PTZ1A225U-IRA-N

RoboPTZ Series

DAHUA - PTZ PRODUCT LINE

CONTENTS

Highlights Applications Advantages

As a RoboPTZ Camera, this positioning system is designed special and delicate, with small appearance, powerful performance and good protection, this positioning system is of great competitiveness

Advantages

Delicate Design

Different with other traditional positioning system, PTZ1A225U-IRA-N looks much smaller and more distinctive

PTZ1A PTZ12

V S

Great Protection

Different with other traditional positioning system, PTZ1A225U-IRA-N supports both IP67 and IK10, and this camera is the first positioning system that support IK10

IK10 IP67

Special Installation

Different with other traditional positioning system, PTZ1A225U-IRA-N supports both upright and inverted mounting orientation , and this is also one common feature of RoboPTZ Series

PTZ1A

V S

PTZ12

There are so many highlights of this RoboPTZ camera, the delicate appearance, the powerful performance, the great protection and etc.

Highlights

PTZ1A225U-IRA-N

 -90°~ 90° Wide Tilt Angle

 IP67,IK10,TVS 8KV Protection  Multiple Installation Methods

 25x Optical Zoom  150m IR Distance

 Starlight Technology & WDR  H.265 Encoding  IVS & Auto-tracking

Whole tilt range can up to -90°~90° Effective tilt angle range can up to -51°~90°

• 90° ~90° Tilt Range

In this test, the camera will be flushed by water source 1.27m away, and the flushing process lasts half an hour in total

Water Flushing Test

In this test, the camera will be showered by water with power on, and the shower process lasts 8 days in total

Water Shower Test

In this test, the camera will be soaked in water with power off, and the soaking process lasts 30 mins in total

IPX7 Test IP67 Protection

In this test, the impact hammer weight (Iron ball) is 5Kg

5kg Iron Ball

In this test, the test impact energy is 20J, which is caused by free falling of iron ball from 40cm height

Test Status

After the tests, the mechanical structure has no damage, functions are actively, and no function failure.

Check After IK10 Test IK10 Protection

To test if the camera can work normal under high and low temperature or not

High & Low Temperature Test Vibrate Test Fall Test Full Test

To test if the camera can work normal in vibrate environments

• r not

To test if the camera package can protect device well during transportation or not

Corner Mount Wall Mount Pole Mount

Multiple Installation Methods

Upright Mounting Orientation Inverted Mounting Orientation

Multiple Installation Methods

Upright Mounting without Bracket Inverted Mounting without Bracket

25x Optical Zoom

 Focus length : 4.8mm~120mm  FOV-H: 59.2° ~ 2.4° Detect / Observe / Recognize / Identify 1613m 646m 323m 161m 5292ft 2119ft 1060ft 528ft

150m IR

 High transmittance

The IR lights have high transmittance because of the special process of the IR lens

 4 IR LEDs

Adjust the brightness according to the different optical zoom

Starlight & WDR

This camera adopts powerful DSP and good image sensor to support starlight, which performs better than ordinary camera.

PTZ1A225U-IRA-N iPhone7

This camera adopts industry-leading WDR technology to perform good even in the most intense contrast lighting conditions.

WDR ON WDR OFF

How many days can

4TB HDD stores at

full-HD footage?

97 days

H.264 encoding

194 days

H.265 encoding

These cameras support industry standards H.265 and H.264 for video compression, as well as advanced Smart Codec technology to provide significant savings of network bandwidth and subsequent storage costs.

H.265 Encoding

Tripwire (video) Missing & Abandon (video) Intrusion (video) Auto-tracking (video) IVS & Auto-tracking

As a RoboPTZ Camera, this positioning system is designed special and delicate, with small appearance, powerful performance and good protection, this positioning system is of great competitiveness

Applications

CITY

Starlight and 150m IR provide a bright image at night 90º elevation angle provides a bigger monitoring range IP67 and IK10 protections reduce maintenance costs IVS and Auto tracking ensure nothing goes unnoticed

SHOPPING MALL

Starlight and 150m IR provide a bright image at night 1080P & 25x optical zoom ensure a wide monitoring range H.265+ offers double the compression ratio, saving on storage costs IVS and Auto tracking ensure nothing goes unnoticed

HIGHWAY& RAILWAY

Starlight and 150m IR provide a bright image at night Multiple installation method provides a better flexibility IP67 and IK10 protections reduce maintenance costs H.265+ offers double the compression ratio, saving on storage costs

FACTORY

120dB WDR and 150m IR provide an excellent image Multiple installation method provides a better flexibility IVS and Auto tracking ensure nothing goes unnoticed H.265+ offers double the compression ratio, saving on storage costs

Dahua Brand: DH-PTZ1A225U-IRA-N DH-PTZ1A225UN-IRA-N OEM: PTZ1A225U-IRA-N PTZ1A225UN-IRA-N

Ordering Information

Visit the website to get more information http://www.dahuasecurity.com/products_category/positioning-system-282.html
