STAR CLUSTERS Lecture 1 Introduction Nora Ltzgendorf (ESA) I ts a school, so ? ? ? ? ? ? ? ? ? ASK QUESTIONS!!! If you dont understand the content If you dont understand the language TAKE NOTES This

slide-1
SLIDE 1

STAR CLUSTERS Lecture 1 Introduction

Nora Lützgendorf (ESA)

slide-2
SLIDE 2

Nora Lützgendorf, KAS16 / 49

➡ ASK QUESTIONS!!!

2

Its a school, so…

? ?

? ? ?

? ? ? ?

➡ If you don’t understand the content… ➡ If you don’t understand the language…

➡ TAKE NOTES

➡ This is the most text on a slide you will see ;)

slide-3
SLIDE 3

Nora Lützgendorf, KAS16 / 49

1.Career 2.Introduction

  • a. What is a star cluster?
  • b. What kind of clusters do we know?
  • c. Where do we find them?
  • d. Characteristics

3

Outline

slide-4
SLIDE 4

Nora Lützgendorf, KAS16 / 49

1.Career 2.Introduction

  • a. What is a star cluster?
  • b. What kind of clusters do we know?
  • c. Where do we find them?
  • d. Characteristics

4

Outline

slide-5
SLIDE 5

/ 49 Nora Lützgendorf, KAS16

Current Position

5

JWST/NIRSpec Instrument and Calibration Scientist

slide-6
SLIDE 6

/ 49 Nora Lützgendorf, KAS16 6

European Space Agency

technology telecom m unications hum an spaceflight earth observation launchers navigation

  • perations

space science exploration

slide-7
SLIDE 7

/ 49 Nora Lützgendorf, KAS16

James Webb Space Telescope

7

FACTS

WHAT: Infrared space telescope WHERE: Lagrange Point 2 WHEN: October 2018 MIRROR: 6.5 m

slide-8
SLIDE 8

/ 49 Nora Lützgendorf, KAS16

James Webb Space Telescope

8

slide-9
SLIDE 9

/ 49 Nora Lützgendorf, KAS16

James Webb Space Telescope

8

slide-10
SLIDE 10

/ 49 Nora Lützgendorf, KAS16

Current Position

9

LAUNCH SEGMENT OBSERVATORY SEGMENT GROUND SEGMENT

Payload adapter Launcher (Ariane 5) Launch site services Science and operation center (STScI) 15 ESA staff members Common systems (deep space network) Provided by NASA Provided by ESA Provided by CSA Spacecraft (bus, sunshield…) Telescope Payload module (ISIM) and instruments NIRCam NIRSpec FGS/NIRISS MIRI

slide-11
SLIDE 11

/ 49 Nora Lützgendorf, KAS16

NIRSpec

10

Fixed Slit Spectroscopy Multi Object Spectroscopy Integral Field Spectroscopy

slide-12
SLIDE 12

/ 49 Nora Lützgendorf, KAS16

Tasks

11

BEFORE LAUNCH (2018)

  • 80% duties, 20% science
  • assist in calibration campaigns

(like Cryo Vacuum Tests at NASA)

  • reduce and analyze data from these

campaigns

  • create calibration files for the instruments (flat-

fields, darks, …)

  • assist in GTO observation preparations

AFTER LAUNCH

  • 50% duties, 50% science
  • commissioning (final calibration and science

verification of the instrument)

  • user support (help astronomers to observe

with the instrument)

  • calibration monitoring (degrading of

hardware, change in instrument…)

  • …

Making sure the instrument is usable for doing Astronomy Making sure astronomers use the instrument most efficiently

slide-13
SLIDE 13

/ 49 Nora Lützgendorf, KAS16 12

How did I get here?

MUNICH, D (2005-2013)

2005 - 2010: Diplom (Physics), LMU 2010 - 2013: PhD (Astrophysics), LMU/ESO

LEIDEN, NL (2013-2015)

2013 – 2015: Research Fellow, ESA

LEIPZIG, D (1985-2004)

1996 – 2004: High-School

BALTIMORE, US (since 2015)

since 2015: JWST Instrument Scientist, ESA

Nora Lützgendorf, KAS16 / 49

slide-14
SLIDE 14

Nora Lützgendorf, KAS16 / 49

1.Career 2.Introduction

  • a. What is a star cluster?
  • b. What kind of clusters do we know?
  • c. Where do we find them?
  • d. Characteristics

13

Outline

slide-15
SLIDE 15

/ 49 Nora Lützgendorf, KAS16

“The Milky Way is nothing else but a mass of innumerable stars planted together in clusters”

14

Introduction

  • Galileo Galilei (1610)
slide-16
SLIDE 16

/ 49 Nora Lützgendorf, KAS16 15

Introduction

  • Lada & Lada (2003)

“Most stars form in clusters”

slide-17
SLIDE 17

/ 49 Nora Lützgendorf, KAS16 16

Star Cluster

Collection of stars roughly born at the same time Collection of stars that are gravitationally bound

slide-18
SLIDE 18

/ 49 Nora Lützgendorf, KAS16 17

Excursion: Color-magnitude diagram

L/M L/MV T/(V-I)

HOT COLD

slide-19
SLIDE 19

/ 49 Nora Lützgendorf, KAS16 18

Color-magnitude diagram

Video can be found here: http://hubblesite.org/newscenter/archive/releases/2010/28

slide-20
SLIDE 20

/ 49 Nora Lützgendorf, KAS16 19

L/M L/MV T/(V-I)

HOT COLD

1) Main Sequence Star

H+He

2) Red Giant

He H+He

4) Asymptotic Giant

C+O He H+He

3) Horizontal Branch Star

H+He He

5) White Dwarf

C+O

Excursion: Color-magnitude diagram

slide-21
SLIDE 21

/ 49 Nora Lützgendorf, KAS16 20

Marcia Rieke

Excursion: Color-magnitude diagram

slide-22
SLIDE 22

/ 49 Nora Lützgendorf, KAS16 20

Marcia Rieke

Excursion: Color-magnitude diagram

slide-23
SLIDE 23

/ 49 Nora Lützgendorf, KAS16 20

Marcia Rieke

Excursion: Color-magnitude diagram

slide-24
SLIDE 24

/ 49 Nora Lützgendorf, KAS16 20

Marcia Rieke

Excursion: Color-magnitude diagram

slide-25
SLIDE 25

/ 49 Nora Lützgendorf, KAS16 20

Marcia Rieke

Excursion: Color-magnitude diagram

slide-26
SLIDE 26

/ 49 Nora Lützgendorf, KAS16 21

Types of clusters

100 -1000 1e5-1e7 1e6-1e8 1e4-1e5 1e4-1e6 OB Associations Embedded Clusters Open Clusters Globular Clusters Nuclear Clusters

N stars

slide-27
SLIDE 27

/ 49 Nora Lützgendorf, KAS16 22

Environment

OB Associations Embedded Clusters Open Clusters Globular Clusters Nuclear Clusters

slide-28
SLIDE 28

/ 49 Nora Lützgendorf, KAS16 23

Types of clusters

100 -1000 1e5-1e7 1e6-1e8 1e4-1e5 1e4-1e6 OB Association Embedded Clusters Open Clusters Globular Clusters Nuclear Clusters

N stars

slide-29
SLIDE 29

/ 49 Nora Lützgendorf, KAS16 24

OB Associations

  • 20 - 500 pc
  • 0.1 stars/pc
  • gravitationally unbound
  • 12 within 650 pc

70 pc 300 pc SMC - NGC 346 M33 - NGC 604

slide-30
SLIDE 30

/ 49 Nora Lützgendorf, KAS16 25

Star Cluster

Collection of stars roughly born at the same time Collection of stars that are gravitationally bound

slide-31
SLIDE 31

/ 49 Nora Lützgendorf, KAS16 26

Types of clusters

100 -1000 1e5-1e7 1e6-1e8 1e4-1e5 1e4-1e6 OB Associations Embedded Clusters Open Clusters Globular Clusters Nuclear Clusters

N stars

slide-32
SLIDE 32

/ 49 Nora Lützgendorf, KAS16 27

Embedded clusters

  • 1 - 10 pc
  • 100 - 1000 stars/pc3
  • age < 5 Myr
  • may or may not be bound
  • still gas in / around the cluster

➡ High extinction

1 1 2 3 4 H-K 1 1 2 3 4 J-H

slide-33
SLIDE 33

/ 43 Nora Lützgendorf, KAS16 28

Embedded clusters

Nora Lützgendorf, KAS16 / 49

Video can be found here: https://www.youtube.com/watch?v=JcqlTOrijtk

slide-34
SLIDE 34

/ 49 Nora Lützgendorf, KAS16 29

Types of clusters

100 -1000 1e5-1e7 1e6-1e8 1e4-1e5 1e4-1e6 OB Associations Embedded Clusters Open Clusters Globular Clusters Nuclear Clusters

N stars

slide-35
SLIDE 35

/ 49 Nora Lützgendorf, KAS16 30

Open clusters

  • core radii ~ 2pc
  • mass ~ 100 - 1000 MSUN
  • age: between 3 Myr and a few Gyr
  • no gas left
  • gravitationally bound

NGC 3603 Arches NGC 3766 NGC 4755

slide-36
SLIDE 36

/ 49 Nora Lützgendorf, KAS16 31

Open clusters - Observations

  • ~ 2000 identified

➡ 1e5 within the Galaxy! (extinction)

Globular Clusters Open Clusters

slide-37
SLIDE 37

/ 49 Nora Lützgendorf, KAS16 32

Types of clusters

100 -1000 1e5-1e7 1e6-1e8 1e4-1e5 1e4-1e6 OB Associations Embedded Clusters Open Clusters Globular Clusters Nuclear Clusters

N stars

slide-38
SLIDE 38

/ 49 Nora Lützgendorf, KAS16 33

  • 1-30 pc
  • mass ~ 104 - 106 MSUN
  • gravitationally bound
  • age: 10 - 12 Gyr

➡ oldest objects in the universe!

Globular Clusters

slide-39
SLIDE 39

/ 49 Nora Lützgendorf, KAS16 33

  • 1-30 pc
  • mass ~ 104 - 106 MSUN
  • gravitationally bound
  • age: 10 - 12 Gyr

➡ oldest objects in the universe!

Globular Clusters

slide-40
SLIDE 40

/ 49 Nora Lützgendorf, KAS16 34

Globular Clusters - Are dense

SUN ALPHA CENTAURI DENSITY ~103 1/pc3

slide-41
SLIDE 41

/ 49 Nora Lützgendorf, KAS16 35

PAST:

  • All stars formed at the same time
  • All stars have the same chemical composition

TODAY: (see Lecture 2)

Omega Centauri, Bellini et al., 2011

Globular Clusters - Not what expected

slide-42
SLIDE 42

/ 49 Nora Lützgendorf, KAS16 36

Always around galaxies Milky Way Andromeda M87

~200 GCs ~500 GCs ~15 000 GCs

Globular Clusters - Live in Galaxies

slide-43
SLIDE 43

/ 49 Nora Lützgendorf, KAS16

Number of Globular Clusters in a galaxy divided by the galaxy’s luminosity:

  • Formation efficiency of Globular Clusters relative to field stars
  • Depends on galaxy type (higher in ellipticals)

37

SN = NGC/LG

Georgiev et al., 2010

Globular Clusters - Specific Frequency

slide-44
SLIDE 44

/ 49 Nora Lützgendorf, KAS16 38

Blue Globular Clusters

  • metal-poor
  • galaxy halo
  • larger

Red Globular Clusters

  • metal-rich
  • bulge/disk
  • smaller

BLUE RED

Globular Clusters - Bimodality

slide-45
SLIDE 45

/ 49 Nora Lützgendorf, KAS16 39

Young Massive Clusters

  • Young cluster populations forming today
  • Maybe forming Globular Clusters???
  • Formation Environments:

Galaxy Mergers Spiral Galaxies Starbursting Dwarfs

High Star Formation

slide-46
SLIDE 46

/ 49 Nora Lützgendorf, KAS16 40

Types of clusters

100 -1000 1e5-1e7 1e6-1e8 1e4-1e5 1e4-1e6 OB Associations Embedded Clusters Open Clusters Globular Clusters Nuclear Clusters

N stars

slide-47
SLIDE 47

/ 49 Nora Lützgendorf, KAS16 41

Nuclear Clusters

  • 1-30 pc
  • mass ~ 105 - 108 MSUN
  • age: multiple epochs of

star formation

  • centers of galaxies
  • gravitational bound
  • co-existing with black hole
  • densest objects in the

universe

Seth et al., 2006

slide-48
SLIDE 48

/ 49 Nora Lützgendorf, KAS16 42

SUN ALPHA CENTAURI ALPHA CENTAURI DENSITY ~106 1/pc3 DENSITY ~106 1/pc3

Nuclear Clusters - Are super dense

slide-49
SLIDE 49

/ 49 Nora Lützgendorf, KAS16 43

Seth et al., 2010

NGC 404

Nuclear Clusters - Host black holes

slide-50
SLIDE 50

/ 49 Nora Lützgendorf, KAS16 44

Nuclear Clusters - Formation

1.) Globular Cluster infall 2.) Gas accretion, star formation

slide-51
SLIDE 51

/ 49 Nora Lützgendorf, KAS16 45

Nuclear Clusters - Formation

1.) Globular Cluster infall 2.) Gas accretion, star formation

slide-52
SLIDE 52

/ 49 Nora Lützgendorf, KAS16 46

Nuclear Clusters - Multiple populations

Sgr/M54

Siegel et al., 2007

slide-53
SLIDE 53

/ 49 Nora Lützgendorf, KAS16 47

Nuclear Clusters - Peculiar kinematics

slide-54
SLIDE 54

/ 49 Nora Lützgendorf, KAS16 48

Nuclear Clusters - In our Galaxy

slide-55
SLIDE 55

/ 49 Nora Lützgendorf, KAS16 48

Nuclear Clusters - In our Galaxy

slide-56
SLIDE 56

/ 49 Nora Lützgendorf, KAS16 48

Nuclear Clusters - In our Galaxy

slide-57
SLIDE 57

Nora Lützgendorf, KAS16 / 49 49

Summary

  • 1. Star Clusters:

➡ Collection of stars roughly born at the same time (sometimes gravitationally bound)

100 -1000 1e5-1e7 1e6-1e8 1e4-1e5 1e4-1e6 OB Associations Embedded Clusters Open Clusters Globular Clusters Nuclear Clusters

  • in the disk
  • gravitationally

unbound

  • in the disk
  • still gas left
  • in the disk
  • gravitationally

bound

  • in the halo/

bulge

  • oldest objects

in the universe

  • at the center
  • f the galaxy
  • densest
  • bjects in the

universe
