PRESENTATION PACK Le Domaine - Erf 1052 DESCRIPTION & INDEX Sanware Schedule Open plan living area with high ceilings and exposed trusses Double garage with storage space 4 x Bathroom 4 x Bedroom scenery. Estate, Situated

slide-1
SLIDE 1

PRESENTATION PACK

Le Domaine - Erf 1052

slide-2
SLIDE 2

DESCRIPTION & INDEX

3D AXO View East & North Elevations West & South Elevations 3D Views - 1 3D Views - 2 3D Views - 3 3D Views - 4 Window Schedule Door Schedule Gates, Vents & Garage Door Schedule Appliance Schedule Sanware Schedule BIMx

Contemporary Cape Vernacular style House in Val De Vie Lifestyle Estate, Situated within the Cape Winelands with Beautiful Mountain scenery. · 4 x Bedroom · 4 x Bathroom · Double garage with storage space · Open plan living area with high ceilings and exposed trusses · Living area with Enclosed Braai Room overlooking Pool Area

slide-3
SLIDE 3

ILLUSTRATION Site Plan

PG | 3

Rooftrusses to be anchored as per part K of SANS 10400 in all aspects - G.H.I straps or wire shall be built into brickwork at depths prescribed by roof truss supplier. WATERPROOFING CONCRETE ROOF : Reinforced concrete roof slab according to
  • eng. spec/design with min 45mm screed
with 1:80 fall to 100mm diameter full-bore
  • utlets. Allow for reinforced fibre bitumen
waterproofing membrane such as derbigum sp4 application by specialist in accordance with manufacturer spec. and SABS 021. Lay 75mm of 20-40mm washed chip stone (brown) on 500 micron DPC over
  • waterproofing. Install wire mesh in front of
all outlets & full bores to keep ravel clear. Ensure gravel are clean and level on completion. No Obstruction on Sidewalk

ROAD

summer sunset

N

E W S

winter sunset winter sunrise summer sunrise N
  • r
t h W e s t W i n d s S
  • u
t h E a s t W i n d s Rainwater Goods 125x85mm OGEE profile seamless aluminium gutters and 75x50mm downpipes to be colour co-ordinated to match the colour of the gutter specification.Colour to client's specifications. ROOFSLAB : Stone Chip 45º Concealed fix steel sheeting Kliplok or Saflok in 0.47 Colorbond Ultra Matt finish, colour to be Granite Matt,installed to 50x76 timber purlins at 1.2m centres for 45 degree roof pitch. 45º 45º 45º 45º 45º 45º 45º 45º 45º 45º 1º Slope ROOFSLAB : Stone Chip DP DP DP DP D P D P DP D P

Boundary 22 500mm Boundary 30 000mm

ERF 1052 ERF 1051 ERF 1053

Boundary 22 500mm Boundary 30 000mm

3500mm Building Line 5000mm Building Line 2500mm Building Line 3500mm Building Line 3500mm Building Line 2500mm Building Line 3500mm Building Line 2500mm Building Line 1º Slope Winter Sunpath Summer Sunpath Summer Sunpath Winter Sunpath

Public Open Space Public Open Space

Double Garage: 40.63 m2 Entrance Patio: 3.76 m2 Ground Floor Living: 255.47 m2

TOTAL AREA: 299.86 m2

Boma: 10.00 m2 Timber deck: 34.08 m2

Drying Yard: 20.56 m2 Pergola Area: 11.63 m2 Plot: 675 m2 Plot Perimeter: 105.000 m Total Coverage: 44.42 % Bulk: 44.42 % 2000mm Boundary Walls: 7.290 m 2000mm Screen Walls: 3.311 m 1200mm Boundary Walls: 15.710 m 1200mm Screen Walls: 1.614 m 1500mm Boundary Walls: 8.850 m 900mm Boundary Wall with 300mm wrought iron above: 21.686 m 300mm Boundary Wall with 900mm wrought iron above: 13.645 m

AREA SCHEDULE

slide-4
SLIDE 4

ILLUSTRATION Ground Floor

PG | 4

Central Aircon Unit 240 400 240 5 175 240 4 605 650 240 5 270 240 240 5 270 240 240 1 020 95 3 160 95 900 240 240 1 000 600 190 3 480 240 360 1 300 190 240 5 070 240 1 015 1 530 240 1 015 240 1 911 240 1 110 1 435 468 2 700 468 95 1 345 95 1 000 95 3 200 95 3 200 95 1 000 190 2 400 190 1 610 600 95 3 205 240 900 450 1 050 650 240 1 020 190 1 130 190 2 740 240 240 960 1 500 940 95 325 600 325 190 200 600 200 95 515 2 100 585 95 550 2 100 550 95 200 600 200 190 648 1 200 648 95 760 400 1 475 600 1 375 600 300 240 240 560 4 880 560 240 2 100 170 240 240 1 002 500 1 003 240 2 035 1 200 2 035 240 661 341 500 341 662 400 240 516 120 240 2 701 600 2 435 600 675 1 190 600 4 450 1 138 1 500 1 300 540 240 1 040 7 275 4 865 680 1 020 175 600 175 2 090 300 400 300 300 400 300 1 626 1 802 400 346 240 300 240 100 1 072 600 1 073 150 240 3 400 95 1 250 190 1 000 95 3 200 95 3 200 95 1 000 190 2 495 95 5 510 240 22 390 5 482 240 6 000 240 2 270 480 2 505 240 5 270 240 6 480 5 255 5 750 17 485 +150 +200 ±0 ±0 ±0 ±0 +200 +200 +200 +200 Desk No Obstruction on Sidewalk

ROAD

HWB Shower HWB HWB HWB Shower Shower Geberit Toilet Geberit Toilet Geberit Toilet Niche Niche Niche Niche Shower Geberit Toilet Niche Niche HWB HWB Pool Pump DW WM TD F F Prep Bowl Eye Level Oven / Microwave G Casted Concrete Pavers Prep Bowl Line Of Bulkhead Above Line Of Bulkhead Above Lounge Tiles Kitchen Tiles Scullery/Laundry Tiles Double Garage Grano Bedroom 2 Carpet Bedroom 3 Carpet Dining Room Tiles Braai Room Tiles Entrance Patio Tiles Passage Tiles Entrance Tiles Dresser Carpet Guest WC Tiles En-suite 3 Tiles En-suite 4 Tiles Bedroom 4 Carpet Main En-suite Tiles Passage Tiles BOMA Main Bedroom Carpet En-suite 2 Tiles summer sunset

N

E W S

winter sunset winter sunrise summer sunrise 240 4 200 900 900 240 1 600 565 240 3 055 240 4 710 600 250 240 240 6 000 240 2 165 240 3 055 240 5 560 240 6 480 2 165 3 535 5 800 17 980 240 5 270 240 240 1 000 95 4 175 240 240 6 000 190 1 650 190 2 560 6 910 240 800 500 700 200 800 200 700 500 240 6 000 240 5 175 240 2 270 240 2 745 240 1 000 95 4 175 240 805 3 056 240 1 120 240 400 240 2 200 240 1 119 240 3 400 95 1 250 190 1 000 95 3 200 95 3 200 95 1 000 190 2 495 95 2 210 95 3 205 240 190 1 000 600 190 3 480 240 240 300 240 1 185 2 800 1 190 240 240 95 2 175 240 2 745 240 1 195 600 1 685 1 828 600 1 051 520 95 240 300 240 5 175 240 540 5 655 5 255 5 750 17 200 240 1 235 2 800 1 235 240 240 5 510 N
  • r
t h W e s t W i n d s S
  • u
t h E a s t W i n d s BIC BIC Painting Niche BIC 4000x2200mm POOL BY SPECIALIST

Boundary 22 500mm Boundary 30 000mm

Driveway Grey Concrete Cobbles Drying Yard Grey Concrete Cobbles

ERF 1052 ERF 1051 ERF 1053

Seat BIC BIC Shelving BIC BIC S h e l v i n g BIC Pergola Over Pergola Over Pergola Over

Boundary 22 500mm Boundary 30 000mm

3500mm Building Line 5000mm Building Line 2500mm Building Line 3500mm Building Line 3500mm Building Line 2500mm Building Line 3500mm Building Line 2400mm High walls 2400mm High walls Timber Deck 2500mm Building Line

Public Open Space Public Open Space

Winter Sunpath Summer Sunpath Summer Sunpath Winter Sunpath

Double Garage: 40.63 m2 Entrance Patio: 3.76 m2 Ground Floor Living: 255.47 m2

TOTAL AREA: 299.86 m2

Boma: 10.00 m2 Timber deck: 34.08 m2

Drying Yard: 20.56 m2 Pergola Area: 11.63 m2 Plot: 675 m2 Plot Perimeter: 105.000 m Total Coverage: 44.42 % Bulk: 44.42 % 2000mm Boundary Walls: 7.290 m 2000mm Screen Walls: 3.311 m 1200mm Boundary Walls: 15.710 m 1200mm Screen Walls: 1.614 m 1500mm Boundary Walls: 8.850 m 900mm Boundary Wall with 300mm wrought iron above: 21.686 m 300mm Boundary Wall with 900mm wrought iron above: 13.645 m

AREA SCHEDULE

slide-5
SLIDE 5

ILLUSTRATION Site Location

PG | 5

ERF 1052

s u m m e r s u n s e t

N

E W S

w i n t e r s u n s e t w i n t e r s u n r i s e s u m m e r s u n r i s e

North West Winds South East Winds

Winter Sunpath Summer Sunpath Summer Sunpath Winter Sunpath
slide-6
SLIDE 6

ILLUSTRATION 3D Floor Plan

PG | 6

Boundary Line Boundary Line Boundary Line

Main Bedroom

Carpet

Bedroom 4

Carpet

Bedroom 3

Carpet

Bedroom 2

Carpet En-suite 4

Tiles

En-suite 3

Tiles

En-suite 2

Tiles

Main En-suite

Tiles

Dressing Room

Carpet

Guest Toilet

Tiles

Passage

Tiles

Passage

Tiles

Braai Room

Tiles

Lounge

Tiles

Kitchen

Tiles

Double Garage

Grano Scullery/ Laundry

Tiles

Dinning Room

Tiles

Entrance

Tiles Drying Yard

Cobbles

Timber Deck

Boma Pool

slide-7
SLIDE 7

ILLUSTRATION 3D AXO View

PG | 7

Boundary Line Boundary Line Boundary Line

slide-8
SLIDE 8

ILLUSTRATION East & North Elevations

PG | 8

200 3 000 2 220 1 303 6 723 2 400 4 800 4 600 2 000 150 3 050 1 200

203x133 Steel I-Beams to

  • Eng. details by specialist.

Stone cladding as per Val de Vie's Gate House.

NGL: ±0 Ground FFL: +200

Lintel: +2 600

Wallplate Height: +3 200

Lintel: +4 800

Chimney:+5 420 Main Roof Apex: +6 723 NGL: ±0 Ground FFL: +200

Lintel: +2 600

Wallplate Height: +3 200

Lintel: +4 600

Chimney:+5 420 Main Roof Apex: +6 723 Garage FFL:+150 500x2100mm aluminium shutters by specialist

House Colour paint to be Arniston White as approved by Val de Vie. Door and Window colour to be, (White - Epoxy coated & Painted ) Concealed fix steel sheeting Kliplok or Saflok in 0.47 Colorbond Ultra Matt finish, colour to be Granite Matt,installed to 50x76 timber purlins at 1.2m centres for 45 degree roof pitch.

Roof pitch at 45º with 300mm overhang.

200 3 000 2 220 1 303 6 723 2 400 1 200

150 2 450 203

203x133 Steel I-Beams to

  • Eng. details by specialist.

NGL: ±0 Ground FFL: +200

Lintel: +2 600

Wallplate Height: +3 200 Chimney:+5 420 Main Roof Apex: +6 723 NGL: ±0 Ground FFL: +200

Lintel: +2 600

Wallplate Height: +3 200 Chimney:+5 420 Main Roof Apex: +6 723 All to Eng spec&detail

House Colour paint to be Ariniston White as approved by Val de Vie. Door and Window colour to be, (White - Epoxy coated & Painted ) Concealed fix steel sheeting Kliplok or Saflok in 0.47 Colorbond Ultra Matt finish, colour to be Granite Matt,installed to 50x76 timber purlins at 1.2m centres for 45 degree roof pitch.

Roof pitch at 45º with 300mm overhang.

East Elevation 1:100 North Elevation 1:100

slide-9
SLIDE 9

ILLUSTRATION West & South Elevations

PG | 9

200 3 000 2 220 1 303 6 723 2 400

Garage FFL:+150

2 000 2 000 2 730 120 150 2 472 203

150 2 472 203 620 203 677 1 500 620 203 677 1 500

Chimney Cowl. Chimney colour to match roof covering.

203x133 Steel I-Beams to

  • Eng. details by specialist.

203x133 Steel I-Beams to

  • Eng. details by specialist.

NGL: ±0 Ground FFL: +200

Lintel: +2 600

Wallplate Height: +3 200 Chimney:+5 420 Main Roof Apex: +6 723 NGL: ±0 Ground FFL: +200

Lintel: +2 600

Wallplate Height: +3 200 Chimney:+5 420 Main Roof Apex: +6 723 All to Eng spec&detail All to Eng spec&detail

House Colour paint to be Arniston White as approved by Val de Vie. Door and Window colour to be, (White - Epoxy coated & Painted ) Concealed fix steel sheeting Kliplok or Saflok in 0.47 Colorbond Ultra Matt finish, colour to be Granite Matt,installed to 50x76 timber purlins at 1.2m centres for 45 degree roof pitch.

Roof pitch at 45º with 300mm overhang. Roof pitch at 45º with 300mm overhang.

200 3 000 2 220 1 303 6 723 2 400 4 600 1 300 200 2 400 480 120 1 200 900 300 2 000 Chimney Cowl. Chimney Cowl. Chimney colour to match roof covering. Plaster Moulding

203x133 Steel I-Beams to

  • Eng. details by specialist.

203x133 Steel I-Beams to

  • Eng. details by specialist.

NGL: ±0 Ground FFL: +200

Lintel: +2 600

Wallplate Height: +3 200

Lintel: +4 600

Chimney:+5 420 Main Roof Apex: +6 723 NGL: ±0 Ground FFL: +200

Lintel: +2 600

Wallplate Height: +3 200

Lintel: +4 600

Chimney:+5 420 Main Roof Apex: +6 723 All to Eng spec&detail All to Eng spec&detail

House Colour paint to be Arniston White as approved by Val de Vie. Door and Window colour to be, (White - Epoxy coated & Painted ) Concealed fix steel sheeting Kliplok or Saflok in 0.47 Colorbond Ultra Matt finish, colour to be Granite Matt,installed to 50x76 timber purlins at 1.2m centres for 45 degree roof pitch.

Roof pitch at 45º with 300mm overhang.

South Elevation 1:100 West Elevation 1:100

slide-10
SLIDE 10

ILLUSTRATION 3D Views - 1

PG | 10

slide-11
SLIDE 11

ILLUSTRATION 3D Views - 2

PG | 11

slide-12
SLIDE 12

ILLUSTRATION 3D Views - 3

PG | 12

slide-13
SLIDE 13

ILLUSTRATION 3D Views - 4

PG | 13

slide-14
SLIDE 14

ILLUSTRATION Window Schedule

PG | 14

Elevation

500 2 400 700 2 400 1 200 2 100 600 2 400 500 2 100 600 2 400 600 2 100 400 2 100 1 000 1 800 600 1 200

Refrence ID:-

D-01/R D-03/L W-01 W-02; W-03; W-05 W-04 W-06; D-07/L; D-08/L W-07; W-08 W-09 W-10 W-11; W-12; W-13

Size:

500×2 400 700×2 400 1 200×2 100 600×2 400 500×2 100 600×2 400 600×2 100 400×2 100 1 000×1 800 600×1 200

Location: -

Entrance Scullery / Laundry Bedroom 4 Double Garage; Bedroom 4; Passage Guest WC Lounge; Bedroom 2; Bedroom 3 Main Bedroom Dresser Main En-suite En-suite 2; En-suite 3

Position:

Exterior Exterior Exterior Exterior Exterior Exterior Exterior Exterior Exterior Exterior

Description:

German Designed European Double glazing Teva Upvc - Onyx Fixed Pane Window, German Designed European Double glazing Teva Upvc - Onyx Window, with 1x Top Hung Opener German Designed European Double glazing Teva Upvc - Onyx Window, with 1x Top Hung Opener German Designed European Double glazing Teva Upvc - Onyx Window, with 1x Top Hung Opener German Designed European Double glazing Teva Upvc - Onyx Window, with 1x Top Hung Opener German Designed European Double glazing Teva Upvc - Onyx Window, with 1x Top Hung Opener German Designed European Double glazing Teva Upvc - Onyx Window, with 1x Top Hung Opener German Designed European Double glazing Teva Upvc - Onyx Fixed Pane Window, German Designed European Double glazing Teva Upvc - Onyx Window, With Double Side Hung Openers. German Designed European Double glazing Teva Upvc - Onyx Side Hung Window,

Frame:

Upvc Upvc Upvc Upvc Upvc Upvc Upvc Upvc Upvc Upvc

Ironmongery:

Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail

Glazing: -

Double Glazing Double Glazing Double Glazing Double Glazing Double Glazing Double Glazing Double Glazing Double Glazing Double Glazing Double Glazing

Glass type:

PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass PG SmartGlass X2™-Standard 6.38mm Laminated Safety Glass

Finish:

Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite

Quantity: -

1 1 1 3 1 3 2 1 1 3

Window Schedule

slide-15
SLIDE 15

ILLUSTRATION Door Schedule

PG | 15

Elevation

1 400 2 400 900 2 400 2 700 2 400 1 500 2 400 900 2 400 800 2 400 925 2 400 5 255 2 400

Refrence ID:-

D-01 D-02; D-03 D-04; D-06 D-05; D-07; D-08; D-09 D-10; D-11; D-13; D-14; D-15; D-17 D-12; D-16 D-18 D-19

Size:

1 400×2 400 900×2 400 2 700×2 400 1 500×2 400 900×2 400 800×2 400 925×2 400 5 255×2 400

Location: -

Entrance Double Garage; Scullery / Laundry Lounge; Main Bedroom Main Bedroom; Bedroom 2; Bedroom 3; Bedroom 4 Main Bedroom; Bedroom 2; Bedroom 3; Bedroom 4; En-suite 4; Guest WC En-suite 2; En-suite 3 Double Garage Braai Room

Position:

Exterior Exterior Exterior Exterior Interior Interior Interior Exterior

Description:-

German Designed European Double glazing Teva Upvc - Onyx Pivot Door German Designed European Double glazing Teva Upvc - Onyx Door. Sill to Have Weep Holes. German Designed European Double glazing Teva Upvc - Onyx Sliding Door. Sill to Have Weep Holes. German Designed European Double glazing Teva Upvc - Onyx Sliding Door. Sill to Have Weep Holes. INTERNAL TIMBER HINGED DOOR. INTERNAL TIMBER SLIDING DOOR. Garage door to be 1/2h Fire rated with self closing mechanism and comply with SANS 10400. Door to have 10mm Threshold. FRAMELESS ALUMINIUM STACKING DOOR.SILL TO HAVE WEEP HOLES.

Frame:

Upvc Upvc Upvc Upvc Timber Timber Timber Aluminium

Ironmongery:

Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail

Glazing: -

Double Glazing Double Glazing Double Glazing Double Glazing None None None Single Glazing

Glass type:

PG SmartGlass X2™-Elite 6.38mm Laminated Safety Glass PG SmartGlass X2™-Elite 6.38mm Laminated Safety Glass PG SmartGlass X2™-Elite 6.38mm Laminated Safety Glass PG SmartGlass X2™-Elite 6.38mm Laminated Safety Glass N/A N/A N/A 6mm thick Laminated Safety Glass

Finish

Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite Upvc: TEVA Onyx. Bi-colour White & Anthracite TIMBER DOOR COLOUR TO BE WHITE AS PER CLIENT'S SPEC AND DETAIL. TIMBER DOOR COLOUR TO BE WHITE AS PER CLIENT'S SPEC AND DETAIL. TIMBER DOOR COLOUR TO BE WHITE AS PER CLIENT'S SPEC AND DETAIL. ALUMINIUM POWDER COATING TO BE MINIMUM 0.6 MICRON

  • THICK. COLOUR : White

Quantity: -

1 2 2 4 6 2 1 1

Door Schedule

slide-16
SLIDE 16

ILLUSTRATION Gates, Vents & Garage Door Schedule

PG | 16

Elevation

200 1 200

Refrence ID:-

V-01; V-02; V-03; V-04

Size:

200×1 200

Location: -

Gable Ends

Position:

Exterior

Description:

Fixed Louvre Ventilation Windows

Frame:

Concrete

Ironmongery:

Top Quality Hardware. To Later Detail

Glazing: -

None

Glass Type :

N/A

Finish:

MANUFACTURURE SPEC - COLOUR : CHARCOAL

Quantity: -

4

Vent Window Schedule Elevation

1 000 2 000 4 880 2 100 1 000 1 200

Refrence ID:-

G-01; G-02 GD-01 GD-03

Size:

1 000×2 000 4 880×2 100 1 000×1 200

Location: -

Site Double Garage Site

Position:

Exterior Exterior Exterior

Frame:

Steel Aluzink Steel

Ironmongery:

Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail Top Quality Hardware. To Later Detail

Glazing: -

None None None

Glass Type :

N/A N/A N/A

Finish:

WROUGHT IRON GATES TO BE BLACK AS PER CLIENTS SPEC. CHARCOAL EPOXY ALUZINK GARAGE DOOR. WROUGHT IRON GATES TO BE BLACK AS PER CLIENTS SPEC.

Quantity: -

2 1 1

Gate & Garage Door Schedule

slide-17
SLIDE 17

ILLUSTRATION Appliance Schedule

PG | 17

Braai & Fireplaces

Braai Room Lounge

Image Description

Built-in Braai Free standing Fireplace

Model Quantity

1 1

2

Appliance Schedule

Kitchen

Image Description

Smeg - 54cm Integrated Full Freezer Smeg - 54cm Integrated Full Fridge Smeg - 60CM CLASSIC ELCTRIC OVEN Smeg - 60CM x 45CM CLASSIC MICROWAVE OVEN Smeg - 70cm Ultra-low Profile Stainless Steel Linea 5 Burner Gas Hob Smeg - 90cm Stainless Steel Wall Mount Extractor Hood

Model

S7220FNDP S7323LFEP SFP6390XE SF4390MCX PGF75-4 KSA900HX

Quantity

1 1 1 1 1 1

6

slide-18
SLIDE 18

ILLUSTRATION Sanware Schedule

PG | 18

Basin Bath

Location

Main En-suite; En-suite 2; En- suite 3; En-suite 4; Guest WC Main En-suite; En-suite 2; En- suite 3; En-suite 4; Guest WC Main En-suite; En-suite 2; En- suite 3; En-suite 4; Guest WC Main En-suite; En-suite 2; En- suite 3; En-suite 4; Guest WC Main En-suite Main En-suite Main En-suite Main En-suite Main En-suite Main En-suite

Image Description

GIO WASTE BRASS CLICKER SLOTTED 32mm LOGIS BASIN MIXER 70 NO PUW Luna Large Deep Basin 595x330 Semi Gloss PVC TRAP 32mm Concealed Body Small - Bath FREE STANDING BATH Gio Nikki Spout Gio Waste Clicker unslotted 40mm LOGIS Single Leaver Shower Mixer PVC Trap 38mm

Quantity

6 6 6 6

24

1 1 1 1 1 1

6

Sanware Schedule

Dish Washer Prep Bowl Shower

Location

Scullery / Laundry Kitchen; Braai Room Kitchen; Braai Room Kitchen; Braai Room Main En-suite; En-suite 2; En- suite 3; En-suite 4 Main En-suite; En-suite 2; En- suite 3; En-suite 4 Main En-suite; En-suite 2; En- suite 3; En-suite 4 Main En-suite; En-suite 2; En- suite 3; En-suite 4 Main En-suite; En-suite 2; En- suite 3; En-suite 4

Image Description

GIO BENKISER TRICORN ANGLE VALVE 15X10 FRANKE CUB UNDERMOUNT PREPBOWL 455x390x140 GIO BENKISER TRICORN ANGLE VALVE 15X10 HANSGROHE DECOR E² SINK MIXER CONCEALED BODY SMALL LOGIS SHOWER MIXER FINISH SET RAINDANCE 150 OVERHEAD SHOWER ROSE SHOWER ARM LONG 400mm ISCA TRAP SHOWER TOURBILLON SQUARE WIRQUIN COMPLETE

Quantity

1

1

2 4 2

8

4 4 4 4 4

20

Sanware Schedule

Sink Washing Machine WC

Location

Scullery / Laundry Scullery / Laundry Scullery / Laundry Scullery / Laundry Main En-suite; En-suite 2; En- suite 3; En-suite 4; Guest WC Main En-suite; En-suite 2; En- suite 3; En-suite 4; Guest WC Main En-suite; En-suite 2; En- suite 3; En-suite 4; Guest WC

Image Description

GIO BENKISER TRICORN ANGLE VALVE 15X10 HANSGROHE DECOR E² SINK MIXER Sink - Blanco Supra 340 GIO BENKISER TRICORN ANGLE VALVE 15X10 BETTA DIPLOMAT W/H PAN GEBERIT ALPHA 15 MATT FLUSH PLATE GEBERIT KOMBIFIX WALL HUNG ALPHA RANGE

Quantity

2 1 1

4

2

2

5 5 5

15

80

Sanware Schedule

slide-19
SLIDE 19

3D WALKTHROUGH.

Njoy the BIMx 3D experience. Follow instructions. Scan above QR CODE with Android or Apple Device. Njoy the BIMx 3D experience. Follow instructions. Copy Following BIMx URL.

https://bimx.graphisoft.com/model/d7b4f3c0-c6c7-4a57-b9c2- 0c7cd500fa94

BIMx Mobile BIMx Desktop

PG | 19

slide-20
SLIDE 20

THANK YOU

Scan above QR CODE with Android or Apple Device, to View Youtube Video or copy following link.

https://youtu.be/18E-hX1C2i8

Scan above QR CODE with Android or Apple Device, to View 360° Panorama or copy following link.

http://view.mylumion.com/?p=ncsz3gzihcfbhcej

PG | 20

Warren Labuschagne (082) 787 0775 iconplans@gmail.com 29 Textile Street Bella Vista Paarl Western Cape 7680 South Africa
