Application of NX Wave Technology in Die Design Process
Seamless integration of part design information into tooling design process
SLIDE 4
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
Presentation Layout
- Overview of wave
- Demonstration of using wave illustrated
through a case study, “COOL RIM”
- Best practices
- Questions & Answers
SLIDE 5
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
We’ll talk about Application of WAVE functionality: create and control upstream flow of design information “do things right from the beginning”
SLIDE 6
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
Our case study – ‘COOL RIM’ Techniques for die-cast tooling design process: applied to any popular molding technology Integrates cool rim part design into die components Demonstrates propagation of part geometry changes to die assembly
SLIDE 7
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – WAVE Facts WAVE – UG/NX technology of linking inter-part geometry creation of inter-part dependencies Works on part topology level Wave Geometry Linker Requires assembly environment does not require WAVE control license
SLIDE 8
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Flow of Information
Machined Part Casting Part Cavity Trim Part
Vertical WAVE Linking (in series)
SLIDE 9
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Machined Part
Step 1: “as machined” model Development of end product (as machined) Integration of casting design intent For effective design ‘clean geometry’ is essential Proper file organization Modeling discipline and diligence
SLIDE 10
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
SLIDE 11
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Flow of Information
Machined Part Casting Part Cavity Trim Part
Vertical WAVE Linking (in series)
SLIDE 12
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Casting Part
Step 2: ”As cast” model Vertical wave link in time stamp Additional casting features: shut-offs added to casting model
SLIDE 13
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
SLIDE 14
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Flow of Information
Machined Part Casting Part Cavity Trim Part
Vertical WAVE Linking (in series)
SLIDE 15
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Cavity Trim Part
Step 3: Cavity Trim Part Vertical wave link to casting model Apply shrinkage factor for cast material (scale feature) Extracted cavity regions – along parting line divisions Tooling seal-off faces developed and attached to appropriate cavity regions to form unique cavity trimming tools
SLIDE 16
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
Trim Sheets
SLIDE 17
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Flow of Information
Die Top Level Assembly Cover Insert Cavity Trim Part
Horizontal WAVE Linking (in parallel)
Ejector Insert Slide#1 Slide#2 Die Component
SLIDE 18
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Die Component
Startup die component model: extruded block controlled by sketch Add to top level die assembly: waved into each cavity component horizontal wave link Overall die dimensions: controlled from single file die component
Envelope
- f die
components
SLIDE 19
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
SLIDE 20
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Cover Insert
Step#1 WAVE linked bodies Step#2 Cavity trim operation Step#3 Final component
Use trim sheet to create the ‘cover insert’ from the original block
SLIDE 21
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Ejector Insert
Step#1 WAVE linked bodies Step#2 Cavity trim operation Step#3 Final component
Use trim sheet to create the ‘ejector insert’ from the original block
SLIDE 22
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Slide#1
Step#1 WAVE linked bodies Step#2 Cavity trim operation Step#3 Final component
Use trim sheet to create the ‘slide#1’ from the
- riginal block
SLIDE 23
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Slide#2
Step#1 WAVE linked bodies Step#2 Cavity trim operation Step#3 Final component
Use trim sheet to create the ‘slide#2’ from the
- riginal block
SLIDE 24
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – Die Top Level Assembly
Final step in design integration process From part model level to tool assembly level Part design changes will propagate to tooling components through top level die assembly model
SLIDE 25
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
SLIDE 26
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
SLIDE 27
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – How does it work? FROM TO UPDATED ‘COVER INSERT`
Change Propagation
SLIDE 28
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
SLIDE 29
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
‘COOL RIM’ – How does it work? FROM TO UPDATED ‘COVER INSERT`
Change Propagation
SLIDE 30
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
SLIDE 31
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
What is important for successful design? File organization: keep it simple and straightforward Proper and efficient use of modeling techniques Efficient WAVE management
SLIDE 32
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
GOOD Design Practices Layer structure / category naming File Organization: Modeling tree structure – feature sequence/grouping/naming Expression/formula definition Defined geometry reference sets
SLIDE 33
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
GOOD Design Practices Fixed datums and primitives: as startup features only Modeling Techniques:
SLIDE 34
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
GOOD Design Practices Fixed datums and primitives: as startup features only Modeling Techniques: Don’t be afraid of using sketches: avoid using non- parametric “flying” wireframe
SLIDE 35
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
GOOD Design Practices Fixed datums and primitives: as startup features only Modeling Techniques: Don’t multiply features: especially datums Don’t patch model by adding features over existing ones Don’t build deep model dependencies Always check validity of model geometry Don’t be afraid of using sketches: avoid using non- parametric “flying” wireframe
SLIDE 36
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
GOOD Design Practices Upfront planning investment into model and file organization and diligence in keeping model files “clean & lean” will bring multiple benefits to seamless flow of design information
SLIDE 37
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
WAVE Management Efficient WAVE management without WAVE Control License Vertical (serial) WAVE linking Horizontal (parallel) WAVE linking Managing WAVE links - breaking, reattaching, up dating links
SLIDE 38
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
WAVE Geometry Linker – What are the benefits? Full parametric integration of part design data into tooling design process Flexible management of linking process “Geometry safe” method Improved performance (smaller individual files) No additional license required Helps even with “challenging part geometry”
SLIDE 39
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
Problem Geometry – How to deal with it? Topology problems must be fixed – clean topology is a MUST for math data integrity
SLIDE 40
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
Problem Geometry – How to deal with it? Well defined and simplified parting lines With clean part geometry, even non-parametric data integration can proceed WAVE management is critical to preserve tooling data integrity – breaking and re-establishing WAVE links, delayed updates Topology problems must be fixed – clean topology is a MUST for math data integrity
SLIDE 41
CADmech Design Inc. Your success; there is no compromise www.cadmech.com
QUESTIONS AND ANSWERS
Contact us: Presenter: Misha Bosnjakovic (misha@cadmech.com) 905.474.2577 x.224 General Inquiries: Jason MacFarlane (jason@cadmech.com) 905.474.2577 x.222
