the various databases

Ontology Based Data Access Rewrite

O Q Q’

Map SQL

M answer

A

23

SLIDE 24

http://streamreasoning.org/events/sr4ld2014

Existing solutions Requirement DSMS CEP OBDA massive datasets data streams heterogeneous dataset incomplete data noisy data reactive answers fine-grained information access complex domain models

24

✗ ✗ ✗ ✗ ✗ ✗

SLIDE 25

http://streamreasoning.org/events/sr4ld2014

Stream Reasoning Definition

§ Making sense

in real time
f multiple, heterogeneous, gigantic and inevitably noisy data

streams

in order to support the decision process of extremely large

numbers of concurrent user

§ Note: making sense of streams necessarily requires processing them against rich background knowledge, an unsolved problem in database

25

D. Barbieri, D. Braga, S. Ceri, E. Della Valle, Y. Huang, V. Tresp, A.Rettinger, H. Wermser:

Deductive and Inductive Stream Reasoning for Semantic Social Media Analytics IEEE Intelligent Systems, 30 Aug. 2010.

SLIDE 26

http://streamreasoning.org/events/sr4ld2014

Research Challenges

§ Relation with DSMSs and CEPs

Just as RDF relates to data-base systems?

§ Data types and query languages for semantic streams

Just RDF and SPARQL but with continuous semantics?

§ Reasoning on Streams

Theory: formal semantics
Efficiency
Scalability and approximation

§ Dealing with incomplete & noisy data

Even more than on the current Web of Data

§ Distributed and parallel processing

Streams are parallel in nature, data stream sources are

distributed, …

§ Engineering Stream Reasoning Applications

Development Environment
Integration with other technologies
Benchmarks as rigorous means for comparison

26

SLIDE 27

http://streamreasoning.org/events/sr4ld2014

Stream Reasoning feasibility (intuition)

§ Many relevant reasoning methods are not able to deal with high frequency data streams § However, trade-off exists between the complexity of the reasoning method and the frequency of the data stream the reasoner

27 Raw ¡Stream ¡Processing ¡ Seman-c ¡Streams ¡

Logic ¡Programs ¡

DL ¡ Complexity ¡ Reasoning ¡ Querying ¡ Rewri-ng ¡ Abstrac-on ¡ Selec-on ¡ Interpreta-on ¡ Change ¡Frequency ¡

PTIME ¡ 2NEXPTIME ¡

104 ¡Hz ¡ 1 ¡Hz ¡ ¡

Dynamics ¡and ¡Scale ¡vs. ¡Complexity ¡ Heiner Stuckenschmidt, Stefano Ceri, Emanuele Della Valle, Frank van Harmelen: Towards Expressive Stream Reasoning. Proceedings of the Dagstuhl Seminar on Semantic Aspects of Sensor Networks, 2010.

AC0 ¡

SLIDE 28

http://streamreasoning.org/events/sr4ld2014

Approaches (a selection) 1/4

§ RDF Stream Processors (ordered by year)

Streaming SPARQL

– Andre Bolles, Marco Grawunder, Jonas Jacobi: Streaming SPARQL - Extending SPARQL to Process Data Streams. ESWC 2008: 448-462

C-SPARQL

– Davide Francesco Barbieri, Daniele Braga, Stefano Ceri, Emanuele Della Valle, Michael Grossniklaus: Querying RDF streams with C-SPARQL. SIGMOD Record 39(1): 20-26 (2010)

SPARQLstream

– Jean-Paul Calbimonte, Óscar Corcho, Alasdair J. G. Gray: Enabling Ontology-Based Access to Streaming Data Sources. International Semantic Web Conference (1) 2010: 96-111

CQELS

– Danh Le Phuoc, Minh Dao-Tran, Josiane Xavier Parreira, Manfred Hauswirth: A Native and Adaptive Approach for Unified Processing of Linked Streams and Linked Data. International Semantic Web Conference (1) 2011: 370-388

It continues in next slide …

28

SLIDE 29

http://streamreasoning.org/events/sr4ld2014

Approaches (a selection) 2/4

… it continues from previous slide
INSTANS

– Rinne, M., Nuutila, E., Törma, S.: INSTANS: High-Performance Event Processing with Standard RDF and SPARQL. Poster in ISWC2012.

Streaming Linked Data

– Marco Balduini, Emanuele Della Valle, Daniele Dell’Aglio, Mikalai Tsytsarau, Themis Palpanas, Cristian Confalonieri: Social listening of City Scale Events using the Streaming Linked Data

Framework. ISWC 2013
TEF-SPARQL (under development)

– Shen Gao, Thomas Scharrenbach, Abraham Bernstein: The CLOCK Data-Aware Eviction Approach: Towards Processing Linked Data Streams with Limited Resources. ESWC 2014: 6-20

29

SLIDE 30

http://streamreasoning.org/events/sr4ld2014

Approaches (a selection) 3/4

§ Stream Reasoners (ordered by year)

Streaming Knowledge Bases

– Walavalkar, O., Joshi, A., Finin, T., Yesha, Y., 2008. Streaming knowledge bases. In: In International Workshop on Scalable Semantic Web Knowledge Base Systems

IMaRS

– Davide Francesco Barbieri, Daniele Braga, Stefano Ceri, Emanuele Della Valle, Michael Grossniklaus: Incremental Reasoning on Streams and Rich Background Knowledge. ESWC (1) 2010: 1-15

TrOWL

– Yuan Ren, Jeff Z. Pan: Optimising ontology stream reasoning with truth maintenance system. CIKM 2011: 831-836

ETALIS (EP-SPARQL)

– Darko Anicic, Paul Fodor, Sebastian Rudolph, Nenad Stojanovic: EP-SPARQL: a unified language for event processing and stream

reasoning. WWW 2011: 635-644
It continues in next slide …

30

SLIDE 31

http://streamreasoning.org/events/sr4ld2014

Approaches (a selection) 4/4

… continues from previous slide
Sparkwave

– Srdjan Komazec, Davide Cerri, Dieter Fensel: Sparkwave: continuous schema-enhanced pattern matching over RDF data

streams. DEBS 2012: 58-68
SR-Based on Answer Set Programming

– Martin Gebser, Torsten Grote, Roland Kaminski, Philipp Obermeier, Orkunt Sabuncu, Torsten Schaub: Stream Reasoning with Answer Set Programming: Preliminary Report. KR 2012

Parallelising Stream Reasoning

– Jacopo Urbani, Alessandro Margara, Ceriel J. H. Jacobs, Frank van Harmelen, Henri E. Bal: DynamiTE: Parallel Materialization of Dynamic RDF Data. International Semantic Web Conference (1) 2013: 657-672 – Chang Liu, Jacopo Urbani, Guilin Qi: Efficient RDF stream reasoning with graphics processingunits (GPUs). WWW (Companion Volume) 2014: 343-344

STARQL (under development)

– ÖL Özçep, R Möller, C Neuenstadt, “A Stream-Temporal Query Language for Ontology Based Data Access”. Description Logics, 2014

31

SLIDE 32

http://streamreasoning.org/events/sr4ld2014

32

Running Example

BlueRoom RedRoom RedSensor BlueSensor

R

f 4 f

Alice David Bob Carl Elena

R

RFID

4

Foursquare

f

Facebook is with

SLIDE 33

http://streamreasoning.org/events/sr4ld2014

Running Example

§ Four ways to learn who is where

33 Sensor Room Person Time-stamp RedSensor RedRoom Alice T1 … … … … Person ChecksIn Time-stamp Bob BlueRoom T2 … … … Person IsIn With Time-stamp Carl null Bob T2 David RedRoom Elena T3 … … … …

SLIDE 34

http://streamreasoning.org/events/sr4ld2014

34

Running Example – Data Model

Observation Sensor Person Post Room where discusses who

bserves

subClassOf subClassOf posts subPropOf

Streaming information Background information

isWith isIn isConnectedTo

SLIDE 35

http://streamreasoning.org/events/sr4ld2014

Running Example – Data Model (formally)

§ Details about hands-on ontology

isConnectedTo is a symmetric property
discusses is a transitive property
isWith is a composition of posts and who
isIn is either a composition of posts and where
r a composition of isWith and isIn

§ Available online

http://www.streamreasoning.org/ontologies/sr4ld2014-onto.rdf

35

SLIDE 36

http://streamreasoning.org/events/sr4ld2014

Structure of the tutorial

§ 9.00 - 10.30

Stream Reasoning introduction (30 min)
RDF stream processing models (60 min)

§ 11.00 – 12.30

An overview of Stream Reasoning (30 min)
C-SPARQL Engine: A RDF Stream Processing system for the

Continuous Extension of SPARQL (C-SPARQL) with Naive Stream Reasoning support (30m)

MorphStream: Ontology-based streaming data access (30m)

§ 13:45 - 15.30

Hands on session (120min)

– From Web tools to JavaCode in Eclipse

§ 16:00 - 17.30

IMaRS: Incremental Materialization for RDF Streams (30m)
Other Stream Reasoning approaches (30 min)
Wrap-up and conclusions (30 min)

36

SLIDE 37

http://streamreasoning.org/events/sr4ld2014

Water, water, every where, Nor any drop to drink.

- The Rime of the Ancient Mariner

Samuel Taylor Coleridge, 1798

Streams, streams everywhere nor any actionable fact to use

- Emanuele and Daniele, 2013 :-P

37

Have fun! Any question?

SLIDE 38

Stream Reasoning For Linked Data

M. Balduini, J-P Calbimonte, O. Corcho,
D. Dell'Aglio, and E. Della Valle

http://streamreasoning.org/events/sr4ld2014
