MRB Research Center Research Center Magnetic Resonance Bavaria MRB Research Center The MRB Research Center is a spin-off of the University of Wrzburg (Physics) Chairmen: Prof. Dr. P. Jakob, Prof. Dr. A. Haase . It was founded in 2005 as a


slide-1
SLIDE 1

MRB Research Center

Research Center Magnetic Resonance Bavaria

slide-2
SLIDE 2

MRB Research Center

The MRB Research Center is a spin-off

  • f the University of Würzburg (Physics)

Chairmen: Prof. Dr. P. Jakob, Prof. Dr. A. Haase.

It was founded in 2005 as a registered non-profit association and is dedicated to:

basic research customized research teaching programs

slide-3
SLIDE 3

“Low-Budget” & Mobile MRI

  • Portable MR scanner
  • MR imaging and spectroscopy
  • Hardware and magnet development

@ the MRB

Gradient amplifier with DA-Converter DAC Transmit Pulse ADC Data Acquisition MR Magnet + Gradients Electronics MR Magnet + Gradients Electronics MR Magnet

Field Studies

Electronics

slide-4
SLIDE 4

Example 1

Sequence: spin echo experiment Sample: gardenbean B-Field: 0.5 T Matrix: 256 x 256 TR : 100 ms TE : 5 ms Averages: 32

“Low-Budget” & Mobile MRI

slide-5
SLIDE 5

Example 2

Sequence: spin echo experiment Sample: water tubes B-Field: 0.5 T Matrix: 512 x 512 TR : 100 ms TE : 5 ms Averages: 9

“Low-Budget” & Mobile MRI

slide-6
SLIDE 6
  • Portable-low-budget, low-field (0.2-1T) animal MR system
  • Can be used in the environment of a nuclear-medicine department
  • Low magnetic field strength = less interference with PET-unit
  • Application of multimodal (PET-MR) contrast agents
  • Open Question:

How to combine this system efficiently with a PET-unit???

Input for the consortium
