Sottotitolo WHAT IS WETNET WETNET is a Consortium created to - - PowerPoint PPT Presentation

Sottotitolo

WETNET is a Consortium created to realize a Project Co-Founded by the Eco-innovation initiative of the European Union, to develope a new low cost technology for metering water flow and pressure, combined with an OPEN SOURCE Supervisory Software, to intercept and cut water leaks, reducing energy costs in water networks.

WHAT IS WETNET

WHO ARE WETNET CONSORTIUM PARTNERS

PRODUCTS MANUFACTURER www.bre.pisa.it ENGINEERING & SYSTEM INTEGRATION www.ingegnerietoscane.net SALES DEVELOPMENT IN ESPANA www.itg.es SALES DEVELOPMENT IN ITALY www.bimatik.it

ACEA GROUP MEMBER

• Old pipes with continuos leaks
• Water loss average more than 40%
• No-revenue water
• High energy costs for water loss

WORLD WATER NETWORK SCENARY WORLD WATER NETWORK SCENARY

WHY CHOOSE WETNET

• Wetnet offer a 360° solution to create Smart Water Networks
• Innovative Low Cost Flow/Pressure Meter
• High performance Data Logger/Uplink
• Smart Supervisory Software OPEN SOURCE
• Experienced Consultant Service to analize, project, and realize Turn-Key

customized solutions

• WPF Pulse Flowmeter

(incremental / counter metering - always on, need external battery)

• WUF Sample Flowmeter

(instant metering - normally sleep/low consuption or always

• n with external power)

2 WETNET FLOW METERS

Patented meters based on load cells new technology

• Materials: Body in stainless steel Inox AISI316
• Pipe range size : from DN 80 to DN 2.000
• Accuracy : Better than the 5% on reading in the 70% of measuring range
• Precision: Better than the 4% on reading in the 70% of measuring range
• Power supply:

3.6Vcc (with external lithium battery)

• Power consuption stand-by / sampling : Very Low, Less than 5mW / less than 30mW
• Open collector outputs : n. 2:outputs for RTU ‘s for speed and flow direction
• Max output frequency :

30 Hz

• Min period between reading : 2 sec
• Bidirectional measuring flowmeter
• Measuring range: from 0,1 to 1,8 m/sec
• Interface: RS-485 for configuration and data exchange, Modbus protocol
• Hot tap insertion without interrupting the water flow
• Waterproof to IP68

WPF - PULSE FLOW METERS DETAILS WPF - PULSE FLOW METERS DETAILS

• Materials of meters: Probe body in stainless steel InoxAISI316
• Pipe range size : from DN 80 to DN 2.000
• Accuracy : Better than the 5% on reading in the 70% of measuring range
• Precision: Better than the 4% on reading in the 70% of measuring range
• Power supply: 7,2 – 30 Vcc
• Power consuption Stand-by / sampling : Less than 10mW / less than 50mW
• Analogue inputs : No. 3 (4-20mA/0-5V)
• Display : Graphic 122x32 pixels
• Pressure sensor: Optional

WUF - UPLINK FLOW METERS DETAILS : part 1 WUF - UPLINK FLOW METERS DETAILS : part 1

• USB interface

For setting and downloading data

• Modem

GSM/GPRS quadriband

• Memory card

SD 2Gb

• Operation / storage temperature -10÷45°C / -20÷60°C
• Bidirectional measuring flowmeter
• Measuring range: from 0,1 to 1,8 m/sec
• Interface: RS-485 for configuration and data exchange, Modbus

protocol

• Hot tap insertion without interrupting the water flow
• Waterproof Sensor: IP68 - Controller: IP42 o IP68 on request

WUF - UPLINK FLOW METERS DETAILS : part 2 WUF - UPLINK FLOW METERS DETAILS : part 2

WLB - WETNET DATA LOGGER / UPLINK

Local logging on SD card Designed for low-power applications with internal battery but supplying also with external source Analog inputs and digital inputs with counter function Digital outputs for supplying external instruments Internal or external antenna User-friendly software for settings and real time data viewing USB interface For setting and downloading data Modem GSM/GPRS quadriband Memory card SD 2Gb Operation / storage temperature -10÷45°C / -20÷60°C Interface: RS-485 for configuration and data exchange, Modbus protocol, can be used as mini-RTU and MODBUS TCP/IP protocol on GPRS link

Waterproof DIN IP42 or Cylinder IP68

• Open Source Software (EUPL LICENCE

FREE)

• Open elaboration capability
• Local data storage and unit conversion
• Supervisory Services software capable of

configuration and test functions, web based monitoring in standalone mode

• Interface with ProGea MOVICON SCADA

(and others SCADA)

• Asynchronous import/export of data sets

ODBC, EPANET

• Functions may be accessed also through

SaaS (Software as a Service)

WSS - SUPERVISORY SERVICE SOFTWARE WSS - SUPERVISORY SERVICE SOFTWARE

EXAMPLE NETWORK SCHEME

CALIBRATION MODEL

SUPERVISORY

DMA EMAIL / SMS

Event type : Possible water loss detected! Delta : 0.49 l/s District : distretto rete chiesina (#334) Date : 2014-11-22 Duration : 6 days Variable : Min. Night Actual value : 7.08 l/s

SCADA X Flow Meter X

DMA SHAPE DMA EVENT DMA EVENT

DMA PATTERN

Flow Meter Logger/Uplink

Work Force Mngr

GIS

Normally 10-20% reduction of water loss in few months Same percentage of energy saving Less CO2 emitted in atmosphere Xxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

WETNET BENEFITS

CASE HYSTORY – ACEA SPA DMA LIRI BASSO FROSINONE

Installation of a Flowmeter to measure input water flow on DMA, sending continuos data to WSS Installation

• f a new

valve to keep constant pressure Water leaks repair

• ------ continuos value

Normally 10-20% reduction of water loss in few months Same percentage of energy saving Less CO2 emitted in atmosphere

CASE HISTORY DMA LIRI BASSO – NIGHT MINIMUM & DAY AVERAGE

NIGHT MINIMUM DAILY AVERAGE
