SLIDE 1
SMART SOLUTIONS
TO TODAY’S TOUGH APPLICATION
DESIGN TECHNOLOGIES INTERNATIONAL Ltd.
VERTICAL TURNING LATHES
SMART SOLUTIONS TO TODAYS TOUGH APPLICATION DESIGN TECHNOLOGIES - - PowerPoint PPT Presentation
SMART SOLUTIONS TO TODAYS TOUGH APPLICATION DESIGN TECHNOLOGIES - - PowerPoint PPT Presentation
SMART SOLUTIONS TO TODAYS TOUGH APPLICATION DESIGN TECHNOLOGIES INTERNATIONAL Ltd. VERTICAL TURNING LATHES VERTICAL TURNING LATHE TYPE VMC 150 TECHNICAL SPECIFICATIONS Table diameter - 1500 mm Max. workpiece outside diameter - 1250 mm Max.
SLIDE 2
SLIDE 3
VERTICAL TURNING LATHE TYPE VMC 150
SLIDE 4
TECHNICAL SPECIFICATIONS
Table diameter
- 1500 mm
- Max. workpiece outside diameter
- 1250 mm
- Max. weight of the workpiece
- 4 tons
- Max. turning height of the workpiece
- 400 mm
- Max. height from top of plain table to bottom of ram
- 600 mm
AC Drive Motor
- SIEMENS
Driving power
- 100 Kw
Table Chuck Speed
- 20 250 rpm
CNC control SIEMENS
- Sinumerik 840D
Tool system
- CAPTO8
Tool magazine
- 20 tools
Total weight of the machine (approximate)
- 18 tons
SLIDE 5
MAIN FEATURES
All main components of the machine (bed, table, crossrail) are made of cast iron The body of the table is made of cast iron clamped of the workpiece automatically by means of 6 jaws system Cross roller bearings under the table 3 bed ways solid casting 2 feed drives for vertical travel of the ram 2 chips conveyors on the both side of the bed (free front) Symmetrical design
SLIDE 6
How we do it…
SLIDE 7
SLIDE 8
SLIDE 9
SLIDE 10
SLIDE 11
SLIDE 12
SLIDE 13
SLIDE 14
SLIDE 15
SLIDE 16
SLIDE 17
SLIDE 18
SLIDE 19
SLIDE 20
SLIDE 21
SLIDE 22
SLIDE 23
SLIDE 24
SLIDE 25
SLIDE 26
SLIDE 27
