SmartBright Panel (RC099V)

4

SmartBright Panel – Features and benefits

Features:

• Perfect replacement for Conv. – System lumen 2600lm & 3800lm to replace

T5(3X14,4X14)/T8(3X18,4X18) troffer

• Energy saving - system efficacy >90 lm/W, 50~60% energy efficient than TL troffer
• Comfortable light – Full window design delivering extremely uniform light
• Multiple mountings – Recessed, suspended and plaster ceiling options all available

5

Applications

• Meeting room
• Office
• Hospital
• School
• Public area

6

Product Designation RC099V LED26S/840 W30L120 PCV GM

4 Mounting option

– Recessed SUS – Suspended PCV – Plaster ceiling

1 2 3

2 CCT

840 – 4000K 865 – 6500K

4

1 Lumen package

26S – 2600lm 36S – 3800lm

3 Dimension

W60L60 – 597X597mm (Recessed & PCV) W60L60 – 603X603mm (Suspended) W30L120 - 297X1197mm (Recessed & PCV) W30L120 - 303X1203mm (Suspended)

Recessed Suspended (w. frame)

7

Mounting options in the range

Recessed 597x597mm Suspended 603x603mm Plaster ceiling 597x597mm

8

Technical Specifications

Type RC099V Recessed & PCV RC099V Suspended (w.frame) Picture

System output 2600 / 3800lm 2600 / 3800lm 2600 / 3800lm 2600 / 3800lm Wattage 29 / 34W 29 / 34W 29 / 34W 29 / 34W System Efficiency 90 / 110lm/W 90 / 110lm/W 90 / 110lm/W 90 / 110lm/W CCT NW(4000K), CW(6500K) NW(4000K), CW(6500K) CRI > =80 > =80 SDCM <5 <5 Operating temp 25ºC 25ºC Driver Fixed output Fixed output IP rating IP20 IP20 Dimension (mm) 597x597x75 297x1197x75 603x603x75 303x1203x75 Installation Recessed, PCV Suspended Lifetime 25,000 hrs @L70 B50 25,000 hrs @L70 B50 Approbation CB / EMC / CE CB / EMC / CE

8

9

Ordering information

12NC Description Lumen CCT Driver Mounting

911401833999 RC099V LED26S/840 W60L60 GM 2600lm 4000K Fixed output Recessed 911401834099 RC099V LED26S/865 W60L60 GM 2600lm 6500K Fixed output Recessed 911401834199 RC099V LED26S/840 W30L120 GM 2600lm 4000K Fixed output Recessed 911401834299 RC099V LED26S/865 W30L120 GM 2600lm 6500K Fixed output Recessed 911401834799 RC099V LED26S/840 W60L60 PCV GM 2600lm 4000K Fixed output Plaster ceiling 911401834999 RC099V LED26S/840 W30L120 PCV GM 2600lm 4000K Fixed output Plaster ceiling 911401835199 RC099V LED36S/840 W60L60 GM 3800lm 4000K Fixed output Recessed 911401835299 RC099V LED36S/865 W60L60 GM 3800lm 6500K Fixed output Recessed 911401835399 RC099V LED36S/840 W30L120 GM 3800lm 4000K Fixed output Recessed 911401835499 RC099V LED36S/865 W30L120 GM 3800lm 6500K Fixed output Recessed 911401835999 RC099V LED36S/840 W60L60 PCV GM 3800lm 4000K Fixed output Plaster ceiling 911401836199 RC099V LED36S/840 W30L120 PCV GM 3800lm 4000K Fixed output Plaster ceiling 911401834399 RC099V LED26S/840 W60L60 SUS GM 2600lm 4000K Fixed output Suspended 911401834499 RC099V LED26S/865 W60L60 SUS GM 2600lm 6500K Fixed output Suspended 911401834599 RC099V LED26S/840 W30L120 SUS GM 2600lm 4000K Fixed output Suspended 911401834699 RC099V LED26S/865 W30L120 SUS GM 2600lm 6500K Fixed output Suspended

• More options available on request

11

Application Guide

Scenario # Grid pattern Lum Spacing Lum description Lum size Lum lm Lum qty Lux average @ 0.8m work plane LPD Uniformity (Emin/ave)

#1 2’ x 2’ 2.4 x 2.4m RC099V LED36S 597 x 597 mm 3800 15

520 6.8 0.7

#2 2’ x 2’ 2.4 x 2.4m RC099V LED26S 597 x 597 mm 2600 15

359 5.8 0.7

#3 1’ x 4’ 2.4 x 2.4m RC099V LED36S 297 x 1197 mm 3800 15

468 6.8 0.76

#4 1’ x 4’ 2.4 x 2.4m RC099V LED26S 297 x 1197 mm 2600 15

325 5.8 0.74

Simulation configuration

• Reflectance: Ceiling -50%, wall - 30%, floor -10%; Maintenance Factor : 0.8; Work Plane Height: 0.8 m; Lum spacing refers to the distance

from luminaire center to center of the next

• #1 & 2 - Area: 11.4 x 6.6 x 2.8m; Luminaires : 3 x 5 = 15pcs
• #3 & 4 – Area: 11.4 x 7.2 x 2.8m; Luminaires : 3 x 5 = 15pcs ;

#1 & #2 #3 & #4

• For 500+lx, recommend model is RC099V LED36S W60L60
• For 400+lx, recommend model is RC099V LED36S W30L120
• For 300+lx, recommend model is RC099V LED26S W60L60/W30L120
• The lx refers to the average lx on the work plane and recommend luminaire spacing is

3x3 grids (2.4m x 2.4m)
