perfSONAR deployment update and use case

Takatoshi Ikeda

APAN-JP, NICT, KDDI R&E Labs tk-ikeda’at’kddilabs.jp

Agenda

• perfSONAR deployment in Japan
• Use Case
• Proposal for use in APAN community

2 perfSONAR Workshop, 29th APAN Meeting, Sydney

pe perfSONAR de depl ploy

• yment in Japa

pan

perfSONAR Workshop, 29th APAN Meeting, Sydney 3

Deployment MAP

4 perfSONAR Workshop, 29th APAN Meeting, Sydney

Tokyo *2 Kashima Tokyo Osaka Fukuoka Fukuoka

Deployment Services

gLS hLS SNMP MA PS-BUOY(BWCTL) PS-BUOY(OWAMP) L2 Status

Package and Service

• perfSONAR-PS V3.1

– Developed entirely in the Perl – Packages are available on Internet2 repository and managed by tools such as Yum or APT-RPM

5 perfSONAR Workshop, 29th APAN Meeting, Sydney

perfSONAR-PS Packages PS Services Description Lookup Service LS Lookup Service LS Registration LS Register measurement services with Lookup Service Topology Service TopS Topology Service SNMP MA MA Expose RRD data collected by SNMP protocol perfSONAR BUOY MA A regular testing of throughput and delay with BWCTL and OWAMP. It expose these measurement data. Status MA Make available the status of network elements. ( port status, etc..) PingER MA & MP PingER service

Package and Service (Cont.)

• Deployment status

6 perfSONAR Workshop, 29th APAN Meeting, Sydney

perfSONAR-PS Packages PS Services Deployment Status APAN JGN2plus Lookup Service LS Global LS, Home LS Home LS LS Registration LS

• Topology Service

TopS Coming soon Coming soon SNMP MA MA Hi-resolution interface usage of core network devices Hi-resolution interface usage of core network devices perfSONAR BUOY MA regular measurement results with some international partners regular measurement results among .domestic nodes . Status MA Trial Use Trial Use PingER MA & MP

• In Operation

Data View

• Global Data View

– http://dc211.internet2.edu/cgi-bin/perfSONAR/serviceList.cgi

• APAN

– Lookup Service – Interface Usage – Throughput – Delay

• JGN2plus

– Lookup Service – Interface Usage

• JP East, US, SG, TH
• JP West, KR

– Throughput – Delay

7 perfSONAR Workshop, 29th APAN Meeting, Sydney

Deployment in APAN members

8 perfSONAR Workshop, 29th APAN Meeting, Sydney

NECTEC, TH VINAREN, VN TAWAREN, TW KOREN, KR

Use Use case se of f perfS fSONA NAR

perfSONAR Workshop, 29th APAN Meeting, Sydney 9

Traffic Weather MAP for SC09

• Aim

– Monitor the link usage of the several networks between Japan and the SC venue effectively. – Identify the bottleneck and traffic conflict quickly and easily.

• Tool Behavior

– The weather map software collects the data from perfSONAR service (SNMP MA) – The data is described in NMWG XML format – The software makes traffic weather Map

• Network

– Main L3 path between Japan and the venue

• Japan: JGN2plus - APAN-JP
• U.S. : TransPAC2 - Internet2 - SC09 Venue
• MAP Type

– PNG – Google MAP

10 perfSONAR Workshop, 29th APAN Meeting, Sydney

Use Case 1

Usage Data(RRD)

SNMAP MA

Traffic Weather MAP （PNG)

11 perfSONAR Workshop, 29th APAN Meeting, Sydney

Use Case 1

Traffic Weather MAP （Google Maps)

12 perfSONAR Workshop, 29th APAN Meeting, Sydney

Use Case 1

Traffic Weather MAP （Google Maps)

• APAN-JP

– http://ps1.jp.apan.net/ps-gmaps/

• JGN2plus

– http://kote-ps-1.ps.jgn2plus.jp/ps/ps- gmaps/index.html

13 perfSONAR Workshop, 29th APAN Meeting, Sydney

Use Case 1

perfSONAR-based Integrated Network Management Platform

• Overview

– Network measurement system

• Monitor and analyze the network data of multiple metrics, points and time

measured by multiple measurement and estimation method

• Manage the data with appropriate resolution
• Provide the data with perfSONAR protocol
• Visualize the data for the operators and researchers.

– Developed by Kyushu Institute of Technology as JGN2plus research project

• Feature

– Collect and Analyze

• Collects the data measured by several measurement tools and store it to

database.

• Analyze from multiple measurement data by using network tomography and

such technology and store it to database.

– Provide the data

• Provide the measurement and analyzed data as perfSONAR MA service

– Visualize

• Visualize the measurement and analyzed data on the web

14 perfSONAR Workshop, 29th APAN Meeting, Sydney

Use Case 2

Architecture Overview

15 perfSONAR Workshop, 29th APAN Meeting, Sydney

Use Case 2

Snapshot of the System Web Interface

16 perfSONAR Workshop, 29th APAN Meeting, Sydney

Use Case 2

Proposal for using perfSONAR in APAN community

perfSONAR Workshop, 29th APAN Meeting, Sydney 17

APAN Network and Application

• APAN Network

– Consist of multi-domain networks with interconnection

• APAN Member: 18 economics, 27 networks

– Each NOC operates the network with each policy – The big gap exists on the bandwidth of the link

• 10Gbps（optical) ～ several Mbps （satellite）
• APAN Application

– Communication over multi-domain networks

• Telemedicine, e-learning, eVLBI, HDTV, LiveE, Earth

Monitoring

– Require better performance

18 perfSONAR Workshop, 29th APAN Meeting, Sydney

APAN Network Operational Issue (1/2)

• Issues

It takes much operator’s energy and time when End-to-End performance problems occur in APAN network

• Identify the degradation point not only own network

but also other networks

• Arrange the iperf server with other NOC each time
• Compare measurement data such as link usage among

different format.

19 perfSONAR Workshop, 29th APAN Meeting, Sydney

APAN Network Operational Issue (2/2)

20 perfSONAR Workshop, 29th APAN Meeting, Sydney

perfSONAR for APAN community

• Goal

– Resolve the APAN operational issues

• Reduce the operator’s energy and shorten the time for

investigation

– Provide the best performance to the APAN community

• Measuring and monitoring the network performance
• Proposal

1. Throughput Measurement

• Established throughput measurement environment

2. Link Usage

• Monitoring APAN international links

21 perfSONAR Workshop, 29th APAN Meeting, Sydney

Throughput measurement

• Proposal to

– The network which support telemedicine – AU, CN, IN, HK, ID, JP, KR, MY, NZ, PH, SG, TEIN3, TH, TW, VN

• What we can do

– Each NOC is able to measure the throughput performance over the APAN network, when their user inquire about the performance problems.

• Requirement

– Put 1 perfSONAR PC in your network

22 perfSONAR Workshop, 29th APAN Meeting, Sydney

Proposal 1 * Blue means already deployed or have a plan

Throughput measurement (image)

23 perfSONAR Workshop, 29th APAN Meeting, Sydney

NW1 NW2 NW3

H/W: PC Server （recent laptop would be OK） S/W： CentOS + iperf/BWCTL + perfSONAR BUOY

• r

pS-Performance Toolkit (Bootable CD) Performance problem measurement User User NW3’s NOC Required Component

inquiry Request for the measurement

Link Usage

• Proposal to

– All APAN member

• What we can do

– Each NOC is able to check the link usage of the APAN network – Available to Only NOC or User as well

• Requirement

– Put 1 perfSONAR PC in your network – SNMP access to the gateway router from perfSONAR server

24 perfSONAR Workshop, 29th APAN Meeting, Sydney

Proposal 2

Link Usage (image)

25 perfSONAR Workshop, 29th APAN Meeting, Sydney

NW1 NW2 NW3

Performance problem User User NOC

retrieve the data

H/W: PC Server （recent laptop would be OK） S/W： CentOS + SNMP MA

• r

pS-Performance Toolkit (Bootable CD) Required Component

View

SNMP Proposal 2

How to install

• perfSONAR-PS packages

– Step by step instruction of perfSONAR-PS v3.1 is available – Released v2.1

• Include installation of perfSONAR BUOY

– http://www.jp.apan.net/noc/perfSONAR/

• Easy registration is required
• pS-Performance Toolkit

– QuickStart wiki for a complete set of instructions regarding installation and configuration. – http://code.google.com/p/perfsonar- ps/wiki/pSPerformanceToolkit31

26 perfSONAR Workshop, 29th APAN Meeting, Sydney

Thank you !
