Silt Fence Installation Kody R. Featherston Candice L. Johnson J. Kent Evatt Monica L. Johnston BAE 4012 Fall 2003 WHAT IS SILT FENCE? A silt fence is a temporary sediment barrier consisting of filter fabric entrenched into the soil


slide-1
SLIDE 1

Silt Fence Installation

Kody R. Featherston Candice L. Johnson

  • J. Kent Evatt

Monica L. Johnston BAE 4012 – Fall 2003

slide-2
SLIDE 2

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

WHAT IS SILT FENCE?

  • A silt fence is a temporary sediment barrier

consisting of filter fabric entrenched into the soil and attached to supporting posts.

slide-3
SLIDE 3

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

PROBLEM DEFINITION

  • Common failures are caused by:

– Improper Installation – Incorrect Location – Inadequate Strength

slide-4
SLIDE 4

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

FAESF

  • Failure Avoidance and Effective Silt Fence

Technology

– control undercutting and overtopping – control lateral flow along the silt fence – improve the trapping of fine silts and clays – provide adequate strength posts and fence – provide for adequate bearing capacity of post footings

slide-5
SLIDE 5

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

STATEMENT OF WORK

  • Enviro-Mech will focus on reducing

failure due to improper installation.

  • Dr. Barfield’s team will continue

developing a new filter fence material configuration and support mechanism.

  • Enviro-Mech will design and build a

machine which will create a trench, lay the fence, and backfill the trench.

slide-6
SLIDE 6

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

INVESTIGATION

  • Recommended Silt Fence Practices
  • Current Equipment Patented

and in Production

  • Similar Vibratory Plow Applications
slide-7
SLIDE 7

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

RECOMMENDED PRACTICES

  • Information Concerns

– Trench Dimensions – Fence Location – Post Height – Fence Size

slide-8
SLIDE 8

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

CURRENT EQUIPMENT

  • Tommy Silt Fence

Machine

  • Erosion Runner
  • ImpleMax SF12c
  • McCormick

Equipment

slide-9
SLIDE 9

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

VIBRATORY PLOW

  • Cable Installation

Blades

– Integrated Slot – Four Bar Linkage

Groove

  • n Back

Edge of Blade Cable Guide Hook to Secure Guide Upper Latch

slide-10
SLIDE 10

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

CONCEPT DEVELOPMENT

  • Design Criteria

– FAESF Research Group – Charles Machine Works

  • Potential Solutions

– Proposal A - Two-Disk Method – Proposal B - Feed Channel Method – Proposal C - Tension Rod Method

slide-11
SLIDE 11

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

DESIGN CRITERIA

  • FAESF Proposed Design
slide-12
SLIDE 12

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

DESIGN CRITERIA

  • Design compatible with current power source

provided by Charles Machine Works

  • Economical
  • Marketable
slide-13
SLIDE 13

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

INSTALLATION METHODS

  • Proposal A - Two-Disk Method
  • Proposal B - Feed Channel Method
  • Proposal C - Tension Rod Method
slide-14
SLIDE 14

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

PROPOSAL A TWO-DISK METHOD

  • Two narrow disks

pinch the fabric.

  • The disks feed the

fabric into the slot.

  • Fabric is released

at the bottom of the slot.

slide-15
SLIDE 15

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

PROPOSAL B FEED CHANNEL METHOD

  • Channel will be

attached similar to four-bar linkage currently used.

  • The fence will require

added bulk to bottom edge.

slide-16
SLIDE 16

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

PROPOSAL C TENSION ROD METHOD

  • Spring loaded rod

will guide material through slot.

  • The end of the

rod acts as a pressure point.

slide-17
SLIDE 17

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

TEST AND ANALYSIS

  • Testing is required to determine the most

effective and financially feasible solution. – Methods Testing – Concept Testing – Final Design Testing

slide-18
SLIDE 18

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

PROJECT SCHEDULE

Fall Semester Accomplishments

10%

slide-19
SLIDE 19

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

PROJECT SCHEDULE

Spring Semester Plans

slide-20
SLIDE 20

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

PROJECT BUDGET

Material Cost Fabrication Time Fabrication Cost Total Cost Web Handling $30.00 10 hr $24.00 $54.00 Feeding Mechanism $330.00 50 hr $120.00 $450.00 Packing Wheel $180.00 25 hr $60.00 $240.00 Total Cost $540.00 85 hr $204.00 $744.00

slide-21
SLIDE 21

BAE 4012 – Fall 2003 K. Featherston, C. Johnson, M. Johnston, J.K. Evatt

THANK YOU

  • Richard Sharp -

Project Engineer

  • Kelvin Self -

Manager R & D

  • Dr. Billy Barfield -

FAESF Research Group

  • Dr. Ellen Stevens -

FAESF Research Group

  • Dr. Paul Weckler -

Senior Design Instructor

  • Dr. Glenn Brown -

Senior Seminar Instructor

  • Dr. Ron Elliot -

BAE Department Head

Enviro-Mech would like to thank those who have contributed to our Senior Design Project.

slide-22
SLIDE 22

Questions
