Stormwater Program Management in GSA’s National Capital Region (NCR)

Russell Clark Stormwater Program Manager

GSA Capital Region Portfolio At a Glance

• 100 million SF
• 43M Owned
• 57M Leased
• 956 buildings

Federal and Local Regulations

• Energy Independence and Security Act (EISA) - Section 438
• Clean Water Act - Chesapeake Bay TMDL
• Executive Orders - 13508 and 13693
• District of Columbia regulations and SRCs
• Maryland regulations and new MS4 permit
• Virginia regulations and Chesapeake Bay Preservation Areas

Nebraska Avenue Complex (DHS)

How GSA is Ensuring Better Stormwater Results Portfolio-wide

• Stormwater Task Force monthly meetings
• Relationship building with other GSA business-lines

–Office of Facilities Management –Office of Design and Construction –Office of Planning and Design Quality –Office of Portfolio Management

• Integrated stormwater into asset planning
• Created & filled new position - Regional Stormwater Program

Manager (2016)

Role of Stormwater Program Manager

• Performing design reviews and coordinating SW Task Force
• Visiting all BMPs in portfolio to evaluate condition and needs
• Capturing design, installation and maintenance pitfalls and avoid

issues in future designs

• Setting up regional maintenance contracts for certain BMP types
• Integrating BMP maintenance tasks into GSA’s National

Computerized Maintenance Management System

Possible Regional BMP Maintenance Contracts

Cistern Systems / Storm and Sand Filters

Identify High Priority Sites for Voluntary Projects

Phase 1a - US Coast Guard Headquarters

Herbert C. Hoover Building

Contact Information

Russell Clark Stormwater Program Manager US GSA, National Capital Region Public Buildings Service, Office of Facilities Management C: (202) 704-3642 russell.clark@gsa.gov

District of Columbia Water and Sewer Authority

George S. Hawkins, General Manager

May 8, 2017

APA National Planning Conference

Briefing for:

DC Water’s DC Clean Rivers Project

Briefing on:

1

DC Water’s DC Clean Rivers Project:

Where is the Combined Sewer System Located?

• Combined Sewer System

Covers 1/3 of the District (12,478 acres)

• 47 Active CSO outfalls
• 13 to Anacostia
• 10 to Potomac
• 24 to Rock Creek
• Three receiving waters
• Anacostia River
• Potomac River
• Rock Creek

2

DC Water’s DC Clean Rivers Project:

Consent Decree Timeline

January 14, 2016 – Consent Decree Modification Entered in Federal Court

3

Public Participation Public Participation

2142 1063 49 3254 1282 638 43 1963 54 79 5 138

500 1000 1500 2000 2500 3000 3500

Anacostia River Potomac River Rock Creek Total System

CSO Overflow (mg/avg year) 1996 2013 LTCP Completed

(DC Water Formed)

4

Total System 96% Reduction

DC Water’s DC Clean Rivers Project:

Magnitude of the Problem, DC Water’s Solution

Program Completion

2016

5

DC Water’s DC Clean Rivers Project:

The Right Technology for the Right Place

CSO’s 027, 028, 029: Manage volume equal to 1.2” of rain falling

• n 133 impervious

acres CSO’s 025, 026: Separate sewers CSO’s 020-024: Control using Potomac River Tunnel CSO 049: Manage volume equal to 1.2” of rain falling

• n 365 impervious acres

DC Water’s DC Clean Rivers Project:

GI Program Drivers

• Volume Management (Gallons)
• Control Combined Sewer Overflows
• Cost Effectiveness
• Responsibility to Rate Payers
• Maintenance/Asset Management
• Safety
• Aesthetics
• Performance
• Outreach
• Build Public Awareness and Stewardship
• Triple Bottom Line Benefits
• Deliver Multiple Benefits to the

Community

6 DC Water’s Green Roof

• n Fort Reno Reservoir

DC Water’s DC Clean Rivers Project:

GI Implementation Schedule

Potomac River GI Rock Creek GI

7

More information available at: dcwater.com/green

DC Water’s DC Clean Rivers Project:

GI Technologies for Right-of-Way

Siting and Design Goals:

• Match character and

aesthetic of neighborhoods

• Provide infrastructure

upgrades by prioritizing areas for implementation

• Provide ancillary

benefits to community

• Minimize temporary and

long-term impacts to community

• Coordinate work with
• ther entities (DDOT,
• ther utilities, etc.)

Planter Bioretention in Tree Planter Curb Extension Bioretention in Parking Lane Permeable Pavement in Parking Lane Permeable Pavement in Alley 8

Bioretention Permeable Pavement

DC Water’s DC Clean Rivers Project:

GI Technologies for Private Property

Bioretention in Right-of-Way Bioretention in Right-of-Way

• Free, voluntary Downspout Disconnection Program with

Rain Barrels - Drain the Rain!

9

More information available at: dcwater.com/draintherain

DC Water’s DC Clean Rivers Project:

Maintenance Goals

• GI is an asset that needs to be maintained
• DCCR’s Green Infrastructure Maintenance Program goals
• Performance: Ensure GI function to meet performance requirements
• Safety: Ensure public and maintenance crew safety
• Aesthetics: Ensure GI maintains the original project aesthetic goal

10

National Green Infrastructure Certification Program (NGICP)

• Initiated under the leadership of DC Water and

the Water Environment Federation (WEF), NGICP

• Sets national certification standards for GI

construction, inspection, and maintenance workers

• Designed to meet international best-practice

standards, NGICP advances the establishment

• f sustainable communities by:
• Promoting GI as an environmentally and

economically beneficial stormwater management option;

• Supporting the development of proficient

green workforces; and

• Establishing a career path for skilled GI

workers.

• 15 jurisdictions nationally have partnered

and are implementing NGICP locally

11 DC Spring 2017 Training for June 6, 2017 Exam

More information available at: ngicp.org

DC Water’s DC Clean Rivers Project:

Financing

• Rate Payer Funded
• Impervious Area Charge

12

Units Current FY 2016 Proposed 4.75% FY 2017 Proposed 5.0% FY 2018 DC Water and Sewer Retail Rates (1) Ccf 54.56 $ 57.17 $ 60.05 $ DC Water Clean Rivers IAC ERU 20.30 22.24 25.18 DC Water Customer Metering Fee 5/8" 3.86 3.86 3.86 DC Water Water System Replacement Fee (3) 5/8" 6.30 6.30 6.30 Subtotal DC Water Rates & Charges 85.02 $ 89.57 $ 95.39 $ Increase / Decrease 10.97 $ 4.55 $ 5.82 $ District of Columbia PILOT (1) Ccf 2.91 $ 2.98 $ 3.04 $ District of Columbia Right-of-Way Fee (1) Ccf 1.05 1.05 1.12 District of Columbia Stormwater Fee (2) ERU 2.67 2.67 2.67 Subtotal District of Columbia Charges 6.63 $ 6.70 $ 6.83 $ Total Amount Appearing on DC Water Bill 91.65 $ 96.27 $ 102.22 $ Increase / Decrease Over Prior Year 11.03 $ 4.62 $ 5.95 $ Percent Increase in Total Bill 13.7% 5.0% 6.2%

(1) Assumes average monthly consumption of 6.20 Ccf, or (4,638 gallons)

• Innovative Financing Mechanisms
• Green Bond, Environmental Impact Bond

Questions?

Bethany Bezak, PE, LEED AP

Green Infrastructure Manager DC Water and Sewer Authority Email: Bethany.Bezak@dcwater.com

PARK(ing) Day, 2014 13

Innovative Stormwater Management in Washington, DC

National Planning Conference | May 8, 2017 | 4:15pm – 5:30pm

1

Stormwater Perspectives

City / Stormwater Utility Water and Sewer Utility Federal / Facility Manager

2

Stormwater Perspectives

BRIAN VAN WYE District Department of Energy and Environment

City / Stormwater Utility Water and Sewer Utility Federal / Facility Manager

3

Stormwater Perspectives

BRIAN VAN WYE District Department of Energy and Environment RUSSELL CLARK General Services Administration

City / Stormwater Utility Water and Sewer Utility Federal / Facility Manager

4

Stormwater Perspectives

BRIAN VAN WYE District Department of Energy and Environment RUSSELL CLARK General Services Administration BETHANY BEZAK DC Water

City / Stormwater Utility Water and Sewer Utility Federal / Facility Manager

5

NICK BONARD National Capital Planning Commission

Stormwater Perspectives

BRIAN VAN WYE District Department of Energy and Environment RUSSELL CLARK General Services Administration BETHANY BEZAK DC Water

City / Stormwater Utility Water and Sewer Utility Federal / Facility Manager Moderator

6

Washington, DC

Source: Opening Reception for Rights of Ways: Mobility and the City exhibition, Dec. 5, 2013. Photo by June Lee.

METRO POPULATION 6,097,000 (2015) CITY POPULATION 672,000 (2015)

7

The Potomac River Watershed

Source: Wikipedia user Kmussert

8

Land Use

9

Downtown Core

10

Emerging Neighborhoods

Source: Flickr User Claire Uziel Source: Flickr User Ted Eytan

11

Historic Districts

Source: Flickr User John M Source: Flickr User Garber DC

12

Residential

Source: Gpogle Maps

13

Federal

14

DC’s Stormwater Challenges

• 1. Combined Sewer System
• 2. Urbanization and Stormwater Capacity Issues
• 3. Increased Heavy Rain Storms in the Future

15

Combined Sewer System

CSS MS4 MS4 MS4

Combined Sewer er ( (CSS) Sepa parat ate S e Sewer er ( (MS MS4)

Source: Civil Engineers PK

16

Urbanization

17

Precipitation Increases

Source: DC Climate Adaptation Plan

18

Brian Van Wye

1

Scaling Green Infrastructure in Washington, DC

DOEE Voluntary GI Programs

• Public projects:

 Transportation right-of-way  Public buildings and parking lots

• Subsidies for Private Sector

 RiverSmart Homes  RiverSmart Roofs  RiverSmart Communities  RiverSmart Schools

• RiverSmart Rewards Discounts
• Challenges

 Maintenance  Siting GI in area not slated for redevelopment  Paying all or most of cost up front  Minimal incentive for partners to identify least-cost projects  SCALE

3

Regulations Key to MS4 Stormwater Solution

CSS MS4 MS4 MS4

• Municipal Separate Storm

Sewer System

 $7B+ GI build-out  $10 Mil/yr for GI  GI stormwater regulations

can achieve 10x the GI retrofits of voluntary programs

4

Flexibility for Regulated Development

CSS MS4 MS4 MS4

5 CSS MS4 MS4 MS4

• 43% of the District’s

land is impervious.

Flexibility for Regulated Development

6 CSS MS4 MS4 MS4

• 43% of the District’s

land is impervious.

Flexibility for Regulated Development

7

Optimizing Environmental Outcomes

CSS MS4 MS4 MS4

8 CSS MS4 MS4 MS4

• GI located in MS4 is
• More beneficial for

waterbodies

• Less expensive
• Provides greater

environmental justice outcomes.

• GI size/capacity can

be optimized

Optimizing Environmental Outcomes

• Regulated site free to go off site

after achieving 50% of required retention on site.

Stormwater Retention Credit Trading

1.2” retention required = 10,000 gal. On-site minimum = 5,000 gal. Impervious surface = 14,000 sf

• Off-site volume is ongoing annual obligation.
• Two options to achieve Offv:
• In-lieu fee (ILF) payment to DOEE = $3.61/gallon/year.
• Privately tradable SRCs. 1 SRC/gallon/year.

Potential 10-Year Financial Return on Retention BMP - SRC Revenue and Discount on Impervious Fees Assuming installation of BMP to retain 1.7" of stormwater from 1000 square feet of impervious area Rate 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 10-Year Total Max Discount – DC Water IAC 4% $5 $6 $8 $10 $11 $12 $13 $14 $15 $15 $107 Max Discount – SW Fee 55% $18 $18 $26 $26 $26 $26 $33 $33 $33 $33 $273 Projected Value of SRCs (inflation-adjusted at 3.5%/year) $1.85 $1,863 $1,928 $1,996 $2,065 $2,138 $2,213 $2,290 $2,370 $2,453 $2,539 $21,855 Total $1,886 $1,952 $2,030 $2,101 $2,175 $2,251 $2,336 $2,417 $2,501 $2,587 $22,235

Properties may receive discounts for retention up to the 1.2” storm and SRCs for retention up to the 1.7” storm.

Potential Financial Return

DOEE SRC Purchase Program

• Pay for performance option contract.
• 1 SRC = 1 gallon of installed GI retention capacity.
• DOEE pays for 3 years at a time.
• SRC generator has option to sell to DOEE per contract terms.
• Price floor provides certainty to private investors and SRC

generators.

• Engage private capital – e.g. $1.7M investment from Prudential.
• Incentivize GI retrofits in priority locations of MS4.
• Initial $11.5M investment to scale up if successful.

Leveraging private capital via DOEE SRC Purchase Program

$$

SRC Aggregator

SRCs SRCs

$$

GI Retrofit

$$

SRCs

$$

$$ Discount

• n SW

Fee

$$

Benefits for District of SRC Purchase Program

• Risk of maintenance failure not born by DOEE.
• Risk of selecting site that will trigger regs not born by DOEE.
• Incentive to find least-cost opportunities on public & private land.
• Savings for ratepayers compared to DOEE building GI itself.
• SRCs as regulatory currency facilitates scaling up and down.

0% 20% 40% 60% 80% 100% 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49

Projection of DC MS4 Impervious Area Retrofitted

Regs GI Retrofits

Benefits for District of SRC Purchase Program

0% 20% 40% 60% 80% 100% 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49

Projection of DC MS4 Impervious Area Retrofitted

Regs GI Retrofits CSS-Purchased SRCs

• Risk of maintenance failure not born by DOEE.
• Risk of selecting site that will trigger regs not born by DOEE.
• Incentive to find least-cost opportunities on public & private land.
• Savings for ratepayers compared to DOEE building GI itself.
• SRCs as regulatory currency facilitates scaling up and down.

Benefits for District of SRC Purchase Program

0% 20% 40% 60% 80% 100% 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49

Projection of DC MS4 Impervious Area Retrofitted

Regs GI Retrofits CSS-Purchased SRCs DOEE SRC Purchases

• Risk of maintenance failure not born by DOEE.
• Risk of selecting site that will trigger regs not born by DOEE.
• Incentive to find least-cost opportunities on public & private land.
• Savings for ratepayers compared to DOEE building GI itself.
• SRCs as regulatory currency facilitates scaling up and down.

SRC Market Data

• SRC trades
• 12 trades overall
• 68,900 SRCs purchased
• $139,525 in sales
• 8 trades in 2016 at average $1.85/SRC
• Demand
• Approximately 12% of regulated sites (42 projects) have
• pted to meet some of their retention obligation off-site
• 14 have completed construction or are approaching their

final inspection

• Approximately 307,000 gallons of annual demand
• 77% of SRCs used were generated in MS4 and used in CSS.
• 12% of SRCs used were generated in MS4 and used in MS4.
• 11% of SRCs used were generated in CSS and used in CSS.

17

For More Information

Brian Van Wye

Brian.VanWye@dc.gov; 202-741-2121 SRC trading - green.dc.gov/src RiverSmart Rewards discount - green.dc.gov/riversmartrewards Stormwater management regulations - green.dc.gov/swregs
