SMART SOLUTIONS TO TODAYS TOUGH APPLICATION DESIGN TECHNOLOGIES INTERNATIONAL Sp. z o.o. HEAVY DUTY CNC CONTROLLED LATHE TV 60/960 CNC The heavy duty TV60/960 CNC Lathes incorporate design features based upon the most recent achievements


slide-1
SLIDE 1

SMART SOLUTIONS

TO TODAY’S TOUGH APPLICATION

DESIGN TECHNOLOGIES INTERNATIONAL Sp. z o.o.

slide-2
SLIDE 2

HEAVY DUTY CNC CONTROLLED LATHE TV 60/960 CNC

slide-3
SLIDE 3

The heavy duty TV60/960 CNC Lathes incorporate design features based upon the most recent achievements in machine tool design and heavy duty machining techniques

slide-4
SLIDE 4

The lathe in below execution is intended for:  Rough and finish machining  Turning  Boring  Reaming  Tapping  Thread cutting  Taper turning  Facing with constant cutting speed  Grinding  Abrasive  Milling and drilling  Cold rolling

slide-5
SLIDE 5

MAIN FEATURES

 All main components of the machine are made of GG25 cast iron  Faceplate are made of cast steel  Four guideway step bed  Electrical cabinet wired 3/480V/60 Hz-UL list  High rigidity and precision of manufacturing  Siemens CNC control Sinumeric 840D  High efficiency  Fine surface finish of machined workpiece  Hardened and ground bedways. Flat bedways are flash chromed  Hardened and ground gears, spline shafts  Centrally operated lubrication systems

slide-6
SLIDE 6

Workpiece Capacity: Swing over bedways

  • 60 in.

Total distance between centers

  • 80 ft.

Carrying capacity between centers

  • 80 tons

Headstock:

  • No. of speed ranges
  • 2

Range of speeds

  • 0.5-100 RPM

Constant horsepower range RPM

  • 7.5-100 RPM

Torque at faceplate, at 60 inch diameter

  • 120.000 Nm (1000.000 in. Ibs)

Main drive motor AC-Siemens

  • 127 HP

Faceplate diameter

  • 60 inch.

Tailstock: Quill squire

  • 18,9x18,9 inch. x inch.

Quill travel

  • 15 inch.

Quill thrust capacity

  • 70,000 lbs.

Quill traverse rate, inches per minute

  • 5.5 - 11 inch.

Tailstock traverse rate

  • 90 ipm.

TECHNICAL SPECIFICATIONS

slide-7
SLIDE 7

Carriages: Carriage travel (Z & W axis)

  • 80 ft

Carriage thrust, capacity

  • 13,500 lbs

Carriage traverse rate, inches per minute

  • 250 ipm

Carriage feed range, inches per minute

  • 0-250 ipm

Cross slide: Cross slide thrust, capacity

  • 13,500 lbs.

Cross slide feed range, inches per minute

  • 0-200

Cross slide ball screw diameter

  • 3.15 inch.

Tool size

  • 2 inch.

Steady Rests:

  • No. of steadies
  • 2 + 2

Configuration hinged yoke

  • 3 point

Shaft range, O.D.:

  • 20-32 inch.

“C” - axis

  • No. of speeds - “C” axis
  • (Inf.Var.)

Range of speeds – “C” axis

  • 005-2 RPM

TECHNICAL SPECIFICATIONS

slide-8
SLIDE 8

How we do it…

slide-9
SLIDE 9
slide-10
SLIDE 10
slide-11
SLIDE 11
slide-12
SLIDE 12
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19

Thank you for your attention.
