PROPOSED SITE PLAN APPROVALS (NOT TO SCALE) 0 25 Buildable Area Less Than 50 Square Feet 12 12 100 100 6 6 0 0 Zoning Setback Requirements: Creek Setback: 100 Lake Setback: 60 Existing Aerial,

SLIDE 1

APPROVALS

PROPOSED SITE PLAN

(NOT TO SCALE)

SLIDE 2

100’ 100’ 6 ’ 6 ’ 12’ 12’ Existing Aerial, Setbacks per Code Buildable Area Less Than 50 Square Feet

0’ 25’

Zoning Setback Requirements: Creek Setback: 100’ Lake Setback: 60’ Side Setback: 12’

SLIDE 3

House Height 25’ max., requesting 26.51’ House Setback, Rear / Lake 60’ required, requesting 40.7’ Concrete Walk Setback, Creek 100’ required, requesting 17.1’ House Setback, Creek ◊ 100’ required, requesting 25’, existing 25’ Retaining Wall Setback, Creek 100’ required, requesting 4.5’ Garage Setback, North Property Line / Side ◊ 12’ required, requesting 5.2’, existing varies 0' - 4.7’ (Previously approved while Zoning requirement was 10')

1 2 3 4 5 6

6 Requested Variances

2 are equivalent to variances previously granted in 2013 - Denoted by ◊

SLIDE 4

42’ 42’ 45’ 45’ 21’ 21’ 41’ 41’ 48’ 48’ 45’ 45’ 40.7’ 40.7’

Visible shoreline Visible shoreline (2016 Pictometry measurements) (2016 Pictometry measurements) Ontario County GIS Ontario County GIS Average setback of 6 adjacent properties: ~40.3' Average setback of 6 adjacent properties: ~40.3' Proposed Project: 40.7' (from MHWL) Proposed Project: 40.7' (from MHWL)

Lake Setbacks Analysis

SLIDE 5

0’ 25’

Sketch Plan Setbacks

Average Lake Setback: 50.6' (based on setback to closest point at 5' increments along entire lake front facade.) Creek Setback: Request equivalent to previously granted creek setback (2013) Relative Setback to Neighboring Structures: House is consistently set back 10+ feet behind range line of adjacent neighbours house. (Agreement with neighbors) Garage Setback: Request equivalent to previously granted creek setback (2013) 25’ 25’ 18.5’ 18.5’ 5.7’ 5.7’ 5.7’ 5.7’ 10’ 10’ 40.7’ 40.7’ 63.2’ 63.2’ Existing Structure (blue dashed line) Proposed Structure (grey region)

SLIDE 6

Building Elevations

PROPOSED ELEVATIONS

(NOT TO SCALE)

SLIDE 7

PROPOSED ELEVATIONS

(NOT TO SCALE)

SLIDE 8

PERSPECTIVE RENDERING

LAKESIDE

SLIDE 9

PROPOSED DETACHED GARAGE ELEVATIONS

(NOT TO SCALE)

SLIDE 10

APPROVALS
