The Role of Analytics in Shaping the Future of Warehouse Operations Dr Tony McVeigh

MORE WITH LESS !

2

ORDER PICKING

3

4

Order Picking

▪ The retrieval of items from storage in response to customer demand ▪ Picking is the most labour-intensive and costly process that typically comprises 55% of the total warehouse operational expenses* ▪ Half of the order picker’s time is spent on traveling* ▪ Minimizing traveling cost (distance or time) is one

• f the most focussed objectives to improve order

picking efficiency

* Tompkins et al (2010)

5

Warehousing and Order Fulfilment

▪ Since order picking is acknowledged as the most labour and capital-intensive activities in warehouse operations, this drives a strong emphasis on picking optimisation; in particular:

• 1. Storage Allocation

Regulates the location of items (to minimise handling costs)

• 2. Routing Policies

Defines the best possible batch and route (for optimal picking) ▪ Order picking research* concentration is 32% and 38% on storage and routing, respectively ▪ With dynamic fluctuations in demand, warehouse picking can be a bottleneck in the order fulfilment cycle, which is an essential service level KPI ▪ The picking strategy should optimise the service level by compressing the order fulfilment cycle

* McGinnis et al (2011)

ORDER PICKING SYSTEMS

6

7

Layout Equipment Labour Technology

• ABC Analysis
• Slotting
• Product Characteristics
• Demand Profiling
• Location System
• Space
• Routing Policies
• Handling Units

− Totes, Bins, Cartons − Pallets − Cages

• MHE
• Racking
• Carousels
• Conveyors
• Automation
• Goods-to-Picker
• Picker-to-Goods
• Walking Distances
• Batch or Zone
• Training
• Ergonomics
• Health & Safety
• WMS
• Voice Picking
• RF Picking
• Pick-to-Light
• Put-to-Light
• AS-RS

Order Picking Interrelationships

8

Warehouse Design and Simulation

Classification of Order Picking System *

* Dallari, Marchet and Melacini (2007)

Automation level

Who picks the goods? Who / what moves in the pick zone? Conveyance to connect pick zones? Picking policy OPS

Automation Level

* Dallari, Marchet and Melacini (2007) Picking Volume Number of Items Order Lines per Day

Picker-to-Part Sortation Part-to-Picker Pick-to-Tote

Selection Method: OPS Matrix *

▪ Order sizes less than 0.5m³

PICK ROUTES

11

12

S-Shape Return Mid-Point Largest Gap Combined Optimal

Basic Routing Policies

13

Comparison of Routing Methods

Not for general distribution

PerformanSC Case Study * ▪ Narrow-aisle configuration ▪ Low level picker-to-parts system ▪ Order size range: 1 to 27 items (average,19) ▪ Pick tours follow S-Shaped routes ▪ Current pick routes approach the optimal solution for a large number of items ▪ For a small number of picks, the current practices are sub-optimal by 25%

Most Popular 14% travel reduction to pick 11 items

▪ For the most frequently picked orders, pick distances may be reduced by 14% solely by re-routing

14

PRODUCT SLOTTING

15

Slotting

▪ In general, less than 15% of SKUs within a warehouse are assigned to the most efficient location and this results in 10% to 30% cost increase in travel time and under-utilised locations* ▪ Slotting is a procedure used to optimally place individual goods within the warehouse ▪ This process a) Increases the storage density - squeeze more product into the space available b) Reduces picking distance - locate the most popular items close to despatch

• place items that frequently ship together next to each other in the pick face

c) Enables ergonomic efficiencies - by placing heavy items at waist height d) Accounts for key parameters such as value, cube, weight and crushability e) Determines how many and what size of pick face is required for each product line (e.g. very fast movers will require multiple pick faces to avoid congestion and bottle-necks at a single location) ▪ Drives improvements in space utilisation with possible footprint savings between 35% and 43% ▪ Accounts for seasonality and suggests product transfers

* Frazelle (2010)

Simple Slotting Technique

16

▪ Slotting software is integrated within many of today’s WMSs but can also be sourced separately ▪ Alternatively, simple slotting can be accomplished by order profiling using spreadsheet models ▪ Orders may be analysed in a number of different ways - the following grid presents one possible scheme

High Moderate Low High

Aa Ab Ac

Moderate

Ba Bb Bc

Low

Ca Cb Cc

Value Frequency

▪ Aa products are those SKUs that generate the most value and are sold most frequently, while Cc products, on the

• ther hand, are considered to be slow-movers; selling the least and moving less frequently

▪ Each SKU is assigned one of nine possible classifications ▪ Items having high sales and pick frequencies may be located in close proximity to despatch (Golden Zone) ▪ The data can then be used to generate a warehouse heat map in which with colour codes are used to depict the positions and classifications of each SKU

17

Slotting Case Study

▪ Warehouse footprint: 200m x 55m (2 mins to briskly walk from wall-to-wall) ▪ Order profiling analyses performed ▪ The top 50 fast movers identified and relocated closer to despatch (Golden Zone) ▪ Consequently, aggregate pick travel reduced by 17km per shift ▪ This process is deployed across all SKUs and re-slotting

• ccurs each quarter

▪ The order picking cycle time reduced by 20% resulting in improved warehouse throughput and material handling savings

Mobile Gold Standard (2011)

Mean Std Dev

Slow 0.65 0.21 Normal 1.11 0.17 Fast 1.47 0.2 Faster 1.83 0.25 Running 2.7 0.46 Walking Speed [ms-1] Walking Speed Level

Not for general distribution

18

INVENTORY REPLENISHMENT

19

Conventionally normal!

Low Low High High Variability in demand quantity Variability in demand timing

Demand Partitions

Smooth

▪ Demand is largely static; does not vary significantly over time ▪ Call-off remains relatively close to the average values ▪ Mainstream products

Erratic

▪ Sales may be substantial ▪ Volumes may vary dramatically ▪ Low-value items usually fulfilled immediately ex-stock

Intermittent

▪ Sporadic demand ▪ Products approaching end-of-life ▪ May account for half of stocked goods

Lumpy

▪ Slow-moving / expensive SKUs ▪ High value maintenance components ▪ Sold on occasional basis ▪ Safety stock requirements ▪ SKU cost / lead-time according to service level criticality

* Syntetos, Boylan, Croston (2005)

p

Demand Distributions

CV² 1.32 0.49

p

Inventory Replenishment Models

CV² 1.32 0.49

Normal Negative Binomial Gamma Poisson

Continuous Functions Discrete Functions

23

Demand Distribution: Retail Sector Case Study 1

▪ 12 week timescale: 2.8 million units across 17 thousand SKUs ▪ There are 3 essential SKU classes: Lumpy, Erratic and Smooth ▪ However, volume-wise, most items are found to be Smooth and the balance, Erratic ▪ Stock management is improved by the adoption of 2 replenishment models; Normal and Poisson ▪ The impact on service and working capital is both positive and measurable ▪ Storage requirements (pallet spaces) reduced by 8 – 11%

33% 30% 37%

Not for general distribution

24

Demand Distribution: Hardware Sector Case Study 2

▪ Typically, inventory replenishment was driven by Normal rules ▪ Demand partitioning provided insights into SKU classifications ▪ Introducing a more appropriate replenishment model to Lumpy SKUs enabled a reduction in component stock levels ▪ For a 98% service protection target, the annual impact is a) 14% less stock in the system, and b) 9% less material value

Normal NBD

Not for general distribution

25

SUMMARY

26

In Conclusion

▪ The application of analytics is key for the advancement of warehouse operations performance ▪ Three (of many possible) paths to performance improvements were presented - − Order Picking − Item Slotting − Inventory Replenishment

• each requiring demand and master data and each alone, capable of delivering rapid economic benefits

▪ Logistics and warehouse operations needs analytics and, in turn, the needs that arise in these activities drives new problems that analyses will help solve ▪ In reality, the implementation of meaningful solutions for warehouse and supply chain processes requires a) the use of technology to-hand for the management of data and knowledge extraction and, b) the resolution of optimisation models to assist decision making and so, making it possible to achieve ….

More with less !

Thank you for your attention
