GCT634: Musical Applications of Machine Learning

Rhythm Transcription Dynamic Programming

Graduate School of Culture Technology, KAIST Juhan Nam

Outlines

• Overview of Automatic Music Transcription (AMT)
• Types of AMT Tasks
• Rhythmic Transcription
• Introduction
• Onset detection
• Tempo Estimation
• Dynamic Programming
• Beat Tracking

Overview of Automatic Music Transcription (AMT)

• Predicting musical score information from audio
• Primary score information is note but they are arranged based on rhythm,

harmony and structure

• Equivalent to automatic speech recognition (ASR) for speech signals

Model Beat Key Chord Structure Tempo Onsets

Types of AMT Tasks

• Rhythm transcription
• Onset detection
• Tempo estimation
• Beat tracking
• Tonal analysis
• Key estimation
• Chord recognition
• Timbre analysis
• Instrument identification
• Note transcription
• Monophonic note
• Polyphonic note
• Expression detection

(e.g. vibrato, pedal)

• Structure analysis
• Musical structure
• Musical boundary / repetition

detection

• Highlight detection

Types of AMT Tasks

• Rhythm transcription
• Onset detection
• Tempo estimation
• Beat tracking
• Tonal analysis
• Key estimation
• Chord recognition
• Timbre analysis
• Instrument identification
• Note transcription
• Monophonic note
• Polyphonic note
• Expression detection

(e.g. vibrato, pedal)

• Structure analysis
• Musical structure
• Musical boundary / repetition

detection

• Highlight detection

We will mainly focus on these topics!

Overview of AMT Systems

• Acoustic model
• Estimate the target information given input audio (usually short segment)
• Musical knowledge
• Music theory (e.g. rhythm, harmony), performance (e.g. playability)
• Prior/Lexical model
• Statistical distribution of the score-level music information (e.g. chord

progression) Acoustic Model Musical Knowledge Transcription Model Beat, Tempo Key, Chords Notes Prior or Lexical Model

Audio-Level Score-Level

Introduction to Rhythm

• Rhythm
• A strong, regular, and repeated pattern of sound
• Distinguish music from speech
• The most primitive and foundational element of music
• Melody, harmony and other musical elements are arranged on the basis of

rhythm

• Human and rhythm
• Human has innate ability of rhythm perception: heart beat, walking
• Associated with motor control: dance, labor song

Introduction to Rhythm

• Hierarchical structure of rhythm
• Beat (tactus): the most prominent level,

foot tapping rate

• Division (tatum): temporal atom, eighth
• r sixteenth
• Measure (bar): the unit of rhythm

pattern (and also harmonic changes)

• Notations
• Tempo: beats per minute, e.g. 90 bpm
• Time signature: e.g. 4/4, 3/4, 6/8

[Wikipedia]

Human Perception of Tempo

• Mckinney and Moelant (2006)
• Collect tapping data from 40 human subjects
• Initial synchronization delay and anticipation (by tempo estimation)
• Ambiguity in tempo: beat or its division ?

[D. Ellis’ e4896 slides]

Overview of Rhythm Transcription Systems

• Consists of several cascaded tasks that detect moments of

musical stress (accents) and their regularity

Beat Tracking Tempo Estimation Onset Detection Musical Knowledge

Onset Detection

• Identify the starting times of musical events
• Notes, drum sounds
• Types of onsets
• Hard onsets: percussive sounds
• Soft onsets: source-driven sounds (e.g. singing voice, woodwind, bowed

strings)

[M.Muller]

Example: Onset Detection

1 2 3 4 5 6 −1 −0.5 0.5 1 time [sec] amplitude ? “Eat (꺼내먹어요) ” Zion.T

Onset Detection Systems

• Onset detection function (ODF)
• Instantaneous measure of temporal change, often called “novelty” function
• Types: time-domain energy, spectral or sub-band energy, phase difference
• Decision algorithm
• Ruled-based approach
• Learning-based approach

Decision Algorithm Onset Detection Function Audio Representations

(Feature Extraction) (Classifier)

Onset Detection Function (ODF)

• Types of ODFs
• Time-domain energy
• Spectral or sub-band energy
• Phase difference

Time-Domain Onset Detection

• Local energy
• Usually have high energy at onsets
• Effective for percussive sounds
• Various versions
• Frame-level energy
• Half-wave rectification

𝑃𝐸𝐺(𝑜) = 𝐹 𝑜 = ) 𝑦 𝑜 + 𝑛 𝑥(𝑛) .

/ 012/

𝑃𝐸𝐺(𝑜) = 𝐼(𝐹 𝑜 + 1 − 𝐹 𝑜 )

𝐼 𝑠 = 𝑠 + 𝑠 2 = 8𝑠, 𝑠 ≥ 0 0, 𝑠 < 0

1 2 3 4 5 6 −1 −0.5 0.5 1 time [sec] amplitude

Waveform

1 2 3 4 5 6 5 10 15 20 time [sec] ODF 1 2 3 4 5 6 2 4 6 8 10 time [sec] ODF

Spectral-Based Onset Detection

• Spectral Flux
• Sum of the positive differences from

log spectrogram

• ODF changes depending on the

amount of compression 𝜍

time [sec] frequency−kHz 1 2 3 4 5 0.5 1 1.5 2 x 10

4

1 2 3 4 5 100 200 300 400 time [sec] ODF

𝑃𝐸𝐺(𝑜) = ) 𝐼(𝑍 𝑜 + 1, 𝑙 − 𝑍 𝑜, 𝑙 )

/2A B1C

𝑍 𝑜, 𝑙 = log 1 + 𝜍 𝑌 𝑜, 𝑙 𝑌 𝑜, 𝑙 : STFT

Phase Deviation

• Sinusoidal components of a note is continuous while the note is

sustained

• Abrupt change in phase means that there may be a new event

[D. Ellis’ e4896 slides] Deviation from the steady-state for all frequency bins

ϕk(n)−ϕk(n −1) ≈ ϕk(n −1)−ϕk(n − 2)

Phase continuation (e.g. during sustain of a single note)

Δϕk(n) =ϕk(n)− 2ϕk(n −1)+ϕk(n − 2) ≈ 0 ζ p = 1 N Δϕk(n)

k=1 N

∑

Post-Processing

• DC removal
• Subtract the mean of ODF
• Normalization
• Scaling level of ODF
• Low-pass filtering
• Remove small peaks
• Down-sampling
• For data reduction

Low-pass Filtering (Solid line)

(Tzanetakis, 2010)

Onset Decision Algorithm

• Rule-based Approach: peak detection rule
• Peaks above thresholds are determined as onsets
• The thresholds are often adaptively computed from the ODF
• Averaging and median are popular choices to compute the thresholds

threshold =α + β ⋅median(ODF) α :offset,β :scaling

Median with window size 5

0.5 1 1.5 2 2.5 3 3.5 4 4.5 5

time [sec]

50 100 150 200 250 300 350

ODF

ODF Threshold

Challenging Issue in Onset Detection: Vibrato

Onset detection using spectral flux

SuperFlux

• A state-of-the-art rule-based onset detection function
• S. Bock et al., “Maximum Filter Vibrato Suppression For Onset Detection”,

DAFx, 2013

• Step1: log-spectrogram
• Make harmonic partials have the same depth of vibrato contour
• Step2: max-filtering
• Take the maximum in a window on the frequency axis
• The vibrato contours become thicker

𝑍 𝑜, 𝑛 = log 1 + 𝑌 𝑜, 𝑙 L 𝐺 𝑙, 𝑛 𝑌 𝑜, 𝑙 : STFT 𝑍

0MN 𝑜, 𝑛 = max

(𝑍 𝑜, 𝑛 − 𝑚: 𝑛 + 𝑚 )

SuperFlux

• A state-of-the-art rule-based onset detection function
• S. Bock et al., “Maximum Filter Vibrato Suppression For Onset Detection”,

DAFx, 2013

• Step1: log-spectrogram
• Make harmonic partials have the same depth of vibrato contours
• Step2: max-filtering
• Take the maximum in a window on the frequency axis
• The vibrato contours become thicker

𝑍 𝑜, 𝑛 = log 1 + 𝑌 𝑜, 𝑙 L 𝐺 𝑙, 𝑛 𝑌 𝑜, 𝑙 : STFT 𝑍

0MN 𝑜, 𝑛 = max

(𝑍 𝑜, 𝑛 − 𝑚: 𝑛 + 𝑚 )

SuperFlux

Log-spectrogram Max-filtered Log-spectrogram

SuperFlux

• Step3: Super-flux
• Take the difference with some distance
• Assumption: frame-rate is high in onset detection (i.e. small hop size)
• Step 4: pick-picking
• 1) 𝑇𝐺∗ (𝑜) = max

(𝑇𝐺∗ 𝑜 − 𝑞𝑠𝑓0MN: 𝑜 + 𝑞𝑝𝑡𝑢0MN )

• 2) 𝑇𝐺∗ (𝑜) ≥ mean

(𝑇𝐺∗ 𝑜 − 𝑞𝑠𝑓M\]: 𝑜 + 𝑞𝑝𝑡𝑢M\] ) + 𝜀

• 3) 𝑜 − 𝑜_`a\bcde2cfeag > 𝑑𝑝𝑛𝑐𝑗𝑜𝑏𝑢𝑗𝑝𝑜 𝑥𝑗𝑒𝑢ℎ

𝑇𝐺∗(𝑜) = ) 𝐼(𝑍 𝑜 + 𝜈, 𝑙 − 𝑍 𝑜, 𝑙 )

/2A B1C

𝜈 = max (1, (𝑂 2 − min 𝑜 𝑥 𝑜 > 𝑠 ) ℎ + 0.5 (0 ≤ 𝑠 ≤ 1)

SuperFlux

Peak-picking Max-filtered Log-spectrogram

Tempo Estimation

• Estimate a regular time interval between beats
• Tempo is a global attribute of a song: e.g. bpm or mid-tempo song
• Tempo often changes within a song
• Intentionally: e.g. dramatic effect: Top 10 tempo changes
• Unintentionally: e.g. re-mastering, live performance
• There are also local tempo changes: e.g. rubato

Tempo Estimation Methods

• Auto-Correlation
• Find the periodicity as used in pitch detection
• Discrete Fourier Transform
• Use DFT over ODF and find the periodicity
• Comb-filter Banks
• Leverage the “oscillating nature” of musical beats

Auto-Correlation

• ACF is a generic method to detect periodicity of a signal
• Thus, this can be applied to ODF to find a dominant period that may

correspond to tempo

• The ACF shows the dominant peaks that indicate dominant tempi

1 2 3 4 5 −1 1 2 3 x 10

5

time [sec] ODF 1 2 3 4 5 100 200 300 400 time [sec] ODF

Onset Detection Function (spectral flux) Auto-Correlation

Tempo Estimation Using Tempo Prior

• Tempo is estimated by multiplying the prior with the auto-

correlation (observation)

• The auto-correlation corresponds to a likelihood function
• Tempo prior can be calculated from beat annotations of a dataset
• The distribution fits to a log-normal distribution well

Histogram of beats from a dataset

[D. Ellis’ e4896 slides] (Klapuri, 2003)

Beat Spectrum

• Leverage the repetitive nature of music
• Algorithm
• Step1: compute cosine distance between two

frames of magnitude spectrogram

• Step 2: sum the elements on the diagonals

(Foote, 2001)

𝑇(𝑗, 𝑘) = 𝑊

b L 𝑊 b

𝑊

b

L 𝑊

w

𝐶(𝑚) = ) 𝑇(𝑙, 𝑙 + 𝑚)

• B

Beat Spectrum

• A more robust version can be obtained

from the 2D auto-correlation of the similarity matrix

• The final beat spectrum is derived by

summing over one axis

• The left plot shows five beats and a triplet

within a beat.

• “Beat spectrogram” can be also
• btained by successive beat spectra

𝐶(𝑙, 𝑚) = ) 𝑇(𝑗, 𝑘) L 𝑇(𝑗 + 𝑙, 𝑘 + 𝑚)

• b,w

(Foote, 2001) Five beats and a triplet within a beat

Tempogram

• Algorithm
• Step 1: compute ODF from the half-wave

rectified spectral flux

• Step2: obtain the frequency and phase

that provide the maximum correlation with for the ODF and form a local sinusoidal kernel

• Step 3: accumulate the successive local

sinusoidal kernels to form a PLP curve

• Step 4: take DFT or auto-correlation

(Grosche, 2009)

k(m) = w(m −n)cos(2π( ˆ wm − ˆ ϕ))

• Modeling the onset function using sinusoid as predominant local

periodicity (PLP)

Tempogram

• Cyclic Tempogram
• Accumulate the tempogram

for integer multiples of a tempo (up to four octaves)

• Conceptually similar to

“Chromagram”

(Grosche, 2011)

Comb-Filter Banks

• Also called resonant filter banks
• Comb filter equation
• Builds up rhythmic evidences

(by anticipation?)

(Klapuri, 2006)

𝑧 𝑜 = 𝑦 𝑜 + 𝛽𝑧 𝑜 − 𝜐

Sub-band Resonant Filter Banks

• Algorithm
• A sub-band filter bank as a front-end

processing

• Parallel ODFs for 6 bands
• 150 resonators for each band and all

possible tempo values (60 - 240 bpm)

• Pick up the delay that provides the

highest peak as a tempo

(Scheirer, 1998)

Beat Tracking

• Estimate the position of beats in music
• Usually a subset of detected onsets selected by the tempo

Beat Tracking by the Resonator Model

• Once the resonator model chooses

the tempo that returns the highest peaks, the output produces a sequence of resonated peaks

• They correspond to the beats

(Scheirer, 1998)

• Find the optimal “hopping” path on music (Ellis, 2007)
• 𝐷

𝑢b : cost of the path 𝑢b

• 𝑃 𝑢b : onset strength function (i.e. ODF)
• 𝐺(∆𝑢, 𝑈): tempo (𝑈) consistency score: e.g. 𝐺 ∆𝑢, 𝑈 = −(𝑚𝑝𝑕

∆g ‚ ).

Beat Tracking by Dynamic Programming

𝐷 𝑢b = ) 𝑃 𝑢b

ƒ b1A

+ 𝛽 ) 𝐺 𝑢b − 𝑢b2A, 𝑈

ƒ b1.

. . .

1

Finding the Minimum-Cost-Path

• Naïve approach
• Find all paths from A to K and calculate the cost for each, and choose the

path that has the minimum cost.

• As the number of nodes increases, the number of possible paths increases

exponentially

A C B D E F G H 2 4 3 3 6 2 4 2 2 3 2 5 4 1 2 3 3 1 5 3 I J K 7 4 5 6 3 3 5 7 4 3 2 3 2

Dynamic Programming (DP)

• Observation
• Say the minimum-cost-path passes by a node p,
• What is the minimum-cost-path from A to p ?
• It is just a sub-path of the minimum-cost-path from A to K.
• Thus, we don’t have to compute the cost from scratch; we can use the cost

computed from the previous nodes.

A C B D E F G H 2 4 3 3 6 2 4 2 2 3 2 5 4 1 2 3 3 1 5 3 I J K 7 4 5 6 3 3 5 7 4 3 2 3 2

Dynamic Programming (DP)

• The minimum cost is computed by the following equation:
• The minimum-cost-path can be found by tracing back the

computation

Ck( j) = Ok( j)+ min

i {Ck−1(i)+cij}

Ck( j) Ok( j)

: cost up to node j : local cost at node j

cij : transition cost from i to j

A C B D E F G H 2 4 3 3 6 2 4 2 2 3 2 5 4 1 2 3 3 1 5 3 I J K 7 4 5 6 3 3 5 7 4 3 2 3 2

Applying DP to Beat Tracking

• To optimize:
• Define 𝐷∗ 𝑢 as best score up to time 𝑢 and compute it for every 𝑢
• Also, store the time that returns maximum score 𝑄 𝑢
• At the end of the sequence, traceback 𝑄 𝑢 , which returns the best path 𝑢b

𝐷 𝑢b = ) 𝑃 𝑢b

ƒ b1A

+ 𝛽 ) 𝐺 𝑢b − 𝑢b2A, 𝑈

ƒ b1.

𝐷∗ 𝑢 = 𝑃 𝑢 + max

… {𝛽𝐺 𝑢 − 𝜐, 𝑈 + 𝐷∗ 𝜐 }

𝑄 𝑢 = argmax

…

{𝛽𝐺 𝑢 − 𝜐, 𝑈 + 𝐷∗ 𝜐 }

1 2 3 4 5 100 200 300 400 time [sec] ODF

𝑢 𝜐 𝐷∗ 𝑢

Example of DP to Beat Tracking

References

• E. Scheirer, “Tempo and Beat Analysis of Acoustic Musical Signals”, 1998
• J. Foote and S. Uchihashi, “The Beat Spectrum: A New Approach to Rhythm

Analysis”, 2001

• G. Tzanekatis, “Musical Genre Classification of Audio Signals”, 2002
• A. Klapuri, “Analysis of the Meter of Acoustic Musical Signals”, 2006
• P. Grosche and M. Muller, “Computing Predominant Local Periodicity

Information In Music Recordings”, 2009

• P. Grosche and M. Muller, “Cyclic Tempogram – A Mid-Level Tempo

Representation For Music Signals”, 2010

• D. Ellis, “Beat Tracking by Dynamics Programming”, 2007
• S. Bock and G. Widmer, “Maximum Filter Vibrato Suppression For Onset

Detection”, 2013
