Pump Baseplate Resonance Responsible for Large Piping Vibration and Component Failures Jos A Vzquez, Ph.D. DuPont Company Engineering- Eng Mechanics Group Wilmington, Delaware Problem Statement Two overhang Centrifugal Pumps working

slide-1
SLIDE 1

Pump Baseplate Resonance Responsible for Large Piping Vibration and Component Failures

José A Vázquez, Ph.D. DuPont Company

Engineering- Eng Mechanics Group Wilmington, Delaware

slide-2
SLIDE 2

Problem Statement

  • Two overhang Centrifugal Pumps working

in parallel

  • Pumps driven by 75 hp motors, 3600 rpm
  • Over 15 years of operation, experienced

repeat failures on piping system, valves, couplings, impellers and housings

  • Routine vibration measurement for

trending do not show any discernable pattern

slide-3
SLIDE 3

Problem Statement (cont)

  • Maintenance Personnel observed high

vibration on the piping system where many

  • f the failures occurred
  • Initial thought was that piping resonance

was excited and that shook the pump

  • It had been a practice to tighten the pipe

hanging supports to reduce vibration temporarily

slide-4
SLIDE 4

Problem statement (cont.)

South Pump North Pump

slide-5
SLIDE 5

Vibration Measurement on South Pump Bearing Housing, Coupling End Horizontal direction

Period of 8.1 sec

slide-6
SLIDE 6

Typical collection window for vibration routes 60000 CPM, 800 Lines, 4 Averages, 50% overlap

Vibration Measurement on South Pump Bearing Housing, Coupling End Horizontal direction

slide-7
SLIDE 7

Vibration Measurement on South Pump Bearing Housing, Coupling End Horizontal direction

FFT on 5 minutes worth of data. 153600 lines, 0.00333 Hz resolution

slide-8
SLIDE 8

Vibration Measurement on South Pump Bearing Housing, Coupling End Horizontal direction

South Pump North Pump Zoom around Pump running speed. 0.00333 Hz resolution

slide-9
SLIDE 9

Vibration Measurement on South Pump Bearing Housing, Coupling End Horizontal direction

South Pump Only North Pump Only Both Pumps

slide-10
SLIDE 10

Vibration Measurement on South Pump Bearing Housing, Coupling End Horizontal direction

South Pump. North Pump is Off

slide-11
SLIDE 11

Vibration Measurement on South Pump Bearing Housing, Coupling End Horizontal direction

North Pump. South Pump is Off

slide-12
SLIDE 12

ODS of the pumps

North Pump

slide-13
SLIDE 13

ODS of the pumps

South Pump

slide-14
SLIDE 14

Vibration Analyses

  • All Vibration at running speed (1X)
  • Previous attempts at balancing did not

yield any significant improvements

  • Maintenance Personnel thought the

problem was a piping resonance

slide-15
SLIDE 15

Impact Testing

  • Impact testing on the Inlet and discharge

piping did not show any resonance in the vicinity of running speed

  • Based on the evidence from the ODS, the

baseplate was impacted in several

  • directions. We found a natural frequency
  • n the baseplate of the south pump at the

running speed of that pump.

slide-16
SLIDE 16

South Pump Baseplate resonance

slide-17
SLIDE 17

Repairs

  • Repaired the pump pad that had some

cracks

  • Changed the in-house baseplate for a

fabricated baseplate that could be grouted in

  • Corrected the local practice of tightening

the pipe hangers to control vibration

  • The pumps have been in operation for 5

years without major issues

slide-18
SLIDE 18

Current Look of the Pump Installation
