SR 874 Ramp Connector Project Development & Environment (PD&E) Study

“Moving Miami-Dade”

MDX Contract #: RFP-09-04 MDX Work Program #: 87410.011 ETDM #: 11501

Kick-off Meeting

2

Project Development & Environment Study

• Develop and evaluate engineering and environmentally feasible

alternative solutions that meet the need determined in the Planning Phase.

• Evaluate potential impacts to the social, natural and physical

environments and determine ways to avoid or minimize impacts.

• Inform and involve the public in the development of the project.
• This process is mandated by the National Environment Policy Act

(NEPA) and state law. It represents a combined effort by technical professionals who analyze information and document the best alternative for a community’s transportation needs.

3

Project Life Cycle

4

4

Project Development & Environment Study

5

Project Description

SR 874

• Urban Principal

Arterial Expressway

• Approximately 7.2

miles

• Posted Speed Limit

55mph

• Hurricane Evacuation

Route

• Part of SIS/FIHS
• Proposes a new

ramp connection between the existing SR 874 at the HEFT with SW 136th St

6

Corridor Characteristics

Part of the Florida Intrastate Highway System (FIHS) Part of the Strategic Intermodal System (SIS)

• Develops and maintains the network of

highways that combined make up the intrastate system

• Composed of interconnected limited and

controlled-access roadways including interstate highways and Florida’s Turnpike system

• System of transportation facilities of statewide

and interregional significance

• Focused on the efficient movement of

passengers and freight

• Carries 68% of all truck traffic and 29% of all

traffic This project is included in the Miami-Dade County 2035 Long Range Transportation Plan and in the Miami-Dade Comprehensive Development Master Plan

7

Purpose and Need

1. Social Demand and Economic Development 2. System Connectivity 3. Capacity 4. Evacuation Route/ Emergency Services

8

Purpose and Need

Social Demand and Economic Development

• The study area is one of the fastest growing most densely populated communities in the state with

limited expressway access

• Population and jobs are anticipated to increase by 104% and 37%, respectively by 2035
• Improvements to the Kendall-Tamiami Executive Airport and near by supporting land-uses such as

new tourist developments anticipated for Miami MetroZoo, schools, community and shopping centers will increase traffic congestion in the area

• Growth in industrial and flex-space

activities in the area are largely dependent upon expressway access

9

Purpose and Need

System Connectivity

• SR 874 provides a southwest to

northeast connection from the HEFT to the Palmetto Expressway (SR 826)

• The proposed connector would

provide an alternate travel route, relieving congestion at the HEFT/SW 120 St and SW 152 St interchanges

• The new facility would provide

local traffic a more direct route to the centers of employment in the County (i.e. Downtown Miami and Miami International Airport)

10

Purpose and Need

Capacity

• SW 120 St and SW

152 St are the only corridors in the area with access to the expressway system

• SW 120 St and SW

152 St and their interchanges with the HEFT are currently

• perating over

capacity

• Expressways in the

area are currently heavily congested

11

Purpose and Need

Evacuation Route/ Emergency services

• The lower southeast Florida Region has been identified by

the National Oceanic Atmospheric Administration (NOAA) as one of the most hurricane vulnerable areas in the United States

• HEFT is one of three continuous north-south corridors

along with Krome Avenue to the west and US 1 to the east and thus serves as a critical evacuation route

• The SR 874/Don Shula Expressway facilitates access to
• ther critical north-south facilities (i.e. SR 826/Palmetto

Expressway, US-1, I-95)

• This project would provide an additional connection to the

SR 874 facility and expedite the mobility at the HEFT interchanges decreasing evacuation time

12

Corridor Constraints

• Tamiami Complex

Pineland Preserve and Nixon Smiley Pineland Preserve

• Multiple Residential

neighborhoods

• Existing and

proposed FP&L lines

• CSX Railroad
• FP&L Davis

Substation

• Proposed HEFT

improvements

• Kendall Tamiami

Executive Airport – FAA compliance

TAMIAMI COMPLEX PINELAND PRESERVE BONITA LAKES DAVIS SUBSTATION CSX RR GPC SPUR

VENEZIA LAKES NIXON SMILEY PINELAND PRESERVE KENDALL TAMIAMI EXECUTIVE AIRPORT

13

Key Project Components

• Public Involvement
• Engineering
• Corridor Analysis
• Traffic Analysis
• Issues
• Environmental
• Coordination

14

Public Involvement

15

Public Involvement

Community Involvement

• Identify Key Stakeholders, businesses, etc.
• Meetings:

– Fact sheets – Newsletters – Project website – Public meetings – Preparing responses to inquiries – Agency/Elected Officials Kick-off Meeting – Public Kick-off Meeting – County Commissioners Presentation – Public Alternatives Workshop – Public Hearing

• Ways of engaging the community:

16

Public Involvement

Public Outreach Program

• A Public Outreach Program was conducted as a part of the SR 874

Connector Project Concept Study (June, 2008)

• A total of 41 community groups in the area were incorporated in the study
• Public Concerns included:
• Height of ramp
• Aesthetics
• Tolls
• Lighting
• Noise from ramps
• Noise walls
• Future ramp connection to turnpike
• Level of service of surrounding streets
• Issues identified by environmental agencies

17

Engineering

Alternative Selection Process

18

Engineering

Corridor Analysis

Preferred alternative from the SR 874 Connector Report was later found to be unfeasible due to impacts to Pineland Preserve Corridors B, C, D, & E commence at the intersection

• f

SW 136/SW 137 Ave and traverse in part along SW 136 St Corridors A & D would require additional R/W along SW 128 St. This corridor has warehouses abutting the roadway as well as a dedicated nature preserve Corridor C would partially traverse over the CSX railroad and is in very close proximity to both the Bonita Lakes housing development and the Pineland Preserve. Corridors B & E would either infringe

• n

the existing FPL easement and thus conflict with the planned expansion

• f

the transmission lines and/or impact numerous existing warehouses Corridors A&D would require a modification to the planned HEFT interchange in order to accommodate the new ramps

Avoid impacts to:

• Pineland Preserves
• FP&L
• Residences
• Proposed HEFT

improvements

19

Engineering

Traffic Analysis

• Perform Data Collection
• Traffic Analysis Years:
• Opening: 2017
• Interim: 2027
• Design: 2037
• Determine traffic

improvements/ impacts of proposed facility on existing street grid

• Determine any additional

improvement that may be required

• Requires the Preparation of

an Interchange Modification Report (IMR)

• Requires FDOT review

(FIHS/ SIS facility)

20

Issues

• Intersection Impacts
• Drainage/ Stormwater treatment
• Retention ponds within bridge footprint
• Potential Joint Use Pond Agreement with

Venezia Lakes residential development

• FAA approach surface compliance for the

Kendall Tamiami Executive Airport

• Minimize right-of-way
• Develop necessary horizontal and vertical

alignments to avoid or minimize impacts to a multitude of project constraints

Engineering

21

• Direct Effects
• Natural Issues
• Physical Issues
• Socio-Economic Issues
• Cultural Issues
• Indirect & Cumulative Effects (ICE)
• Indirect (or secondary)
• Cumulative (actions by others)

Environmental

22

Physical Issues

• Noise Impacts - Numerous noise

sensitive receptors

• Multiple noise sensitive sites

along project corridor

• Air Quality - Improvements that

reduce congestion also reduce air quality impacts

Environmental

Cultural Issues

• Historic Structures and Districts - No

historical sites identified

• Archaeological Analysis
• Performing Cultural Resource

Assessment Survey (CRAS)

23

Natural Issues

• Floodplains
• Site within 100 year flood

plain

• Special Designations
• Wildlife and Habitat
• 26-acre Tamiami Pineland

Complex- part of Dade County Archipelago Florida Forever Project

• Recreation Areas
• Section 4(f) Potential
• Aesthetics
• Secondary and Cumulative

Environmental

Seven (7) issues of Substantial degree were identified within the project area including

24

Possible Permits

• Army Corps of Engineers (ACOE)

– Dredge Fill Permit

• SFWMD

– Environmental Resource Permit (ERP)

• MD Department of Environmental Resources

Management (DERM)

– Class II

• Right-of-Way Occupancy Permit

– To work within and over CSX right-of-way

Environmental

25

• On-going/Planned Developments
• Miami-Dade County
• Florida Department of Transportation ( FDOT)
• Florida Turnpike Enterprise (FTE)
• Miami Dade Public Works (MDPW)
• Miami Dade Transit (MDT)
• Florida Highway Administration (FHWA)
• Florida Department of Environmental

Protection (FDEP)

• South Florida Water Management District

(SFWMD)

• Florida Power & Light (FPL)
• CSX Transportation (CSX)
• Federal Aviation Administration (FAA)

Coordination

26

Collaborative Effort

27

PROJECT SCHEDULE

Next Steps

• Final Design: 2011-2013
• Right-of-Way: 2013-2015
• Construction: 2015-2017

28

More Information

If you would like to learn more about this study, please contact:

• Ms. Tere Garcia

Public Information Officer Phone: (305) 860-3758 Cell: (786) 277-9292 Fax: (305) 860-3759 E-mail: Tgarcia@bermelloajamil.com
