Ericsson Internal | 2018-03-12

5G Market Potential and Status Update

Painel Telebrasil 2018 IEEE 5G Summit

Tiago Machado Ericsson Brazil 2018-05-22

Ericsson Internal | 2018-03-12

The Generations: from Voice to IoT

Ericsson Internal | 2018-03-12

New revenue streams from 5G

Ericsson Internal | 2018-03-12

New revenue streams from 5G

Ericsson Internal | 2018-03-12

5G evolution goes beyond Radio Access

Ericsson Internal | 2018-03-12

5G high level time plan

5G in Brazil

Ericsson Internal | 2018-03-12

Braziliancities

Motivationfor Rural Coverage

(2017) Brasil Centro Oeste Nordeste Norte Sudeste Sul Cities 5.570 8,38% 32,21% 8,08% 29,95% 21,38% Demographic Density 24,4 hab/km² 9,88 hab/km² 36,84 hab/km² 4,65 hab/km² 94,04 hab/km² 52,58 hab/km²

Populational density inhabitants/Km2 [2017] IBGE and EMPRAPA

Ericsson Internal | 2018-03-12

5G RANGE

Overview

5G-RANGE – 5G-Remote Area Access Network for 5Th GEneration

EU-Brazil Joint Call - H2020-EUB-2017

List of Participants

EU Partners

Universidad Carlos III de Madrid (Spain) - Coordinator Technische Universität Dresden (Germany) University of Oulu (Finland) Telefónica I+D (Spain)

Brazilian Partners

Inatel (Instituto Nacional de Telecomunicações) CPqD (Centro de Pesquisa e Desenvolvimento em Telecomunicações) USP (Universidade de São Paulo) UFC (Universidade Federal do Ceará) UnB (Universidade de Brasília) - Coordinator Ericsson Brazil

Ericsson Internal | 2018-03-12

5G RANGE

Overview

— Context

— Limited availability of Internet Broadband access in remote areas — Demand not met with current technologies and products

— Low population density — Geographical barriers — Large distances — Usage of licensed bands

— Objectives

— Design, develop, implement and validate the mechanisms to enable the 5G network to provide an economically effective solution for Internet access for remote areas:

— Use of cognitive radio approach employing both licensed and unlicensed frequencies — New waveform in order to provide the desirable dynamic and fragmented spectrum allocation. — Cell radius above 50 km (>100Mbps at the edge)

— Novel contributions on 5G standards in support of global industry consensus e.g. through submission of joint contributions in these fora by EU and Brazilian players

— Internet Penetration

80% 10%

Ericsson Internal | 2018-03-12

High CapacityTransport

2016 Cities without Optical Backhaul Midwest 181 Northeast 1.095 North 250 Southeast 651 South 168

In blue: cities with Optical Backhaul In blank: cities without Optical Backhaul

Optical backhaul [2016] ANATEL

Ericsson Internal | 2018-03-12

Infrastructureanddigitalizationare keyenablers

Spectrum Availability Spectrum Caps Spectrum Pricing Site Viability

— Infrastructure enablers

Ericsson Internal | 2018-03-12

Infrastructureanddigitalizationare keyenablers

Spectrum Availability Spectrum Caps Spectrum Pricing Site Viability

— Infrastructure enablers

Network Neutrality Data Privacy Cyber security Industrial Policy

— Digitalization enablers

Ericsson Internal | 2018-03-12

Spectrum for 5G introduction

Ericsson Internal | 2017-12-19

Three layers of spectrum are needed: Low, Mid, High

High Bands 6GHz Mid Bands 1-6GHz Low Bands < 1GHz

Super data layer Coverage & Capacity Coverage Layer

Ericsson Internal | 2017-12-19

POTENTIAL Available bandwidth in 600MHz in Brazil

100

MHz

APPLICATIONS

FWA eMBB Rural IoT

BASE

Potential reuse

• f existing

infrastructure Rural coverage Global Roaming

Lower bands enable coverage

Logistics

High Bands 6GHz Mid Bands 1-6GHz Low Bands < 1GHz

Super data layer Coverage & Capacity Coverage Layer

Ericsson Internal | 2017-12-19

POTENTIAL Available bandwidth in 2.3 + 3.5GHz in Brazil, considering LSA in C-Band

500

MHz

APPLICATIONS

IoT eMBB Industry 4.0 Smart Cities

BASE

Potential reuse

• f existing

infrastructure Urban coverage Global Roaming

Mid-bands have the balance of Coverage x Capacity

High Bands 6GHz Mid Bands 1-6GHz Low Bands < 1GHz

Super data layer Coverage & Capacity Coverage Layer

Ericsson Internal | 2017-12-19

POTENTIAL Available bandwidth in millimeter Waves above 24GHz up to E-Band in Brazil

>10

GHz

APPLICATIONS

Self Driving Cars Remote Medicine Robots VR/AR

BASE

Indoor, urban, private, local, short range, multi-layer Global Roaming

mmWavewill add 10x more capacity

High Bands 6GHz Mid Bands 1-6GHz Low Bands < 1GHz

Super data layer Coverage & Capacity Coverage Layer

Ericsson Internal | 2017-12-19

3.5GHz isavailableworldwide: theprime 5G band

100MHz or less 200MHz 300MHz 400MHz

Ericsson Internal | 2017-12-19

Millimetric bands under study at ITU WRC-19

From 24.25 to 86GHz, a total of 33GHz is targeted

24.25 27.5 31.8 33.4 37 40.5 42.5 45.5 66.0 76.0 81.0 86.0 52.6 50.4 43.5 50.2 47 47.2

allocations to the mobile service on a primary basis may require additional allocations to mobile

Ericsson Internal | 2017-12-19

Millimetric bands under study at ITU WRC-19

From 24.25 to 86GHz, a total of 33GHz is targeted

24.25 27.5 31.8 33.4 37 40.5 42.5 45.5 66.0 76.0 81.0 86.0 52.6 50.4 43.5 50.2 47 47.2

allocations to the mobile service on a primary basis may require additional allocations to mobile

1

24GHz

24.25-27.5

Global Priorities

Ericsson Internal | 2017-12-19

Millimetric bands under study at ITU WRC-19

From 24.25 to 86GHz, a total of 33GHz is targeted

24.25 27.5 31.8 33.4 37 40.5 42.5 45.5 66.0 76.0 81.0 86.0 52.6 50.4 43.5 50.2 47 47.2

allocations to the mobile service on a primary basis may require additional allocations to mobile

2 42GHz

40.5-43.5

1

24GHz

24.25-27.5

Global Priorities

Ericsson Internal | 2017-12-19

Millimetric bands under study at ITU WRC-19

From 24.25 to 86GHz, a total of 33GHz is targeted

24.25 27.5 31.8 33.4 37 40.5 42.5 45.5 66.0 76.0 81.0 86.0 52.6 50.4 43.5 50.2 47 47.2

allocations to the mobile service on a primary basis may require additional allocations to mobile

2 42GHz

40.5-43.5

3

70GHz

66-76

1

24GHz

24.25-27.5

Global Priorities

Ericsson Internal | 2017-12-19

Millimetric bands under study at ITU WRC-19

From 24.25 to 86GHz, a total of 33GHz is targeted

24.25 27.5 31.8 33.4 37 40.5 42.5 45.5 66.0 76.0 81.0 86.0 52.6 50.4 43.5 50.2 47 47.2

allocations to the mobile service on a primary basis may require additional allocations to mobile

2 42GHz

40.5-43.5

3

70GHz

66-76

4 48GHz

45.5-52.6

1

24GHz

24.25-27.5

Global Priorities

Ericsson Internal | 2017-12-19

Millimetric bands under study at ITU WRC-19

From 24.25 to 86GHz, a total of 33GHz is targeted

24.25 27.5 31.8 33.4 37 40.5 42.5 45.5 66.0 76.0 81.0 86.0 52.6 50.4 43.5 50.2 47 47.2

allocations to the mobile service on a primary basis may require additional allocations to mobile

2 42GHz

40.5-43.5

3

70GHz

66-76

5 32GHz

31.8-33.4

4 48GHz

45.5-52.6

1

24GHz

24.25-27.5

Global Priorities

Ericsson Internal | 2017-12-19

Millimetric bands under study at ITU WRC-19

From 24.25 to 86GHz, a total of 33GHz is targeted

24.25 27.5 31.8 33.4 37 40.5 42.5 45.5 66.0 76.0 81.0 86.0 52.6 50.4 43.5 50.2 47 47.2

allocations to the mobile service on a primary basis may require additional allocations to mobile

2 42GHz

40.5-43.5

3

70GHz

66-76

5 32GHz

31.8-33.4

4 48GHz

45.5-52.6

6

85GHz

81-86

1

24GHz

24.25-27.5

Global Priorities

Ericsson Internal | 2017-12-19

Ongoing draft laws in Brazil — PLS 330 / 2013 — PL 5276 / 2016 Main topics — Data protection authority — Personal data — Sensitive data — Anonymized data — International Data Flows — Consent: explicit vs implicit — Identifiable vs identified user US approach — Focus on private contracts — Broader trade and competition regulation — Implicit consent — Open data flows EU approach: GDPR — Focus on user protection — Data protection authority — Explicit consent — Limited non-EU data flows — EU Digital Single Market

Digitalization Enablers: Why data privacy matters

Ericsson Internal | 2017-12-19

Digitalization Enablers: Why net neutrality matters

Network Neutrality — Science of limited resources — From homogeneity to network slicing — FCC stance versus Europe — Latency over throughput — The myth of fast lanes US movement vs EU instance Brazilian Internet Civil Framework & Decree

Definition

• f Net

Neutrality

User demand Business Opportunity Tech evolution 5G & IoT Market Equilibrium Basic Rights and Rules

Ericsson Internal | 2017-12-19

Key topics — Data localization — Critical Infrastructure — Cyber-espionage — Legal Interception — Vendor and technology vetting — Security by design — IoT and 5G introduction

Digitalization Enablers: Why cyber security matters

Network Security Information Security Local Systems Cloud IT Specific Industry-wide Data exposure Data Corruption Computers & Phones IoT Networks Access Ubiquity Preventive & Reactive Proactive measures

Ericsson Internal | 2018-03-12

Public policies for Cybersecurity, Net Neutrality and Data Privacy will be key enablers or roadblocks for 5G introduction . mmWave should be prioritized, especially 26GHz and 42GHz, to enable high-demand use cases including IoT.

Key stepsfor 5G

Early 5G introduction will be viable in 3.5GHz to cope with data growth in urban areas, while benefiting from global ecosystem.
