SLIDE 1
Single-point Webserver
COUNTIS E17 - E18 - E27 - E28
Single-point webserver
12/10/2017
2
Single-point Webserver COUNTIS E17 - E18 - E27 - E28 Single-point - - PowerPoint PPT Presentation
Single-point Webserver COUNTIS E17 - E18 - E27 - E28 Single-point - - PowerPoint PPT Presentation
Single-point Webserver COUNTIS E17 - E18 - E27 - E28 Single-point Webserver The products have an Ethernet port with an integrated web server accessible on a standard web browser (Internet Explorer, firefox) Single-point webserver 2
SLIDE 2
SLIDE 3
Single-point webserver
12/10/2017
3
Login
SLIDE 4
Single-point webserver
12/10/2017
4
Instantaneous values - U/I
SLIDE 5
Single-point webserver
12/10/2017
5
Instantaneous values - Power
SLIDE 6
Single-point webserver
12/10/2017
6
Energy – Total and Partial
Reset of partial energies. Available in admin login.
SLIDE 7
Single-point webserver
12/10/2017
7
Energies per tariff – Total and Partial
Reset of partial energies (per tariff). Available in admin login.
SLIDE 8
Single-point webserver
12/10/2017
8
Recording – Export of energy values
SLIDE 9
Single-point webserver
12/10/2017
9
Recording – Export of energy values
8Mb of memory;
1 values recorded every 15min memory of 2500 days 4 values recorded every 15min memory of 1300 days
16 parameters available for recording;
SLIDE 10
Single-point webserver
12/10/2017
10
Diagnosis
SLIDE 11
Single-point webserver
12/10/2017
11
Configuration
Modification of communication parameters; Modification of the internal clock (manual or synchronization with NTP server); Choice of the separator for CSV file.
SLIDE 12
Single-point webserver
12/10/2017
12
Configuration
Automatic export of CSV files via FTP.
SLIDE 13
Single-point webserver
12/10/2017
13
Configuration
Two profiles available:
User (viewing information)
Login: user Password: user
Admin (viewing, configuring and resetting energies)
Login: admin Password: Admin
SLIDE 14
Single-point webserver
12/10/2017
14
