PROVIDENCE ACADEMY ADA AND DECK REPAIRS - 2020 PROJECT GOALS Repair North Balconies Provide ADA Access Repair East Entrance Improve column foundations. SCOPE 1A: WEST PORCH FRAMING REPAIRS

slide-1
SLIDE 1

PROVIDENCE ACADEMY

ADA AND DECK REPAIRS - 2020

slide-2
SLIDE 2

PROJECT GOALS

  • Repair North Balconies
  • Provide ADA Access
  • Repair East Entrance
  • Improve column

foundations.

slide-3
SLIDE 3
slide-4
SLIDE 4

SCOPE 1A: WEST PORCH FRAMING REPAIRS

slide-5
SLIDE 5

PORCH COLUMN BASES

slide-6
SLIDE 6

SCOPE 1B: WEST PORCH ACCESSIBLE RAMP

slide-7
SLIDE 7

SCOPE 2: EAST WALL ADA ENTRANCE

slide-8
SLIDE 8

SCOPE 3: EAST PORCH

slide-9
SLIDE 9

SCOPE 4: EAST ENTRANCE

slide-10
SLIDE 10

COLUMNS AND RAILINGS

  • Columns to be replaced at North decks.
  • New columns to be a consistent size, square or round

to match existing.

  • The entire railing system at south decks to be

replaced, and a new top rail with intermediate cables to be provided.

slide-11
SLIDE 11

DECK SYSTEM

  • Add new pedestrian traffic coating on

upper level decks. Lower level decks to be decking material to match

  • existing. Color to be similar to

existing. Traffic Coating Column Paint
