Having our roots throughout North America gives Nation Ramps clients the flexibility they deserve. Nation Ramps has the capability to deliver our ramps anywhere in North America at some of the most competitive rates, thanks to being a subsidiary

SLIDE 1

SLIDE 2

1-877-780-2288 | sales@nationramps.com Nation Ramps leads the industry by creating win/win solutions for our customers and

associates. Through honesty and integrity we build long term relations by exceeding

expectations. Having our roots throughout North America gives Nation Ramps clients the flexibility they deserve. Nation Ramps has the capability to deliver our ramps anywhere in North America at some of the most competitive rates, thanks to being a subsidiary to industry-leading T-Lane Transportation. BUY | RENT | LEASE | USED with Nation Ramps, today.

SLIDE 3

RENTALS

Nation Ramp rentals has the ability to deliver & set up
ur rental ramps anywhere in North
America. With
ur large rental fleet, we can offer next day delivery

to almost any location.

Whether your project requirements span one day or
ne year, we have you covered. If you happen to like
ur Nation Ramps Nation ramp so much by the end of

your rental term we can offer a purchase plan as well. We will offer to give you a portion of your rental fees back to put towards the sale price. BUY | RENT | LEASE | USED

NATION RAMP RENTALS

1-877-780-2288 | sales@nationramps.com

SLIDE 4

PRODUCT LINE

1-877-780-2288 | sales@nationramps.com

SLIDE 5

GROUND TO DOCK RAMP

MODEL LENGTH (FEET) WIDTH (INCHES) USABLE WIDTH (INCHES) CAPACITY (GVW) HEIGHT 12" SAFETY RUB RAILS MOUNTING BRACKETS GTD16k-27×102-S

26.5 FT 102 IN 97 IN 16,000 LBS PER REQUEST INCLUDED OPTIONAL

GTD16k-27×120-S

26.5 FT 120 IN 115 IN 16,000 LBS PER REQUEST INCLUDED OPTIONAL GTD18k-27×77-S 26.5 FT 77 IN 72 IN 18,000 LBS PER REQUEST INCLUDED OPTIONAL GTD18k-27×96-S 26.5 FT 95.25 IN 90 IN 18,000 LBS PER REQUEST INCLUDED OPTIONAL

GTD20K-27x102-S

26.5 FT 102 IN 97 IN 20,000 LBS PER REQUEST INCLUDED OPTIONAL

GTD20K-27x120-S

26.5 FT 120 IN 115 IN 20,000 LBS PER REQUEST INCLUDED OPTIONAL

GTD30k-27×102-S

26.5 FT 102 IN 97 IN 30,000 LBS PER REQUEST INCLUDED OPTIONAL

GTD30k-27×120-S

26.5 FT 120 IN 115 IN 30,000 LBS PER REQUEST INCLUDED OPTIONAL

1-877-780-2288 | sales@nationramps.com

The Ground to Dock ramp design allows for forklifts, vehicles and personnel to travel with ease from ground (grade) level up to warehouse dock high levels.

SLIDE 6

EQUIPMENT LOADING RAMP

MODEL LENGTH (FEET) WIDTH (INCHES) USABLE WIDTH (INCHES) CAPACITY (GVW) HEIGHT 12" SAFETY RUB RAILS

EQP30k-27×120-46A

27 FT 120 IN 115 IN 30,000 LBS ADJUSTABLE 38" TO 55" INCLUDED

EQP50k-27×120-46A

27 FT 120 IN 115 IN 50,000 LBS ADJUSTABLE 38" TO 55" INCLUDED

1-877-780-2288 | sales@nationramps.com

The standalone equipment loading ramp is designed for heavy duty equipment loading. Excavators, tractors, forklifts, scissors lifts, vehicles

etc. can be loaded with ease from

ground level up to low bed, step deck, flatbed, railcar, or van trailers.

BUY | RENT | LEASE | USED

SLIDE 7

The standalone Portable Loading Dock Ramp is designed for forklifts to load or off-load product from tractor trailer, container

r rail cars.

This one heavy duty piece ramp and platform combo allows for the forklift to completely level off before entering the trailer.

MODEL LENGTH (FEET) PLATFORM LENGTH (FEET) WIDTH (INCHES) USABLE WIDTH (INCHES) CAPACITY (GVW) HEIGHT 12" SAFETY RUB RAILS PLD18k-34×77-50A 26.5 FT 7.5 FT 77 IN 72 IN 18,000 LBS ADJUSTABLE 41” TO 60” INCLUDED PLD18k-34×96-50A 26.5 FT 7.5 FT 96 IN 90 IN 18,000 LBS ADJUSTABLE 41” TO 60” INCLUDED

PLD22k-34×102-50A

26.5 FT 7.5 FT 102 IN 97 IN 22,000 LBS ADJUSTABLE 41" TO 60" INCLUDED

PLD22k-34×120-50A

26.5 FT 7.5 FT 120 IN 115 IN 22,000 LBS ADJUSTABLE 41" TO 60" INCLUDED

PLD33k-34×102-50A

26.5 FT 7.5 FT 102 IN 97 IN 33,500 LBS ADJUSTABLE 41" TO 60" INCLUDED

PLD33k-34×120-50A

26.5 FT 7.5 FT 120 IN 115 IN 33,500 LBS ADJUSTABLE 41" TO 60" INCLUDED

1-877-780-2288 | sales@nationramps.com

PORTABLE LOADING DOCK

SLIDE 8

MOBILE YARD RAMP

The standalone Mobile Yard Ramp is designed for forklifts to load or off-load product from tractor trailer, container or rail cars. This one piece heavy duty ramp and platform combo allows for the forklift to completely level off before entering the trailer. It also has the capability to be towed via forklift. With its design including wheels and forklift fork adaptor, this mobile ramp can be easily moved from trailer to trailer or stowed away at the end of the workday.

MODEL LENGTH (FEET) PLATFORM LENGTH (FEET) WIDTH (INCHES) USABLE WIDTH (INCHES) CAPACITY (GVW) HEIGHT 12" SAFETY RUB RAILS MYR18k-34×96-50A 26.5 FT 7.5 FT 96 IN 90 IN 18,000 LBS ADJUSTABLE 41” TO 60” INCLUDED MYR22k-34×102-50A 26.5 FT 7.5 FT 102 IN 97 IN 22,000 LBS ADJUSTABLE 41" TO 60" INCLUDED MYR22k-34×120-50A 26.5 FT 7.5 FT 120 IN 115 IN 22,000 LBS ADJUSTABLE 41" TO 60" INCLUDED MYR33k-34×102-50A 26.5 FT 7.5 FT 102 IN 97 IN 33,500 LBS ADJUSTABLE 41” TO 60” INCLUDED MYR33k-34×120-50A 26.-5 FT 7.5 FT 120 IN 115 IN 33,500 LBS ADJUSTABLE 41” TO 60” INCLUDED

1-877-780-2288 | sales@nationramps.com

SLIDE 9

1-877-780-2288 | sales@nationramps.com

STANDALONE PLATFORM

The standalone Portable Platform is designed to be added onto any of our portable loading docks. This addition will give you the ability to completely level off with the largest of crates or pallets before the forklift and product start the decline down the ramp. These platforms can also be used to create a multiple truck unloading platform for crossdocking purposes.

MODEL LENGTH (FEET) PLATFORM WIDTH (INCHES) PLATFORM USABLE WIDTH (INCHES) PLATFORM CAPACITY (GVW) PLATFORM HEIGHT 12" SAFETY RUB RAILS

SAP16k-8×102-48A

8 FT 102 IN 97 IN 16,000 LBS ADJUSTABLE 37" TO 60" INCLUDED

SAP16k-08×120-48A 8 FT

120 IN 115 IN 16,000 LBS ADJUSTABLE 37" TO 60" INCLUDED

SAP16k-16×102-48A

16 FT 102 IN 97 IN 16, 000 LBS ADJUSTABLE 37" TO 60" INCLUDED

SAP16k-16×120-48A

16 FT 120 IN 115 IN 16, 000 LBS ADJUSTABLE 37" TO 60" INCLUDED

SAP30k-8×102-48A

8 FT 102 IN 97 IN 30, 000 LBS ADJUSTABLE 37" TO 60" INCLUDED

SAP30k-08×120-48A 8 FT

120 IN 115 IN 30, 000 LBS ADJUSTABLE 37" TO 60" INCLUDED

SAP30k-16×102-48A 16 FT

102 IN 97 IN 30, 000 LBS ADJUSTABLE 37" TO 60" INCLUDED

SAP30k-16×120-48A 16 FT

120 IN 115 IN 30, 000 LBS ADJUSTABLE 37" TO 60" INCLUDED

SLIDE 10

CUSTOM RAMP SOLUTIONS

When none of our standard options fit into your project or yard ramp needs, allow our in house design team to help you create a solution to your project. A simple call to our staff to discuss your project will get the ball rolling toward a complete engineered solution for the most challenging ramp projects.

1-877-780-2288 | sales@nationramps.com

SLIDE 11

ADD ON OPTIONS FOR ALL MODELS

Add on options to each product include:

OSHA and Work Safe Compliant Handrails – For personnel safety
Ladders and Stairs (Lead to Platform Levels) – For easy access to platform levels
Electric Motor – For simple height adjustability
Wood Decking – For metal tracked equipment loading
Steel Serrated Bar Grating Surface – Provides optimal traction in all weatherconditions
EOD – Edge of Dock Leveler – Provides easy leveling to all trailer heights
Adjustable Legs – For manual ramp leveling to any trailerheight
Static Height Legs – When only single ramp height is required
Removable Rub Rails – To give our clients the ability to connect multiple ramps or platforms together
Custom Branding (paint, company logo’s etc.)

SLIDE 12

1-877-780-2288 | sales@nationramps.com

SOME BRANDS THAT TRUST IN NATION RAMPS…

SLIDE 13

SAFETY

1-877-780-2288 | sales@nationramps.com
