PRODUCT OFFER Warsaw, 21 st Nov. 2017 1. PRESENTATION OF THE COMPANY - - PowerPoint PPT Presentation

TWÓJ PARTNER W ENERGETYCE

PRODUCT OFFER

Warsaw, 21st Nov. 2017

• Production place
• 35 years of experience
• Production range
• Products in figures
• Production Specialization (AC Switchgear)
• Number of bays produced during the last 2 years
• Employment
• Machine park
• Productivity
• Sales results
• Standards, type tests, certification
• Selected examples of reference list
• 1. PRESENTATION OF THE COMPANY

Production facility

JM-TRONIC Sp. z o.o.

• ul. Wapienna 43/45

04-691 Warszawa

35 YEARS OF EXPERIENCE

35 YEARS OF EXPERIENCE

Production Range

Protection relays and controllers:

• miniMUZ
• ecoMUZ-2, 2G
• multiMUZ-2
• multiMUZ-3
• megaMUZ-2
• megaMUZ-smart

Switchgears:

• MultiCell
• MultiCell-G
• MultiCell-2S
• MultiCell-2S-G
• Rama typu L
• PowerCell
• skrzynki przyłączeniowe SN JMZK
• TrakCell

Switching devices:

• MV vacuum circuit breakers VC-1
• MV vacuum contactors TVAC 7,2kV
• MV earthing switches UJM 12/17/24kV

Other products:

• Electronic locking of earthing switch EBU-W
• Voltage indicator EWN
• Signal relay RS88
• Energy meters

megaMUZ-2

35 years on the protection market

megaMUZ-smart multiMUZ-3 multiMUZ-2 ecoMUZ-2 ecoMUZ-2G miniMUZ

Protection relays and controllers

MultiCell, MultiCell-G MultiCell-2S, MultiCell-2S-G Rama typu L PowerCell Skrzynka przyłączeniowa JMZK TrakCell

Switchgears

Vacuum circuit breaker VC-1 (fixed version) Un=12-24kV

Vacuum contactor TVAC Indoor earthing switch UJM

Switching devices

Set of withdrawable CB VC-1 Un=36kV

Vacuum circuit breaker VC-1 (withdrawable) Un=12-24kV

Product in figures

• Over 30 000 pcs. protection relays
• Over 6 000 pcs. MV circuit breakers VC-1

Product in figures

• Over 5 000 bays of MV switchgears type MultiCell and

MultiCell-2S (double busbar system)

• Robust construction
• Reliable locking system
• Proven solutions backed by years of operation
• Safety
• Innovative arc protection system
• Modern construction solutions
• High resistance to internal arc
• Custom execution

PRODUCTION SPECIALIZATION – AC switchgears MV air insulated switchgear MultiCell Un range from 12 up to 24 kV

PRODUCTION SPECIALIZATION – DC switchgear type TrakCell DC switchgear for insulation level 660 V (Trams traction)

• 2018 – 2020
• Expected over 1500 bays of MV Switchgear
• 2017
• 530 bays of MV Switchgear
• 2015,2016
• 914 bays of MV Switchgears
• 2014
• 544 bays of MV Switchgears
• 2013
• 497 bays of MV Switchgears

Number of MV bays produced during the last 2 years

• Employment – 140 persons in the continuous work system
• 60% of the employees in the manufacturing part.
• Opportunity to increase employment and work for 2-3 changes

Employment

• AMADA CNC machine tool (model AC 2510 NT)
• HAAS ST-10 - modern CNC lathe
• AMADA Bending machine (HFE model 80-25)
• SMT machines for PCB production
• Benders, milling machines, lathes and others
• Eccentric presses - production of copper busbars
• 5S production system

MACHINE PARK

PRODUCTIVITY

40-50 bays per month in the basic production system 480-600 bays per year 700-800 bays per year If the system works for 2-3 changes

SALES RESULTS

2017 Expected turnover of JM Tronic – 12 million EUR 2016 Annual turnover of JM TRONIC - PLN 10 million EUR (increase in the number of protection relays 7%) 2015 Annual turnover of JM TRONIC - 12 million EUR (switchgear sales growth of 11% compared to 2014)

STANDARDS, TYPE TESTS, CERTIFICATION

• JM Tronic develops and produces a product with Polish Standard series PN-EN ...

which are harmonized with IEC standards system.

• Each product designed, developed and implemented to produce is subjected to the

type tests in laboratories accredited by the Polish Accreditation Center (PCA), which is a member of ILAC-MRA.

• Our products are subjected to certification procedures in independent Certification

Centers, which have the appropriate accreditation of the Polish Accreditation Center.

STANDARDS, TYPE TESTS, CERTIFICATION

• Switchgears

STANDARDS, TYPE TESTS, CERTIFICATION

• Switching devices

STANDARDS, TYPE TESTS, CERTIFICATION

• Protection relays

STANDARDS, TYPE TESTS, CERTIFICATION

• Energy meters

• Polish Railways – 800 pcs. bays of MV Switchgear
• PGE Distribution Utility – 700 pcs. vacuum circuit breakers VC-1
• TAURON Distribution Utility – 400 szt. vacuum circuit breakers VC-1
• Coal mine KWK Ziemowit – 60 bays of MV Switchgear
• Power plant Żydowo – the first switchgear in Poland in withdrawable version for 63kA
• Heat Power Plant Tameh – switchgear for high nominal current 2500A and short-circuit currents

50kA / 1s

• Heat Power Plant EDF in Gdynia – comprehensive modernization of the distribution and the supply

boxes for motors 6kV

• Chemical Plant in Puławy – 25 bays of double busbar system switchgear at the Ammonia Division
• Chemical Plant PCC Rokita S.A. – comprehensive erection of 110/6kV substations and 6kV

substations

• TAURON Distribution Utility – delivery of 30 bays single busbar system switchgear 17,5kV for the

erection of 220kV/110kV/15kV substation

• PGE Distribution Utility – delivery of 60 bays single busbar system switchgear 17,5kV for the

modernization of 110/15kV substation

SELECTED EXAMPLES OF REFERENCE LIST

SELECTED EXAMPLES OF REFERENCE LIST

• Polish Railways – 800 pcs. bays of MV Switchgear

• Coal mine KWK Ziemowit – 60 bays of MV Switchgear

Coal mine KWK Ziemowit

• Power plant Żydowo – the first switchgear in Poland in withdrawable version

for 63kA

Power Plant Żydowo

• Heat Power Plant Tameh – switchgear for high nominal current 2500A and

short-circuit currents 50kA / 1s

Heat Power Plant Tameh

Heat Power Plant EDF Gdynia

• Heat Power Plant EDF in Gdynia – comprehensive modernization of the distribution

and the supply boxes for motors 6kV

• Chemical Plant in Puławy – 25 bays of double busbar system switchgear at the

Ammonia Division

Chemical Plant Puławy

TAURON Distribution Utility TAURON Distribution Utility – delivery of 30 bays single busbar system switchgear 17,5kV for the erection of 220kV/110kV/15kV substation
