John Finley Walk ADA Ramps

Located at East 82nd and East 83rd Streets, John Finley Walk Borough of Manhattan Community Board 8 Presentation May 3, 2017 Parks Capital Design

GOALS

• Provide disabled accessibility to the John Finley Walk with ADA ramps at East

82nd and East 83rd Streets (Locations 1 and 2)

• Pre-fabricated Black Powder Coated Galvanized Steel (Heavy Duty)
• Location 1 with 33 LF of ramp with 2.0’ grade change
• Location 2 with 26 LF of ramp with 2.0’ grade change
• Bracket Arms on Metal Decking

CONSTRAINTS

• 3’- 6” ADA Clearance on ramp at 8% slope
• One landing for every turn
• 5’ minimum DOT sidewalk clearance
• Clear access to private doors, yard gates, FDR Drive vents, underground utilities

(manholes, vaults) and FDNY facilities TOTAL BUDGET: $100,000 (Mayoral Funded transfer from DDC 81st Street Pedestrian Bridge) FY 2017 PROJECT SIZE: 1,134.24 SF

• Location 1 - 954 SF
• Location 2 - 180 SF

ADA Ramps at East 82nd and East 83rd Streets |

2

Goals

Neighborhood Location Sites

NTS

Upper East Side East River John Finley Walk Locations East River Harlem River Roosevelt Island

Manhattan

East 82nd Street N N East 83rd Street East End Avenue

Carl Schurz Park Location 1 Location 2

0’ 30’ 60’ 120’

3

ADA Ramps at East 82nd and East 83rd Streets | Site Locations

FLOOD HAZARD ZONES

ZONE X - Moderate risk areas within the 0.2% annual-chance fmoodplain. VE - Areas along coasts subject to inundation by the 1% annual-chance fmood event with additional hazards associated with storm- induced velocity wave action. BFE exists. ZONE A - 1% annual-chance fmood event. No Base Flood Elevation (BFE) exists. ZONE AE - 1% annual-chance fmood event. BFE exists. ZONE AO - 1% annual-chance shallow fmooding. FLOODWAY - watercourse reserved to discharge base fmood. LIMIT OF MODERATE WAVE ACTION Base Flood Elevation (BFE) = 14’

LOCATIONS

N 0’ 180’ 360’

East River

4

ADA Ramps at East 82nd and East 83rd Streets | Flood Risk

LAND USE CATEGORIES

COMMERCIAL MULTI-FAMILY RESIDENTIAL INSTITUTIONAL MIXED USE INDUSTRIAL TRANSPORTATION / UTILITIES OPEN SPACE AND OUTDOOR RECREATION PARKING VACANT LOTS 1 AND 2 FAMILY RESIDENTIAL

Location 1 East 82nd Street East 83rd Street East 84th Street Carl Schurz Park Location 2

East River

N

5

ADA Ramps at East 82nd and East 83rd Streets | Surrounding Land Use

Site Photo 1 - Looking southeast fron East 82nd Street at the East River Esplanade

Drainage Grate Street Light FDNY Standpipe Exterior Door Exterior Door Former Non- Compliant ADA Ramp John Finley Walk

East 82nd Street

Sidewalk “Poor Condition”

Key Map

N 1 East 82nd St.

Tree with Tree Guard Tree with Tree Guard FDR Drive Vent

John Finley Walk

ADA Ramps at East 82nd and East 83rd Streets |

6

Location 1 Site Photos - (E 82nd St.)

Concrete Sidewalk “Poor Condition” FRD Drive Vent FRD Drive Vent

E a s t 8 2 n d S t r e e t

East 82nd Street Step Ramp FDNY Standpipe

Legend

Pedestrian Access Street Light Esplanade Lightpole Building or Structure

Building with wall mounted lights

Concrete Sidewalk ``` Tree Pit with Plant Guard Vent Cover Drain Inlet Water Valve Manhole

Step Ramp Location N

Concrete Sidewalk Tree Pit with Plant Guard Door Entry Gate Gate Door Entry

John Finley Walk

7

ADA Ramps at East 82nd and East 83rd Streets | Location 1 Existing Conditions

Site Photo 3 - Looking northwest at East 82nd Street sidewalk, ADA ramp and FDR Drive vent (right)

Site Photo 2 - Looking souteast at step ramp, ADA ramp, FDR Drive vent (right) and John Finley Walk

Key Map

N 2 3 East 82nd St. John Finley Walk

ADA Ramps at East 82nd and East 83rd Streets |

8

Location 1 Site Photos - (E 82nd St.)

Concrete Sidewalk FRD Drive Vent FRD Drive Vent

East 83rd Street

East 83rd Street Step Ramp

Legend

Pedestrian Access Street Light Step Ramp Location Esplanade Lightpole Building or Structure Concrete Sidewalk Concrete Curb (Typ.) Bike Rack Vent Cover Sewer Manhole Sewer Manholes DEP Manhole Drain Inlet

Building

N 0’ 5’ 10’ 20’

J

• h

n F i n l e y W a l k

9

A D A R a m p s a t E a s t 8 2 n d a n d E a s t 8 3 r d S t r e e t s | L

• c

a t i

• n

2 E x i s t i n g C

• n

d i t i

• n

s

• (

E 8 3 r d S t . )

Site Photo 2 - Looking northwest at East 83rd Street, FDR vents and East 83rd Street sidewalk

Site Photo 1 - Looking soutwest at step ramp, FDR Drive vents and East 83rd Street

Key Map

N 2 1 J

• h

n F i n l e y W a l k East 83rd St.

ADA Ramps at East 82nd and East 83rd Streets |

10

Location 2 Site Photos - (E 83rd St.)

Site Photo 3 - Looking northeast at step ramp and FDR Drive vents Site Photo 4 - Looking northeast at step ramp and John Finley Walk

Key Map

N 4 3 East 83rd St. J

• h

n F i n l e y W a l k

ADA Ramps at East 82nd and East 83rd Streets |

11

Location 2 Site Photos - (E 83rd St.)

New Concrete Sidewalk

East 82nd Street John Finley Walk

FDNY Standpipe

Legend

Pedestrian Access Street Light Esplanade Lightpole Building or Structure

Concrete Sidewalk New Concrete Curb Concrete Sidewalk Adjusted Vent Cover Drain Inlet Water Valve Adjusted Manhole Cover

New Concrete Sidewalk

Building with wall mounted lights New Concrete Sidewalk

Step Ramp Location ADA Ramp N 0’ 5’ 10’ 20’

Door Entry Door Entry Gate Gate Tree Pit with Guard Tree Pit with Guard Ramp Railing Diversion

Ramp View From East 82nd Street 12

ADA Ramps at East 82nd and East 83rd Streets | Location 1 Option 2 - (E 82nd St.)

Section-Elevation A-A Section-Elevation B-B Key Map

B-B A-A N East 82nd St. John Finley Walk

13

ADA Ramps at East 82nd and East 83rd Streets | Location 1 Section Elevations - (E 82nd St.)

East 83rd Street

Legend

Pedestrian Access Street Light Esplanade Lightpole Building or Structure Concrete Sidewalk Concrete Sidewalk New Concrete Sidewalk

Building

Step Ramp Location ADA Ramp N 0’ 5’ 10’ 20’

John Finley Walk

14

ADA Ramps at East 82nd and East 83rd Streets | Location 2 Proposed Plan - (E 83rd St.)

Section-Elevation C-C Section-Elevation D-D Key Map

D-D C-C N East 83rd St. J

• h

n F i n l e y W a l k

15

ADA Ramps at East 82nd and East 83rd Streets | Location 2 Section Elevations - (E 83rd St.)

Railing Posts without Bracket Arms Railings with Bracket Arms Metal Ramps

ADA Ramps at East 82nd and East 83rd Streets |

16

Proposed Features
