Establishing a Seaweed industry in Norway: strategic, economic, and life-cycle perspectives

Matthias Koesling, NIBIO

Introduction to life-cycle thinking

Every day example

• From Material Flow Analysis

to Life-cycle assessment

14/11/2018 2

3

Travelling 100 km (Åndalsnes-Ålesund)

– Using a modern car – 7 litre gasoline/100 km – Energy density 33.1 MJ/l – Energy needed: 7 l/100 km * 33 MJ/l = 198 MJ/100 km

Ca 100 km

Life cycle questions

– How much energy was necessary to produce the gasoline and the car? – What is the environmental impact of producing the gasoline and combusting it?

14/11/2018 4

5

How much energy is necessary to get 1 l gasoline to filling station?

Energy needed for entire way: 7 MJ/l gasoline Energy density of gasoline: 33 MJ/l

6

LCA for travelling 100 km (Åndalsnes-Ålesund)

ADP fossil

GLO: Passenger car (medium, gasoline, 1 piece) ts <LC> EU-28: Gasoline mix (regular) at filling station ts

Abiotic Depletion fossil [MJ]

281,6 256,0 230,4 204,8 179,2 153,6 128,0 102,4 76,8 51,2 25,6 0,0

Use of fossil energy [MJ]

Gasoline at filling station Car-production

7

LCA for travelling 100 km (Åndalsnes-Ålesund)

– Use of gasoline – 7 l/100 km Car: production and use

https://picsart.com/i/sticker-rauch-260477178012212

GWP 100 years

GLO: Passenger car (medium, gasoline, 1 piece) ts <LC> EU-28: Gasoline mix (regular) at filling station ts GLO: Car petrol, Euro 5, engine size 1,4-2l ts <u-so>

Global Warming Potential [kg CO2-Equiv .]

17,6 16,0 14,4 12,8 11,2 9,6 8,0 6,4 4,8 3,2 1,6 0,0

14/11/2018 8

LCA for travelling 100 km (Åndalsnes-Ålesund)

Global warming potential [CO2-equivalents]

Car-production Gasoline at filling station Gasoline combustion

14.11.2018 9

LCA for travelling 100 km (Åndalsnes-Ålesund)

Life-cycle assessment (LCA)

Assess environmental impacts from all the stages of a product's life: – Raw material extraction – Materials processing – Manufacture – Distribution – Use – Repair and maintenance – Disposal or recycling

10

• Protein production

– Soy protein – Seaweed protein

14/11/2018 11

24,000 MJ 278,000 MJ

Results from different approaches Energy demand per t protein

Material Flow Analysis

14/11/2018 12

Soy Seaweed

about 12 times

24,000 MJ 278,000 MJ

Results from different approaches Energy demand per t protein

Material Flow Analysis LCA

38,000 MJ

(non renewable)

122,000 MJ

(renewable)

443,000 MJ

14/11/2018 13

Soy Seaweed

about 12 times about 12 times

Seaweed LCA-results in detail

14/11/2018 14

1 - Gametophyte culture 2 - Sporophyte culture 3 - Deployment & growth at sea 4 - Harvest 5 – Transport 6 - Drying 7 - Extraction 8 - Transportation

ADP fossil

Total NO: GP3 - Deploym... NO: GP4 - Harvest ... NO: GP4 b Transpor... NO: GP5 - Drying of... NO: GP6 - Extractio... Rest

Abiotic Depletion fossil [MJ]

471 859,2 419 430,4 367 001,60000000006 314 572,80000000006 262 144,00000000006 209 715,20000000006 157 286,4000000001 104 857,60000000008 52 428,80000000008 0,00000000007

Seaweed LCA-results, todays production

14/11/2018 15

Use of fossil energy in MJ (Abiotic depletion, fossil)

Total 3 - Deployment & growth at sea 4 - Harvest 5 – Transport 6 - Drying; use of gas 7 - Extraction Rest

450 000 250 000 100 000

GWP 100 years

Total NO: GP2 - Sporophy... NO: GP3 - Deployme... NO: GP4 b Transport... NO: GP5 - Drying of ... NO: GP6 - Extraction... Rest

Global Warming Potential [kg CO2-Equiv .]

29 491,2 26 214,4 22 937,6 19 660,8 16 384,0 13 107,2 9 830,40000000001 6 553,60000000001 3 276,8 0,00000000000

14/11/2018 16

Seaweed LCA-results, todays production

Global warming potential (GWP) In kg CO2-equivalents

Total 3 - Deployment & growth at sea 4 - Harvest 5 – Transport 6 - Drying; use of gas 7 - Extraction Rest

30 000 20 000 10 000

Total, soy

14/11/2018 17

Seaweed LCA-results, todays production

ADP fossil

Total NO: GP3 - Deploym... NO: GP4 - Harvest ... NO: GP4 b Transpor... NO: GP5 - Drying of... NO: GP6 - Extractio... Rest

Abiotic Depletion fossil [MJ]

471 859,2 419 430,4 367 001,60000000006 314 572,80000000006 262 144,00000000006 209 715,20000000006 157 286,4000000001 104 857,60000000008 52 428,80000000008 0,00000000007 Scen 1 gas Scen 2 incin for free

14/11/2018 18

Seaweed LCA-results; Drying energy from incineration for free

Use of fossil energy in MJ (Abiotic depletion, fossil)

450 000 250 000 100 000

Total 3 – Deploy. & growth at sea 4 - Harvest 5 – Transport 6 - Drying; use of gas 7 - Extraction Rest

GWP 100 years

Total NO: GP2 - Sporophy... NO: GP3 - Deployme... NO: GP4 b Transport... NO: GP5 - Drying of ... NO: GP6 - Extraction... Rest

Global Warming Potential [kg CO2-Equiv .]

29 491,2 26 214,4 22 937,6 19 660,8 16 384,0 13 107,2 9 830,40000000001 6 553,60000000001 3 276,8 0,00000000000 Scen 1 gas Scen 2 incin for free

14/11/2018 19

Seaweed LCA-results; Drying energy from incineration for free

Total 3 – Deploy. & growth at sea 4 - Harvest 5 – Transport 6 - Drying; use of gas 7 - Extraction Rest

Global warming potential (GWP) In kg CO2-equivalents

30 000 20 000 10 000

GWP 100 years

Total NO: GP2 - Sporophy... NO: GP3 - Deploym... NO: GP4 b Transpor... NO: GP5 - Drying of ... NO: GP6 - Extractio... Rest

Global Warming Potential [kg CO2-Equiv .]

144 179,2 131 072,0 117 964,8 104 857,6 91 750,40000000001 78 643,20000000001 65 536,00000000001 52 428,80000000002 39 321,60000000002 26 214,40000000002 13 107,20000000002 0,00000000002 Scen 1 gas Scen 2 incin for free Scen 3a incin energ Scen 3b incin en + el

14/11/2018 20

Seaweed LCA-results; Drying energy from incineration

Global warming potential (GWP) In kg CO2-equivalents

Total 3 – Deploy. & growth at sea 5 – Transport 6 - Drying; use of gas

130 000 90 000 50 000 25 000 Including GWP from incineration

Three scenarios for different sizes

– Reference – todays volumes and technologies – IMTA integration – every fish farm in Norway integrates seaweed cultivation – Large scale

14.11.2018 21

Production sizes and transportation

14/11/2018 22

Number of locations Area per location ha Yield t WW/ha Production per location t WW Sum annual Production t WW Placed in counties Solund example 1 1.0 60 60 60 1 IMTA at every fish farm 1132 2.5 60 150 170 000 10 SES-size 90 32 60 1 900 170 000 2 Most fish farms 1000 100 60 6 000 6 000 000 6 Large scale 6 13 300 75 1 000 000 6 000 000 4

Production sizes and transportation

14/11/2018 23

Production per location t WW Sum annual Production t WW Placed in counties Solund example 60 60 1 IMTA at every fish farm 150 170 000 10 SES-size 1 900 170 000 2 Most fish farms 6 000 6 000 000 6 Large scale 1 000 000 6 000 000 4

ADP fossil

Abiotic Depletion fossil [MJ] 40 000 37 500 35 000 32 500 30 000 27 500 25 000 22 500 20 000 17 500 15 000 12 500 10 000 7 500 5 000 2 500 ts 1 Today 2 IMTA 3 SES-size 4 IMTA 6mio 5 Storskala

Use of fossil energy in MJ (diesel for transportation from farm to refinery)

0 10 000 20 000 30 000 MJ

14.11.2018 24

Utilising additional components to protein

25

When the entire economic and environmental costs for growing, harvesting, transporting and drying of algae is given, utilising more ingredients is reducing the costs per output unit.

14/11/2018 26

Utilising additional components to protein

14/11/2018 27

Saccharina latissima Harvested wet weight Dry weight Protein ~10 % Other valuable components

Seaweed farming in Norway has just started. Improvements for yield, ingredients, harvesting, storing and processing can be expected.

14/11/2018 28

14.11.2018 29

Contributions from

Nina Pereira Kvadsheim (Møreforsking Molde) Jan Emblemsvåg (Møreforsking Molde) Jon Halfdanarson (Møreforsking Molde) Matthias Koesling (NIBIO)

Project number: 244244 Funding received from: BIONÆR — Bionæringsprogram HAVBRUK2
