Bushey Police Station, 43 Sparrows Herne, Bushey 16/1290/FUL

Site Plan as Proposed (Existing) Pre-existing Site Plan

Aerial View of Application Site

Birds-eye View of Application Site

Main Police Station building proposed to be converted into 3 flats New house proposed Haystore proposed to be converted to a cycle and bin store Proposed bin storage

Site Plan of Consented Scheme 13/1907/FUL

Differences between the consented scheme 13/1907/FUL and the current scheme 16/1290/FUL

• The main police station building in the consented scheme is proposed to be

converted into 3 x 2 bedroom flats, for the current scheme it is proposed to be converted into a 1 x 2 bedroom flat and 2 x 3 bedroom flats.

• The haystore in the consented scheme is proposed to be converted into a bin

and cycle store with an unused upper floor, the current scheme it is proposed to be converted into a single dwelling and a separate bin store with adjoining cycle store proposed immediately adjacent to it.

• Changes to the configuration of the communal areas of hard and soft

landscaping; Changes to the configuration and number of car parking spaces. The consented scheme proposes 7 car parking spaces and the current scheme proposes 8 spaces.

• Minor elevational changes to the main building.

Site Plan as Proposed (Existing)

Main Police Station building converted to 3 flats New bin store with adjoining cycle store Haystore (converted to a house) New house Police Station Lane to be resurfaced to look as shown

Front & Rear Elevations of Main Building

Existing front – no change Pre-existing rear

Pre-existing rear (showing extension and storage building are now demolished) Existing (as built) rear (note garages have been demolished, single storey rear extension and dormer window)

Pre-existing haystore Existing haystore (as altered). Also note existing large bin store to be removed and replaced by a brick bin store

Pre-existing rear courtyard Existing (as built) new house situated on rear court yard

Pre-existing rear elevation Existing (as built rear elevation) Existing front elevation – no change Proposed rear elevation (window in extension is to be reduced in width)

NW elevation pre-existing NW elevation existing (as built) SE elevation pre-existing SE elevation existing (as built)

NW elevation (as altered) SE elevation (as altered) Pre-existing NW elevation Pre-existing SE elevation

SW elevation existing (as altered) NE elevation existing (as altered) Pre-existing SW elevation Pre-existing NE elevation

Front elevation Rear elevation Side elevations

Aerial View of Application Site
