Status of perfSONAR Development in TWAREN

10/02/2010

Che-nan Yang TWAREN

Outlines

• Deployment Services

– Lookup Services – SNMPMA – BUOY

• perfSONAR Development

– We develop an alarm correlation system on perfSONAR framework.

• TL1 MP
• SNMPLite MP
• Correlation MP

– VQM MP

• Future Work

Deployment Services in Taiwan

• Lookup Service

–

Home Lookup Service(hLS)

–

perfSONAR Information Service Tree

• https://dc211.internet2.edu/cgi-bin/perfAdmin/tree.cgi
• SNMPMA
• SNMPMA

–

perfSONAR Global Service and Data View

• http://dc211.internet2.edu/cgi-

bin/perfSONAR/serviceTest.cgi?url=http://ma.perfsonar.twaren.net:9997/per fSONAR_PS/services/SNMPMA&eventType=http://ggf.org/ns/nmwg/charact eristic/utilization/2.0

• perfSONAR-PS BUOY
• Psping

−

cpan perfSONAR_PS::Client::Echo

− psping http://211.79.63.72:8080/perfSONAR_PS/services/pSB

Measurement Tools

TOOL Description Iperf Throughput Measurement BWCTL Wrapper tool for Iperf RRDTool-Cacti Database which store traffic data OWAMP One-way delay measurement

TWAREN -Devices

• LA: 622M *3 (LA-7606)

–

Gi4/1 ifindex : 25

–

Gi4/2 ifindex : 26

–

Gi4/7 ifindex : 31

• CHI 622M*4 (CHI-7606)

–

Gi4/2 ifindex : 2

–

Gi4/2 ifindex : 2

–

Gi4/4 ifindex : 4

–

Gi4/6 ifindex : 6

–

Gi4/9 ifindex : 9

psUI-TWAREN Link Utilization Monitoring

SNMP MA - Link Utilization Monitoring

Alarm Correlation in Hybrid Networks

Measurement Point Services

• TL1 MP

–

Provide to execute the TL1 commands on ONS equipments.

• SNMPLite MP

–

Get the status of specific router equipments.

• Correlation MP
• Correlation MP

–

Implement the alarm correlation algorithm that we proposed to simplifies root-cause analysis.

TL1 MP

Response Request Response

SNMPLite MP

Request Response

Integrate into the perfSONARUI

System Architecture of ps-VQM

ps-VQM UI VQM Tool VQM MP

SOAP XML

10/02/2010

ps-VQM Test Infrastructure

packet loss vs MOS

2.5 2.75 3 3.25 3.5 3.75 4 4.25 4.5

(PCMU)

1.7 3.4 5.1 6.8 8.5 10.2 11.9 13.6 15.3 17 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5

packet loss rate (%) MOS value (P

Tool Version

• perfSONAR CLMP

– Version : perfsonar-clmp_2.1-1

• Tomcat

– Version : 5.5 – Version : 5.5

• Voice Quality Measurement(VQM)

10/02/2010

Tested with example XML requests

<nmwg:message type="MeasurementRequest” id="msg1" xmlns:nmwg="http://ggf.org/ns/nmwg/base/2.0/" xmlns:nmwgt="http://ggf.org/ns/nmwg/topology/2.0/"> <nmwg:metadata id="probeVQM"> <nmwg:subject id="sub1"> <nmwgt:endPointPair> <nmwgt:endPointPair> <nmwgt:dst type="ipv4" value="www.perfsonar.net"/> </nmwgt:endPointPair> </nmwg:subject> <nmwg:eventType>http://ggf.org/ns/nmwg/tools/VQM/2.0</nmwg:eventType> <nmwg:parameters id="param1"> <nmwg:parameter name="Receiver">[REC_IP]</nmwg:parameter> </nmwg:parameters> </nmwg:metadata> <nmwg:data id="1" metadataIdRef="probeVQM" /> </nmwg:message>

10/02/2010

Results

• Codec
• PacketLossRate
• Bandwidth
• Delay (ms)
• Delay (ms)
• Jitter (ms)
• MOS

– 5-point scale: Bad、poor、fair、good、excellent.

10/02/2010

Future Development

• We are going to install perfSONAR-BUOY on all TWAREN GigaPOPs.
• We are going to integrate this alarm correlation system with our production

environment.

• Based on perfSONAR framework, we will continue to develop management system

for SDH or DWDM equipments.

Acknowledgement

• The useful resources for development.

–

perfSONAR Developer’s Wiki

–

perfSONAR Mailing List

• We also give thanks for Ikeda-san to help us to test the perfSONAR-VQM between

Taiwan and Japan.
