slide-1
SLIDE 1

Self-Adjusting Stack Machines

Matthew A. Hammer Georg Neis Yan Chen Umut A. Acar

Max Planck Institute for Software Systems

OOPSLA 2011 — October 27, 2011 Portland, Oregon, USA

slide-2
SLIDE 2

Static Computation Versus Dynamic Computation

Static Computation: Fixed Input Compute Fixed Output Dynamic Computation: Changing Input Compute Changing Output Read Changes Update Write Updates

Matthew A. Hammer Self-Adjusting Stack Machines 2

slide-3
SLIDE 3

Dynamic Data is Everywhere

Software systems often consume/produce dynamic data Scientific Simulation Reactive Systems Analysis of Internet data

Matthew A. Hammer Self-Adjusting Stack Machines 3

slide-4
SLIDE 4

Tractability Requires Dynamic Computations

Changing Input Compute Changing Output Static Case (Re-evaluation “from scratch”) compute 1 sec # of changes 1 million Total time 11.6 days

Matthew A. Hammer Self-Adjusting Stack Machines 4

slide-5
SLIDE 5

Tractability Requires Dynamic Computations

Changing Input Compute Changing Output Read Changes Update Write Updates Static Case (Re-evaluation “from scratch”) compute 1 sec # of changes 1 million Total time 11.6 days Dynamic Case (Uses update mechanism) compute 10 sec update 1 × 10−3 sec # of changes 1 million Total time 16.7 minutes Speedup 1000x

Matthew A. Hammer Self-Adjusting Stack Machines 4

slide-6
SLIDE 6

Dynamic Computations can be Hand-Crafted

As an input sequence changes, maintain a sorted output. 1,7,3,6,5,2,4 Changing Input compute 1,2,3,4,5,6,7 Changing Output 1,7,3,6 /,5,2,4 Remove 6 update 1,2,3,4,5,6 /,7 1,7,3,6,5,2 /,4 Reinsert 6, Remove 2 update 1,2 /,3,4,5,6,7 A binary search tree would suffice here (e.g., a splay tree) What about more exotic/complex computations?

Matthew A. Hammer Self-Adjusting Stack Machines 5

slide-7
SLIDE 7

How to Program Dynamic Computations?

Can this programming be systematic? What are the right abstractions?

  • 1. How to describe dynamic computations?

◮ Usability: Are these descriptions easy to write? ◮ Generality: How much can they describe?

  • 2. How to implement these descriptions?

◮ Efficiency: Are updates faster than re-evaluation? ◮ Consistency: Do updates provide the correct result? Matthew A. Hammer Self-Adjusting Stack Machines 6

slide-8
SLIDE 8

In Self-Adjusting Computation, Ordinary programs describe dynamic computations. Self-Adjusting Program C Source Compiler C Target + Run-time The self-adjusting program:

  • 1. Computes initial output from initial input
  • 2. Automatically updates output when input changes

Matthew A. Hammer Self-Adjusting Stack Machines 7

slide-9
SLIDE 9

Self-Adjusting Programs

Input Read Compute Write Output Read Changes Trace Write Updates Update

◮ Self-adjusting program maintains dynamic

dependencies in an execution trace.

◮ Key Idea: Reusing traces efficient update

Matthew A. Hammer Self-Adjusting Stack Machines 8

slide-10
SLIDE 10

Challenges

Existing work targets functional languages:

◮ Library support for SML and Haskell ◮ DeltaML extends MLton SML compiler

Our work targets low-level languages (e.g., C)

◮ stack-based ◮ imperative ◮ no strong type system ◮ no automatic memory management

Matthew A. Hammer Self-Adjusting Stack Machines 9

slide-11
SLIDE 11

Challenges Low-Level Self-Adj. Computation

Efficient update complex resource interactions:

◮ execution trace, call stack, memory manager

Input Read Compute Write Output Read Changes Trace Write Updates Update

Matthew A. Hammer Self-Adjusting Stack Machines 10

slide-12
SLIDE 12

Challenges Low-Level Self-Adj. Computation

Efficient update complex resource interactions:

◮ execution trace, call stack, memory manager

Input Read Compute Write Output Read Changes Trace Write Updates Update

Matthew A. Hammer Self-Adjusting Stack Machines 10

slide-13
SLIDE 13

Challenges Low-Level Self-Adj. Computation

Efficient update complex resource interactions:

◮ execution trace, call stack, memory manager

code revaluation make new trace, search old trace

  • found change

found match change propagation repair + edit

  • ld trace
  • Matthew A. Hammer

Self-Adjusting Stack Machines 10

slide-14
SLIDE 14

Example: Dynamic Expression Trees

Objective: As tree changes, maintain its valuation

+ − + 3 4 − 5 6

((3 + 4) − 0) + (5 − 6) = 6

+ − + 3 4 + − 5 6 5

((3+4)−0)+((5−6)+5) = 11

Matthew A. Hammer Self-Adjusting Stack Machines 11

slide-15
SLIDE 15

Example: Dynamic Expression Trees

Objective: As tree changes, maintain its valuation

+ − + 3 4 − 5 6

((3 + 4) − 0) + (5 − 6) = 6

+ − + 3 4 + − 5 6 5

((3+4)−0)+((5−6)+5) = 11 Consistency: Output is correct valuation Efficiency: Update time is O(#affected intermediate results)

Matthew A. Hammer Self-Adjusting Stack Machines 11

slide-16
SLIDE 16

Expression Tree Evaluation in C

1 typedef struct node s* node t; 2 struct node s { 3 enum { LEAF, BINOP } tag; 4 union { int leaf; 5 struct { enum { PLUS, MINUS } op; 6 node t left, right; 7 } binop; 8 } u; } 1 int eval (node t root) { 2 if (root->tag == LEAF) 3 return root->u.leaf; 4 else { 5 int l = eval (root->u.binop.left); 6 int r = eval (root->u.binop.right); 7 if (root->u.binop.op == PLUS) return (l + r); 8 else return (l - r); 9 } }

Matthew A. Hammer Self-Adjusting Stack Machines 12

slide-17
SLIDE 17

The Stack “Shapes” the Computation

int eval (node t root) { if (root->tag == LEAF) return root->u.leaf; else { int l = eval (root->u.binop.left); int r = eval (root->u.binop.right); if (root->u.binop.op == PLUS) return (l + r); else return (l - r); } }

Stack usage breaks computation into three parts:

Matthew A. Hammer Self-Adjusting Stack Machines 13

slide-18
SLIDE 18

The Stack “Shapes” the Computation

int eval (node t root) { if (root->tag == LEAF) return root->u.leaf; else { int l = eval (root->u.binop.left); int r = eval (root->u.binop.right); if (root->u.binop.op == PLUS) return (l + r); else return (l - r); } }

Stack usage breaks computation into three parts:

◮ Part A: Return value if LEAF

Otherwise, evaluate BINOP, starting with left child

Matthew A. Hammer Self-Adjusting Stack Machines 13

slide-19
SLIDE 19

The Stack “Shapes” the Computation

int eval (node t root) { if (root->tag == LEAF) return root->u.leaf; else { int l = eval (root->u.binop.left); int r = eval (root->u.binop.right); if (root->u.binop.op == PLUS) return (l + r); else return (l - r); } }

Stack usage breaks computation into three parts:

◮ Part A: Return value if LEAF

Otherwise, evaluate BINOP, starting with left child

◮ Part B: Evaluate the right child

Matthew A. Hammer Self-Adjusting Stack Machines 13

slide-20
SLIDE 20

The Stack “Shapes” the Computation

int eval (node t root) { if (root->tag == LEAF) return root->u.leaf; else { int l = eval (root->u.binop.left); int r = eval (root->u.binop.right); if (root->u.binop.op == PLUS) return (l + r); else return (l - r); } }

Stack usage breaks computation into three parts:

◮ Part A: Return value if LEAF

Otherwise, evaluate BINOP, starting with left child

◮ Part B: Evaluate the right child ◮ Part C: Apply BINOP to intermediate results; return

Matthew A. Hammer Self-Adjusting Stack Machines 13

slide-21
SLIDE 21

Dynamic Execution Traces

Input Tree + − + 3 4 − 5 6 Execution Trace

A+ B+ C+ A− B− C− A− B− C− A+ B+ C+ A0 A5 A6 A3 A4

Matthew A. Hammer Self-Adjusting Stack Machines 14

slide-22
SLIDE 22

How to Update the Output?

Original Input + − + 3 4 − 5 6 Changed Input + − + 3 4 + − 5 6 5 Goals:

◮ Consistency: Respect the (static) program’s meaning ◮ Efficiency: Reuse original computation when possible

Matthew A. Hammer Self-Adjusting Stack Machines 15

slide-23
SLIDE 23

How to Update the Output?

Original Input + − + 3 4 − 5 6 Changed Input + − + 3 4 + − 5 6 5 Goals:

◮ Consistency: Respect the (static) program’s meaning ◮ Efficiency: Reuse original computation when possible

Idea: Transform the first trace into second trace

Matthew A. Hammer Self-Adjusting Stack Machines 15

slide-24
SLIDE 24

+ − + 3 4 + − 5 6 5 Unaffected/Reuse Affected/Re-eval New Evaluation Unaffected/Reuse Affected/Re-eval

A+ B+ C+ A− B− C− A+ B+ C+ A+ B+ C+ A0 A− B− C− A5 A3 A4 A5 A6

Matthew A. Hammer Self-Adjusting Stack Machines 16

slide-25
SLIDE 25

Before Update A+ B+ C+ A− B− C− A− B− C− A+ B+ C+ A0 A5 A6 A3 A4 After Update A+ B+ C+ A− B− C− A+ B+ C+ A+ B+ C+ A0 A− B− C− A5 A3 A4 A5 A6

Matthew A. Hammer Self-Adjusting Stack Machines 17

slide-26
SLIDE 26

How to Program Dynamic Computations?

  • 1. How to describe dynamic computations?

Usability: Are these descriptions easy to write? Generality: How much can they describe?

  • 2. How to implement this description?

? Correctness: Do updates provide the correct result? ? Efficiency: Are updates faster than re-evaluation?

Matthew A. Hammer Self-Adjusting Stack Machines 18

slide-27
SLIDE 27

Overview of Formal Semantics

◮ IL: Intermediate language for C-like programs ◮ IL has instructions for:

◮ Mutable memory: alloc, read, write ◮ Managing local state via a stack: push, pop ◮ Saving/restoring local state: memo, update Matthew A. Hammer Self-Adjusting Stack Machines 19

slide-28
SLIDE 28

Overview of Formal Semantics

◮ IL: Intermediate language for C-like programs ◮ IL has instructions for:

◮ Mutable memory: alloc, read, write ◮ Managing local state via a stack: push, pop ◮ Saving/restoring local state: memo, update

◮ Transition semantics: two abstract stack machines:

◮ Reference machine: defines “normal” semantics ◮ Tracing machine: defines self-adjusting semantics

Can compute an output and a trace Can update output/trace when memory changes Automatically marks garbage in memory

◮ We prove that these stack machines are consistent

Matthew A. Hammer Self-Adjusting Stack Machines 19

slide-29
SLIDE 29

Consistency theorem, Part 1: No Reuse

Trace Input Tracing Machine Run (P) Output

  • Input

Reference Machine Run (P) Output Tracing machine is consistent with reference machine (when tracing machine runs “from-scratch”, with no reuse)

Matthew A. Hammer Self-Adjusting Stack Machines 20

slide-30
SLIDE 30

Consistency theorem, Part 2: Reuse vs No Reuse

Trace0 Input Tracing Machine Run (P) Trace Output

  • Input

Tracing Machine Run (P) Trace Output Tracing machine is consistent with from-scratch runs (When it reuses some existing trace Trace0)

Matthew A. Hammer Self-Adjusting Stack Machines 21

slide-31
SLIDE 31

Consistency theorem: Main result

Trace0 Trace Input Tracing Machine Run (P) Output

  • Input

Reference Machine Run (P) Output Main result uses Part 1 and Part 2 together: Tracing machine is consistent with reference machine

Matthew A. Hammer Self-Adjusting Stack Machines 22

slide-32
SLIDE 32

How to Program Dynamic Computations?

  • 1. How to describe dynamic computations?

Usability: Are these descriptions easy to write? Generality: How much can they describe?

  • 2. How to implement this description?

Correctness: Do updates provide the correct result? ? Efficiency: Are updates faster than re-evaluation?

Matthew A. Hammer Self-Adjusting Stack Machines 23

slide-33
SLIDE 33

Overview of Our Implementation

CEAL Compiler C Translate IL Transform IL Translate C + RT

◮ Compiler: produces C targets from C-like source code ◮ Run-time: maintains traces, performs efficient updates

Matthew A. Hammer Self-Adjusting Stack Machines 24

slide-34
SLIDE 34

Dynamic Expression Trees: From-Scratch Time

0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 250K 500K 750K Time (s) Input Size Exptrees From-Scratch Self-Adj Static

Matthew A. Hammer Self-Adjusting Stack Machines 25

slide-35
SLIDE 35

Dynamic Expression Trees: Ave Update Time

0.011 0.012 0.013 0.014 0.015 0.016 0.017 0.018 0.019 0.020 0.021 0.022 250K 500K 750K Time (ms) Input Size Exptrees Ave Update Self-Adj

Matthew A. Hammer Self-Adjusting Stack Machines 26

slide-36
SLIDE 36

Dynamic Expression Trees: Speed up

0.0 x 100 5.0 x 103 1.0 x 104 1.5 x 104 2.0 x 104 2.5 x 104 250K 500K 750K Speedup Input Size Exptrees Speedup Self-Adj

Matthew A. Hammer Self-Adjusting Stack Machines 27

slide-37
SLIDE 37

Summary of Empirical Results

Benchmark N Initial Overhead Speed-up (Compute / Static) (Static / Update) exptrees 106 8.5 1.4 × 104 map 106 18.4 3.0 × 104 reverse 106 18.4 3.8 × 104 filter 106 10.7 4.9 × 104 sum 106 9.6 1.5 × 103 minimum 106 7.7 1.4 × 104 quicksort 105 8.2 6.9 × 102 mergesort 105 7.2 7.8 × 102 quickhull 105 3.7 2.2 × 103 diameter 105 3.4 1.8 × 103 distance 105 3.4 7.9 × 102

Matthew A. Hammer Self-Adjusting Stack Machines 28

slide-38
SLIDE 38

Our Contributions

A consistent self-adjusting semantics for low-level programs

Matthew A. Hammer Self-Adjusting Stack Machines 29

slide-39
SLIDE 39

Our Contributions

A consistent self-adjusting semantics for low-level programs Our abstract machine semantics

◮ Describes trace editing & memory management

implementation of run-time system

◮ But requires programs with a particular structure

implementation of compiler transformations

Matthew A. Hammer Self-Adjusting Stack Machines 29

slide-40
SLIDE 40

Our Contributions

A consistent self-adjusting semantics for low-level programs Our abstract machine semantics

◮ Describes trace editing & memory management

implementation of run-time system

◮ But requires programs with a particular structure

implementation of compiler transformations Our intermediate language is low-level, yet abstract

◮ orthogonal annotations for self-adjusting behavior ◮ no type system needed

implementation of C front end

Matthew A. Hammer Self-Adjusting Stack Machines 29

slide-41
SLIDE 41

Thank You! Questions?

Self-adjusting computation is a language-based technique to derive dynamic programs from static programs. Summary of contributions:

◮ A self-adjusting semantics for low-level programs.

This semantics defines self-adjusting stack machines.

◮ A compiler and run-time that implement the semantics. ◮ A front end that embeds much of C.

Matthew A. Hammer Self-Adjusting Stack Machines 30
