RiversideBoulevardandWest68thStreetRamp May21,2012 - - PowerPoint PPT Presentation

Riverside
Boulevard
and
West
68th
Street
Ramp
 May
21,
2012


Jimmy
Zuehl,
Architectural
Specialist
 Accessibility
Services
(United
Spinal
Association)
 718.803.3782,
Extension7505
 Email:
jzuehl@accessibility‐services.com


• Private,
National
Not

for
Profit



Organization


• Established
in
1946

as

Eastern


Paralyzed


Veterans

Association


• Most

members

have

a

spinal



cord
injury
or
disease


• Name
changed
in
January
2004

• Headquarters

in

Queens,


NY


www.unitedspinal.org


• Provides

Accessibility

Training


Programs


• Offers


Plan


Review


Services

• Engineering

and

Architectural


Consulting


• Site
Assessment
and
Reporting


• 3rd
Party
Inspections


www.accessibility‐services.com


Why
Is
Accessibility
Important?


Why
Is
Accessibility
Important?


• Under
the
ADA,
a
person
with
a
disability
is
a
person
who:



‐Has
a
physical
or
mental
impairment
that
substantially
limits
one
or



more
major
life
activities.

‐Has
a
record
of
such
an
impairment.

‐Is
regarded
as
having
such
an
impairment.



Why
Is
Accessibility
Important?


• 1
in
5
Americans
have
a
disability

• The
disability
population
is
growing
due
to
aging,
war,
and


identification.


• The
disabled
population
is
the
largest
minority
group
in
our
country.


Why
Is
Accessibility
Important?


• Accessibility
does
not
always
only
benefit
wheelchair
users.



‐People
who
are
blind
‐Limits
of
Protruding
Objects
and
Braille
Signage.

‐People
who
are
Deaf

‐Visible
Appliances
(strobes).

‐People
of
short
stature
‐Heights
of
Operable
Parts
and
Controls.

‐People
using
crutches
or
walking
aids
–Grab
bars
and
Handrails.


Requirements


Accessible
Walking
Surface,
General

‐Elements
of
an
Accessible
Walking
Surface:


• Firm,
stable,
slip
resistant
surfaces.

• Slope
may
not
exceed
5%
(1:20)
for
walking
surfaces;
cross
slope








may
not
exceed
1:48
(2%).



• No
changes
in
level
greater
than
¼
inch
vertical
or
½
inch
beveled.

• Minimum
36
inch
clear
width.

• Passing
space
at
least
5’X5’
minimum
provided
every
200’,
if
less


than
60”
of
clear
width
is
provided

along
an
accessible
route.


• Minimum
80
inches
of
head
room
with
out
protruding
objects.


Accessible
Walking
Surface,
Changes
in
Elevation


Accessible
Walking
Surface,
Clear
Width


Accessible
Walking
Surface,
Limits
of
Protruding
Objects


Accessible
Ramps,
General

‐Elements
of
an
Accessible
Ramp:


• Firm,
stable,
slip
resistant
surfaces.

• Slope
may
not
exceed
8.33%
(1:12)
for
ramps;
cross
slope








may
not
exceed
1:48
(2%).



• Clear
width
of
any
ramp
run
shall
be
36”
minimum
between


handrails
(when
provided).


• The
rise
for
a
ramp
run
shall
be
no
more
than
30”.

• Ramps
shall
have
Landings
at
both
the
top
and
bottom.

• Ramp
runs
with
a
rise
greater
than
6”
shall
have
Handrails
on


both
sides
of
the
ramp.


• Edge
Protection
is
required
on
both
sides
of
the
ramp.


Accessible
Ramps,
Landings

‐Landing
shall
be
level
and
not
slope
more
than
1:48
(2%)
in
any



direction.

‐Landings
shall
be
minimum
60
inches
deep
and
at
least
as
wide
as
the



ramp.


Accessible
Ramps,
Handrails


Accessible
Ramps,
Handrails
(cont.)


Accessible
Ramps,
Edge
Protection


Ramp
Inspection:
Friday,
April
13,
2012


Accessible
Ramps,
Slopes
and
Cross
Slopes

‐Slope
may
not
exceed
8.33%
(1:12)
for
ramps;
cross
slope
may
not



exceed
1:48
(2%).


‐Slopes
in
excess
of
1:12
(8.33%)
were
measured
at
all
ramp
segments.


‐Much
of
the
ramp
had
cross
slopes
in
excess
of
1:48
(2%).



Average
Slopes















(Max
Slope):



Segment
#01:
8.04%

(9.00%)



Segment
#02:
8.33%

(9.60%)



Segment
#03:
8.07%

(9.20%)



Segment
#04:
6.87%

(9.60%)



Segment
#05:
8.24%

(11.8%)



Segment
#06:
8.61%

(9.00%)



Segment
#07:
11.6%

(21.4%)



Segment
#08:
7.57%

(9.30%)



Segment
#09:
7.39%

(8.70%)



Segment
#10:
7.45%

(8.80%)



Segment
#11:
4.20%

(6.70%)


Accessible
Ramps,
Slopes
and
Cross
Slopes

‐The
slope
of
a
ramp
is
important
for
a
person
in
a
wheelchair
going
 both
up
and
down
the
ramp.


‐Too
steep
of
a
slope
going
down
the
ramp
could
result
in
a
wheelchair
 user
losing
control.
This
could
lead
to
an
uncontrolled
descent.


‐Too
steep
of
a
slope
going
up
the
ramp
could
limit
wheelchair
users
 from
even
using
the
route.
Many
people
with
mobility
disabilities
have
 limited
strength
to
overcome
changes
in
elevation.


‐Users
with
or
without
disabilities
benefit
from
having
ramps
that
 comply
with
the
accessibility
standards,
including
bicycle
riders
and
 parents
pushing
baby
strollers.

 ‐The
steepness
of
a
ramp
will
either
encourage
or
discourage
use
of
a
 route.


Accessible
Ramps,
Landings,
Slope

‐Landing
shall
be
level
and
not
slope
more
than
1:48
(2%)
in
any



direction.

‐All
intermediate
landings
where
not
level.




Max
Slope





Segment
#01,
top:







2.33%




Segment
#01,
bottom:
2.70%




Segment
#02,
bottom:
3.33%




Segment
#03,
bottom:
2.60%




Segment
#04,
bottom:
5.00%




Segment
#05,
top:







4.50%




Segment
#05,
bottom:
3.60%




Segment
#06,
bottom:
2.60%




Segment
#07,
bottom:
5.80%



Segment
#08,
bottom:
4.90%



Segment
#09,
bottom:
2.20%



Segment
#10,
bottom:
2.20%


Segment
#11,
bottom:
2.50%


Accessible
Ramps,
Landings,
Size

‐Landing
shall
be
level
and
not
slope
more
than
1:48
(2%)
in
any



direction.

‐Watch
out
for
the
electrical
outlets
and
cobblestone.


Accessible
Ramps,
Landings,
Size

‐Landings
shall
be
minimum
60
inches
deep
and
at
least
as
wide
as
the



ramp.

‐All
intermediate
landings
had
lengths
measuring
less
than
60
inches.




Length


Segment
#01,
top:







(+/‐
6
feet)


Segment
#01,
bottom:
(+/‐
4
feet)


Segment
#02,
bottom:
(+/‐
4
feet)


Segment
#03,
bottom:
(+/‐
4
feet)


Segment
#04,
bottom:
(+/‐
5
feet)


Segment
#05,
top:







(+/‐
5
feet)


Segment
#05,
bottom:
(+/‐
4
feet)


Segment
#06,
bottom:
(+/‐
4
feet)


Segment
#07,
bottom:
(+/‐
4
feet)


Segment
#08,
bottom:
(+/‐
4
feet)


Segment
#09,
bottom:
(+/‐
4
feet)


Segment
#10,
bottom:
(+/‐
4
feet)


Segment
#11,
bottom:
(+/‐
6
feet)


Accessible
Ramps,
Landings,
Slope

‐Landings
are
important
because
they
provide
rest
between
ramp
 segments
and
they
provide
an
opportunity
to
turn
around.


‐Rest
and
turn
around
space
is
beneficial
for
all
users,
not
just
users
in
 wheelchairs.


Accessible
Ramps,
Landings,
Size

‐No
changes
in
level
greater
than
¼
inch
vertical
or
½
inch
beveled.

‐Concrete
strips
at
the
tops
and
bottoms
of
ramp
segments
have



changes
in
level
greater
than
1/4
inch
vertical
and
1/2
inch
beveled.


Accessible
Ramps,
Landings,
Size

‐Wheelchair
users
are
unable
to
overcome
such
changes
in
elevations

‐Changes
in
elevation
can
be
tripping
hazards
for
fully
mobile
users
of



the
ramp.



New
Ramp
Proposals


New
Ramp
Proposals,
Option
1

‐Zigzag
ramp
adjacent
to
the
stairs.


New
Ramp
Proposals,
Option
2

‐Jogged
ramp
over
existing
ramp.


New
Ramp
Proposals,
Option
3

‐Straight
ramp
over
existing
ramp.
