Tradition, Reliability, Quality Since 1921 Rok 2018 Organization Chart International BEZ Group 100 % 100 % 100 % ETD ELECTRICAL BEZ TRANSFORMERS MACHINES TRANSFORMERS Distribution transformers, Repairs and service of Power

slide-1
SLIDE 1

Tradition, Reliability, Quality Since 1921

Rok 2018

slide-2
SLIDE 2

2 Power transformers, including service, including repairs International BEZ Group ETD TRANSFORMERS BEZ TRANSFORMERS ELECTRICAL MACHINES Repairs and service of transformers and rotating machinery Distribution transformers, including repairs

100 % 100 % 100 %

Organization Chart

slide-3
SLIDE 3

3

Our Customers

Czech republic, Slovak republic, Poland, Germany, Austria, Switzerland, Holland, Latvia, Lithuania, Macedonia, Bulgaria, Romania, Ukraine, Belarus, Russia, Kazakhstan, Egypt, United Arab Emirates, Bahrain, Angola, Venezuela, Mexico, Chile, Cuba, Dominican republic Denmark, Countries of former Yugoslavia, Afghanistan, Irak, Iran, Pakistan, Bangladesh, Maroco, Ethiopia, Lebanon, China, Korea, Vietnam, Algeria

slide-4
SLIDE 4

Commodities (%)

4

65,64 28,59 1,00 0,82 4,86

transformers up to 100 MVA transformers above 100 MVA reactors repairs

  • ther
slide-5
SLIDE 5

Our Certification

Quality Management System acc, to

EN ISO 9001

Environmental Management System according to

EN ISO 14001

Metalic materials Welded Bonds Requirements according to EN ISO

3834-2

Electrotechnical Test Room Accreditation acc. to EN ISO/IEC

17025

Testing Activities of Test Room E11 Czech Railways Supplier Qualification Certificate 5 Certificate for the Occupational Health and Safety management System under

OHSAS 18001

slide-6
SLIDE 6

Trade Fairs

In 2018 we will be pleased to welcome you at the following fairs:

  • International Electronic and

Electrotechnical Fair, AMPER. Brno, Czech Republic

  • International Electrotechnical Fair

Hannover Messe, Germany

6

  • Middle East Electricity (MEE) Dubaj
  • FIHAV, Kuba
  • POWER KAZAKHSTAN
slide-7
SLIDE 7

Manufacturing Programme

Rok 2018

slide-8
SLIDE 8

Three-phase Regulation Oil Transformers

Three-phase regulating oil transformers with output from 10 to 320 MVA, nominal voltage up to 420 kV AT 350 MVA,420/121/10,5 kV ČEPS

8

8

slide-9
SLIDE 9

Three-Phase non-Regulation Oil transformers

Three-phase non-regulating oil transformers with output up to 410 MVA and voltage up to 420 kV 410 MVA, 410/22 kV – Serbia, Kolubara

9

slide-10
SLIDE 10

One-Phase Oil Transformers

One-phase transformers with total

  • utput of a three-phase set up to 1200

MVA and voltage up to 420 kV 254/3 MVA, 420/13,8 kV - Dalešice

10

slide-11
SLIDE 11

Special Transformers according to Customers Specifications

Regulating and non- regulating transformers according to individual customers specification with different types of winding, cooling and sizes. Autotransformers with output up to 400 MVA and voltage 420 kV

11

Low-noise transformer 40 MVA, 115/21,5 kV, Austria

slide-12
SLIDE 12

Chokes

Chokes for rail vehicles – traction chokes Choke CLVH 550-3m

Reactors

Starting reactors 6,3-22 kV, inductance up to 10%

12

slide-13
SLIDE 13

13

Reactor 18,75 MVAr, 38,5 kV for

substation – Russland 2012

Reactors

  • Output up to 200 MVAr
  • Voltage up to 500 kV (acc. GOST)
  • CLEVER REACTORS
  • Continuous regulation of

reactive power – electronically controlled

  • Frost proof up to±60 °C
slide-14
SLIDE 14

Repairs, Modernization and service

Repairs

  • Oil transformers with output from 1 to 400 MVA
  • Furnace transformers
  • Autotransformers

Technical Support

  • Transformer testing prior to commissioning
  • Transformer diagnostics
  • Transformer technical checkup

All activities are performed up on transformers produced by

  • urselves as well as by other manufacturers.

14

slide-15
SLIDE 15

History

Rok 2018

slide-16
SLIDE 16

Milestones in History

1921 – establishment of Electrotechnical Engineering plant Škoda 1940 – fullfill level 110 kV 1950 – fullfill level 220 kV 1965 – start manufacturing traction transformers 1973 – fullfill level 420 kV 2004 – change of owner and name of company 2009 – first shunt reactor 2010 – first furnace transformer 2013 – start of autotransformers manufacturing 2016 – first hermetized transformer

16

slide-17
SLIDE 17

Photographs • references

Rok 2018

slide-18
SLIDE 18

Transformer 12,5 MVA, 110/27 kV For power substation ČD – year 2004

18

Transformer 63 MVA, 110/10,5 kV Vřesová – year 2006 Transformer 25 MVA, 110/13,8 kV Cuba – year 2007

slide-19
SLIDE 19

19

Transformer 300 MVA, 420/15,75 kV Dukovany – year 2008 Saturating reactor electronically regulated Russia – year 2010 Transformer for electronical conventers EN 61378 51 MVA Železárny ve Strážském, Slovak republic - 2010

slide-20
SLIDE 20

One-phase transformer, 250 MVA, 420/21 kV For Power plant Ledvice - 2012

20

Three-phase transformer 300 MVA,420/15,75 kV for NPP Mochovce, Slovak republic - 2013 One-phase transformer 254/3 MVA, 420/13,8 kV for WPP Dalešice - 2014

slide-21
SLIDE 21

21

Transformer 185 MVA, 220/15,75 for Egyptian customer PSP EL SEWEDY

  • 2015

Furnace transformer 20 MVA, 30 kV for polish customer, Stalowa wola

  • 2015
slide-22
SLIDE 22

22

Three-phase transformer 128MVA, 220/13,2 kV, Atacama, Chile - 2015 Three-phase transformer 210MVA ,231/16,6 kV, Mexico - 2015

slide-23
SLIDE 23

23

Three-phase transformer 60 MVA, 112/21/(6,3) kV, E-Steiemark, Austria- 2017 Rail transformer 27 MVA, 132/66 kV, SBB, Switzerland- 2016

slide-24
SLIDE 24

24

News

Three-phase transformer 350MVA,400/121/10,5 kV Czech republic - 2017

slide-25
SLIDE 25

25

News

Single phase transformers 250/3 MVA, 420/3 kV – Čierný Váh, Slovak republic - 2017

slide-26
SLIDE 26

Company Headquarters

ETD TRANSFORMÁTORY a.s.

Zborovská 54/22 301 00 Plzeň Czech republic Phone: +420 373 031 799 Fax: +420 373 031 908 E-mail: etd@etd-bez.cz GPS: 49.7260092N, 13.3863008E

26
