SLIDE 1
What is SmartPrinter?
Performs print management and manipulation. Works with any PCL5 printer. Receives input date from any source application. A server based print engine.
Smart Printing Solutions LTD What is SmartPrinter? A server based - - PowerPoint PPT Presentation
Smart Printing Solutions LTD What is SmartPrinter? A server based - - PowerPoint PPT Presentation
Smart Printing Solutions LTD What is SmartPrinter? A server based print engine. Performs print management and manipulation. Works with any PCL5 printer. Receives input date from any source application. What can it do? Language
SLIDE 2
SLIDE 3
What can it do?
SLIDE 4
Allow printers with no special printer fonts to print documents in languages such as Hebrew, Russian, Turkish, Greek, etc… Enable automatic support for any character set, font style and font type required by the source application.
) 1/6 (
Language fonts
What can it do?
SLIDE 5
Allow automatic translation of printer emulations such as: Epson, IBM Proprinter, DEC, CaPSL, Prescribe to PCL5. Any standard printer can now print documents written for any specific printer emulation.
) 2/6 (
Emulation conversions
What can it do?
SLIDE 6
Adds templates and logos to a printed document. Eliminates the need of preprinted forms. Supports printing of different templates for different pages in a single document.
) 3/6 (
Logos and Templates
What can it do?
SLIDE 7
Adds barcodes to the printed document, based on data from the document. Supports different barcode encoding methods, such as: UPC, EAN, Code 39, Code 128, 2 of 5, etc…
) 4/6 (
Barcodes
What can it do?
SLIDE 8
Allow you to save the designed document to A folder as a TIFF/PDF file for archive. Allow you to sent the documents automatically via a fax server while using the document data as an input to the fax number.
) 5/6 (
Archive and Fax
What can it do?
SLIDE 9
Allow the usage of all the printer’s capabilities, from any application: Paper trays Stapling Duplex Color printing
Exploiting printer abilities
) 5/6 ( What can it do?
Output bin & Mail box
SLIDE 10
How Does it Work?
SLIDE 11
A textual print job is created in the main computer and sent to the print server (instead of to the printer)
main computer ) 1/4 ( How Does it Work?
SLIDE 12
The print job is received in the print server The SmartPrinter software processes it
main computer ) 2/4 ( Print Server
SmartPrinter print engine is installed
- n the print server
How Does it Work?
SLIDE 13
The processed print job is sent to the printer
main computer ) 3/4 ( Laser Printer How Does it Work? Print Server
SmartPrinter print engine is installed
- n the print server
SLIDE 14
A laser quality print job is printed, while exploiting all the printer’s capabilities and technology
main computer ) 4/4 ( Laser Printer How Does it Work? Print Server
SmartPrinter print engine is installed
- n the print server
SLIDE 15
Sample Application
SLIDE 16
A textual print, containing Epson ESC/P code printed on a dot matrix printer
) 1/4 ( Sample Application
SLIDE 17
Step 1: conversion of the Epson commands to standard PCL5 commands to be printed on a laser printer
) 2/4 ( Sample Application
SLIDE 18
Step 2: Add a template to the form according to an id in the document
) 3/4 ( Sample Application
SLIDE 19
Step 3: Duplicate print job to 3 copies, take each copy from a different paper tray, add barcode and a stamp
) 4/4 ( Sample Application
SLIDE 20
Advantages of the solution
Ability to implement in steps. Exploiting printer capabilities. On demand customized applications. Smooth migration of printers. Fast processing of print data.
