XGT Diagnostics 12/Apr/2001 at VRVS meeting by Tsunefumi Mizuno (mizuno@hirax6.hepl.hiroshima-u.ac.jp) (mizuno@SLAC.Stanford.EDU) XGT Diagnostics: What we need to verify that XGT works is. PHA Spectrum for each XGT (like below) threshold

SLIDE 1

XGT Diagnostics

12/Apr/2001 at VRVS meeting by Tsunefumi Mizuno (mizuno@hirax6.hepl.hiroshima-u.ac.jp) (mizuno@SLAC.Stanford.EDU)

SLIDE 2

PHA Spectrum for each XGT (like below) MIP particle threshold

XGT Diagnostics: What we need to verify that XGT works is….

By taking histogram, we can check

Channel does work/not
Threshold level
PMT gain

SLIDE 3

Rate Counter for each XGT (like the right figure)

XGT Diagnostics: What we need to verify that XGT works is….

We also want to know PHA/Low threshold voltage (House keeping?)
