Pressure Vessel Design (PVD) for HPgTPC Prashant Kumar, Vikas Teotia, Sanjay Malhotra Bhabha Atomic Research Centre, India Outline Vessel Geometry and Material of Construction Thickness calculation as per ASME Code for PV Shell portion

slide-1
SLIDE 1

Pressure Vessel Design (PVD) for HPgTPC

Prashant Kumar, Vikas Teotia, Sanjay Malhotra Bhabha Atomic Research Centre, India

slide-2
SLIDE 2

Outline

  • Vessel Geometry and Material of Construction
  • Thickness calculation as per ASME Code for PV Shell portion
  • Selection of Vessel head and its thickness calculation as per ASME Code
  • Simulations with Hemispherical pressure vessel head
  • Summary and Future work
slide-3
SLIDE 3

Vessel Geometry and Material of Construction

Mechanical Properties: AL 5083 S. N Descri ption Design ation Tensile Strength (MPa) Yield Strength (MPa) 0.2% Proof 1 5083- O B209M 270-345 115-200 2 5083- H32 B209M 305-385 215 min 3 5083- H116 B928M 305 min 215 min 4 5083- H321 B928M 305-385 215 min

  • S. N

Description Value (mm) 1 Vessel inner diameter 5725 mm 2 Length of Shell portion 5192 mm 3 Design Pressure 10 bar

slide-4
SLIDE 4

Thickness calculation for Shell portion: ASME BPV Code Sec. VIII D.1

Assumptions:  Weld efficiency factor (E) = 1.00  Design temperature = 28°C  F.O.S = 3, thus S (maximum allowable stress) = 215 / 3 = 71.66 MPa

Physics Requirements ?? Thickness (barrel section) of < = 0.5 radiation lengths

slide-5
SLIDE 5

Selection of Vessel head and its thickness calculation

slide-6
SLIDE 6

Selection of Vessel head and its thickness calculation

slide-7
SLIDE 7

Thickness calculation for Shell portion: Conti…

ID: Ø 5725 mm 40.28 mm 5192 mm Therefore, OD = 5725 + 2 * 40.28 = 5805.36 mm 40.28 mm 5192 mm ID: Ø 5725 mm Maximum Von Mises Stress = 95.379 Mpa Yield value = 195 Mpa

slide-8
SLIDE 8

Analysis of Hemispherical shaped PV head

OD : 5.805 m ID : 5.725 m Length of Shell : 5.192 m Thickness of shell : 40 mm Thickness of PV head : 20 mm

slide-9
SLIDE 9

Analysis of Hemispherical shaped PV head (no ribs)

Support width : 200 mm Support thickness : 100 mm

Support (only for simulation purpose)

slide-10
SLIDE 10

Analysis of Hemispherical shaped PV head (Von Mises Stress)

slide-11
SLIDE 11

Analysis of Hemispherical shaped PV head (Maximum Displacement)

slide-12
SLIDE 12

Analysis of Hemispherical shaped PV head (ribbed Shell)

Rib thickness : 50 mm Rib width : 100 mm Number of ribs : 3

slide-13
SLIDE 13

Analysis of Hemispherical shaped PV head (Maximum Displacement)

slide-14
SLIDE 14

Analysis of Hemispherical shaped PV head (Maximum Displacement)

slide-15
SLIDE 15

Summary and future work

  • Preliminary calculation and simulations are carried out for pressure vessel of TPC
  • At 40 mm shell thickness; Von mises stress and displacement is evaluated by

simulations

  • With out ribs, the maximum Von mises stress on vessel is about 100 MPa.
  • With three ribs, Von mises stress on vessel reduces to about 85 Mpa
  • Above level of Von Mises stress are lower than the Yield strength of the

designated Aluminum, i.e. 215 MPa
