CRaft: Building High-Performance Consensus Protocols with Accurate Clocks

Feiran Wang*, Balaji Prabhakar*, Mendel Rosenblum*, Gene Zhang† *Stanford University, †eBay Inc.

Overview

• CRaft: a multi-leader extension to Raft enabled by accurate clocks

2

Better performance Existing protocol Synchronized clocks

State Machines

• Maintain internal states
• Respond to external requests
• Examples: databases, storage systems
• How do we make them reliable?

3

State x: 2 y: 3 x←1 State x: 1 y: 3 State x: 1 y: 1 y←x

Replicated State Machines

Servers State Machine x: 2 y: 3 Consensus Log

x←1 y←1 …

Client Client x←1 State Machine x: 2 y: 3 Consensus Log

x←1 y←1 …

State Machine x: 2 y: 3 Consensus Log

x←1 y←1 …

• Consensus: ensures all servers agree on the same log
• Continues to operate if at least a majority of servers are up

4

Diego Ongaro and John Ousterhout. The Raft consensus algorithm. https://raft.github.io

The Raft Consensus Protocol

• A widely used consensus protocol
• Leader-based
• Benefits: simple and efficient
• Limitation: leader is the bottleneck for

throughput and scalability

5

Diego Ongaro and John Ousterhout. 2014. In search of an understandable consensus

• algorithm. In USENIX Annual Technical Conference. 305–319.

Follower Follower Leader Client Client Client Leader

x←1 y←1 … x←1 y←1 … x←1 y←1 …

Limitations with Single Leader

• Single leader limits throughput and scalability

6

Performance degrades with high load Decreasing throughput with larger cluster sizes

Load increases

Challenge in a Multi-Leader Protocol

7

Replicate my log I have a log I have a log I have a log

• k
• k

Single leader Multiple leaders

• Challenge: how to coordinate leaders?
• Solution: agreement on time => agreement on order

Clock Synchronization

Percentile 90th 99th 99.9th max Clock offset 7us 11us 15us 26us Distribution of clock offsets between servers (20 machines on CloudLab)

• Achieving agreement on time is not trivial in a distributed system
• Huygens: a software clock synchronization system

8

Yilong Geng, Shiyu Liu, Zi Yin, Ashish Naik, Balaji Prabhakar, Mendel Rosenblum, and Amin Vahdat. Exploiting a natural network effect for scalable, fine-grained clock synchronization. In NSDI 2018. 81–94.

Huygens precision: ~20us NTP precision: ~20ms

Our Approach: CRaft

Raft CRaft (Clocks + Raft)

Scalability

Output A replicate log A replicated log

Safety & Consistency

✓ ✓

Same guarantee as Raft Practicability

✓ ✓

A simple add-on to Raft; easy to implement

9

The CRaft Consensus Protocol

CRaft Overview

Follower Server 2 Leader Server 1 Follower Server 3 Client Leader Follower Follower Follower Follower Leader Group 1 Group 2 Group 3 Client Client Merged log Merged log Merged log

11

Life of a Request

Leader Server 1 Follower Follower Client State Machine log Follower Server 2 Leader Follower State Machine log Follower Server 3 Follower Leader State Machine log

12

Replicate Commit

Merge

Execute

• Replicated on a majority of servers
• Safe and durable

Timestamp Management

• CRaft guarantees monotonically increasing timestamps in each log
• Safe time: indicates how up-to-date a log is

1 x←1 4 y←1 6 y←x 17 x←2 18 x←5 1 2 3 4 5 index

13

Leader Server Follower Follower Merged log timestamp command Log Safe time = 20

Safe Times

14

1 4 6 17 18 Log Safe time = 20 23 … 25 Current entries: timestamps <= safe time No entries come in with a timestamp smaller than safe time Now How up-to-date is this log?

Merging

1 4 6 17 2 5 12 18 3 8 10 15 1 2 3 4 5 Log 1 Log 2 Log 3 6 5 8 ts = 18 index ts = 12 ts = 19 merged log

• Merge up to the smallest safe time
• CRaft ensures merged log in monotonically increasing timestamp order

15

10 12 …

Optimization: Fast Path

• Fast path: respond to clients early for certain write operations

16

Replicate Commit Merge Execute Normal path: respond after execution Fast path: respond before execution

Evaluation

Experiment Setup

• Implementation
• Based on HashiCorp Raft – a popular and well-optimized implementation
• Environment
• CloudLab, single data center
• Workload
• In-memory key-value store
• Multiple clients send get or set requests concurrently

18

Throughput vs Cluster Size

• Up to ~2x read and ~2.5x write throughput compared to Raft

19

Latency vs Throughput

Average latency vs throughput (3 servers) 99th percentile latency vs throughput (3 servers)

• CRaft improves throughput and latency under high load

20

Performance gain under high load

Load increases Load increases

Average Latency

Performance vs Number of Clients

21

Latency is bounded by clock difference Throughput 2x 2x 2x

• NTP precision: ~20ms, Huygens: ~20us

Conclusion

22

Better performance Stronger consistency Existing systems Synchronized clocks

• Accurate clocks enable better performance and/or consistency

Thank you!
