Preparing for Sea Level Rise Climate Change Adaptation Strategy Update Council Presentation // November 2nd, 2016 Outline Background and Context Coastal Flood Risk Assessment Overview Coastal Flood Risk Assessment Phase 1 and 2 Phase 2 High

slide-1
SLIDE 1

Preparing for Sea Level Rise

Climate Change Adaptation Strategy Update

Council Presentation // November 2nd, 2016

slide-2
SLIDE 2

Coastal Flood Risk Assessment Overview Coastal Flood Risk Assessment Phase 1 and 2

Outline

Background and Context Phase 2 High Level Options by Area Next Steps & Recommendations

2

slide-3
SLIDE 3

3

Despite local efforts, global greenhouse gas emissions keep growing.

slide-4
SLIDE 4

Extreme weather events cost Canadian insurers $3.2B in 2013 Calgary Flood 2013 “Once climate change becomes a defining issue for financial stability, it may already be too late.”

Mark Carney, Governor of the Bank of England (2015)

4

slide-5
SLIDE 5

UK Floods 2014 By 2100 the direct economic losses to the region due to floods could exceed $30B and adaptation costs will approach $10B

Lower Mainland Flood Management Strategy and B.C.

5

slide-6
SLIDE 6
slide-7
SLIDE 7

↘ Impacts from sea level rise include increased coastal flooding, erosion and storm damage ↘ Actions: Complete a Coastal Flood Risk Assessment and develop a City-wide Sea Level Rise Response Plan

7

slide-8
SLIDE 8

Guiding Principles for Sea Level Rise Adaptation

↘ Use the best available science and practice adaptive management ↘ Seek adaptable, green and robust solutions that can be phased over time ↘ Seek “no regret” actions with co-benefits ↘ Pursue funding strategies based on value and equity ↘ Take a risk-based approach ↘ Be resilient by providing redundancy

8

slide-9
SLIDE 9

Sea Level Rise - Causes

↘ 2015 warmest year on record (since 1880) ↘ 90% of new, excess heat is stored in the oceans – Thermal Expansion ↘ Melting of land ice (glaciers) – Antarctica and Greenland

Credit: JohnEnglander.net 9

slide-10
SLIDE 10

Sea Level Rise

↘ Rising sea level is “the single most profound geological change in recorded human history” John Englander, 2016 ↘ Not a possible or a probable but a question of WHEN ↘ Amounts are unpredictable ↘ Unstoppable and irreversible for centuries ↘ Good news: slow so we can plan and adapt but must think BIG and FLEXIBLE enough

BC sea level rise curve (2011)

slide-11
SLIDE 11

Context: King Tide flooding Jericho Pier

11

slide-12
SLIDE 12

Context: King Tide flooding Jericho

12

slide-13
SLIDE 13

Context: King Tide flooding Seawall

Credit: Vancouver Sun Credit: Vancitybuzz 13

slide-14
SLIDE 14

Context: King Tide flooding Seawall

14

slide-15
SLIDE 15

Fraser Basin Council Lower Mainland Flood Management Strategy Provincial Amendment to Flood Hazard Management Guidelines Federal National Disaster Mitigation Program & National Flood Mapping Standards Project CONTEXT

15

slide-16
SLIDE 16

Coastal Flood Risk Assessment (CFRA) Overview

Flood hazard today and in 2100 What is at risk and potential losses

PHASE

1

Develop response options for 11 areas and compare options Flood Construction Level from 3.5m to 4.6m

PHASE

2

2012 2015 2014 VBBL

16

slide-17
SLIDE 17

Jericho Locarno Stanley Park Coal Harbour False Creek Kits Fraser Industrial Southlands

CFRA – Phase 1 Current and Future flood hazard

17

slide-18
SLIDE 18

With increasing sea level rise our risk grows significantly Extreme Storm Event, High Tide 2020

18

slide-19
SLIDE 19

Future Flood Hazard Mapping Extreme Storm Event, High Tide 2100

19

slide-20
SLIDE 20

Identifying Elements at Risk

People Infrastructure

Economy/Assets

Environment

20

slide-21
SLIDE 21

Phase 1 Outcome: FCL from 3.5m to 4.6m

21

slide-22
SLIDE 22

CFRA – Phase 2 Seek Flexible, Adaptive and Robust Solutions

22

slide-23
SLIDE 23

Phase 2 Process – Preliminary Evaluation

Generate Approaches Define Evaluation Criteria Compare Approaches against Criteria Explore Trade-offs between Approaches

23

slide-24
SLIDE 24

Phase 2 – Stakeholders Involved

Parks OEM Planning Engineering Social Planning Facilities BC Hydro BC Government City of Surrey CMHC (Granville Island) Metro Vancouver Port Metro Vancouver TransLink University of British Columbia Urban Development Institute

CITY STAFF EXTERNAL

24

slide-25
SLIDE 25

CFRA Phase 2: Preliminary Evaluation of Approaches

PEOPLE ENVIRONMENT ECONOMY IMPLEMENTATION

RESPONSE APPROACHES CONSIDERATIONS

25

slide-26
SLIDE 26

CFRA Phase 2: It is important to consider WHEN an option should be implemented

26

slide-27
SLIDE 27

Precedent: Dry-line New York City

27

slide-28
SLIDE 28

Precedent: Rotterdam

28

slide-29
SLIDE 29

Precedent: NYC design competition

29

slide-30
SLIDE 30

Precedent: Rotterdam

30

slide-31
SLIDE 31

5 Focus Areas - Preliminary Response Approaches

  • 1. False Creek
  • 2. Fraser River Industrial
  • 3. Southlands
  • 4. Jericho/Locarno
  • 5. Kitsilano

31

slide-32
SLIDE 32

Adapt

Multiple Tools

Protect

With Sea Barrier

Protect

With Raised Seawall

EXAMPLE: False Creek Three Approaches

32

slide-33
SLIDE 33

closed 3-4 days/yr; increasing

  • ver time

~10m high 360m wide EXAMPLE: False Creek PROTECT with sea barrier

slide-34
SLIDE 34

EXAMPLE: False Creek PROTECT with sea barrier

Ramspol, the Netherlands: Storm Surge Barrier Example

Source: boxbarrier.com 34

slide-35
SLIDE 35

8.6 km long seawall to be raised to FCL of 4.6m On average 2.3m of height increase is required

EXAMPLE: False Creek PROTECT with raised seawall

35

slide-36
SLIDE 36

Fill or floodproof Additions make up for lost space Convert 1st floor residential to commercial Deployable flood shields and temporary stairs

EXAMPLE: False Creek ADAPT with planning tools

36

slide-37
SLIDE 37

37

EXAMPLE: False Creek ADAPT with planning tools

37

slide-38
SLIDE 38

Adapt

Multiple Tools

Protect

With Shoreline Dike

Protect

With Inland Dike

EXAMPLE: Fraser River Industrial Three Approaches

38

slide-39
SLIDE 39

Fraser River Industrial: Protect with shoreline Dike

39

slide-40
SLIDE 40

Fraser River Industrial: Protect with Inland Dike

40

slide-41
SLIDE 41

Fraser River Industrial: Adapt with Multiple Planning Tools

Image from: Brooke Peninsula Project Assael Architecture Limited, UK 41

slide-42
SLIDE 42

Adapt

Multiple Tools

Protect

With Dike

Managed Retreat

EXAMPLE: Southlands Three Approaches

42

slide-43
SLIDE 43

Southlands: Protect with Dike

43

slide-44
SLIDE 44

Southlands: Managed Retreat

Musqueam First Nation

44

slide-45
SLIDE 45

Southlands: Adapt with Multiple Tools

Image from: McFarland Marceau Architects Ltd. North Vancouver Outdoor School, Squamish, BC Temporary Flood Barriers (England) 45

slide-46
SLIDE 46

Adapt

Multiple Tools

Protect

With Park Dike

Protect

With Road Dike

Managed Retreat

EXAMPLE: Jericho Four Approaches

46

slide-47
SLIDE 47

Jericho: Protect with Park Dike

47

slide-48
SLIDE 48

Jericho: Protect with Road Dike

48

slide-49
SLIDE 49

Jericho: Managed Retreat

49

slide-50
SLIDE 50

Jericho: Adapt

50

slide-51
SLIDE 51

Jericho Example: Fine Grained Shoreline Planning

51

slide-52
SLIDE 52

Jericho: Example of a Resilient Park

52

slide-53
SLIDE 53

Adapt

Multiple Tools

Protect

With Park Dike

Protect

With Road Dike

EXAMPLE: Kitsilano Three Approaches

53

slide-54
SLIDE 54

Kitsilano - Approaches

Protect with Road Dike Protect with Park Dike Adapt with Planning Tools

54

slide-55
SLIDE 55

2015 High Level Cost Estimate

55

Barrier Raised seawall Adapt False Creek $500M-$800M $9.5M/yr. mtn. $300M-$400M $4M/yr. mtn. $338M $0.5M/yr. mtn. Shoreline Dike Inland Dike Adapt Fraser Industrial $160M $107K/yr. mtn. $55M $107K/yr. mtn. $405M $0.5M/yr. mtn. Shoreline Dike Retreat Adapt Southlands $90M $66K/yr. mtn. $990M $150M $0.5M/yr. mtn. Park Dike Road Dike Retreat Jericho $10M - $24M $20K/yr. mtn. $10M - $20M $15K/yr. mtn. $620M Park Dike Road Dike Adapt Kitsilano $4M - $9M $7K/yr. mtn. $6M - $15M $10K/yr. mtn. $13M $0.5M/yr. mtn.

slide-56
SLIDE 56
  • 1. Coal Harbour
  • 2. Waterfront Road Area
  • 3. New Brighton Park
  • 4. Stanley Park
  • 5. Point Grey Road
  • 6. Port Lands

Secondary Focus Areas – Preliminary Response Approaches

56

slide-57
SLIDE 57

Coal Harbour

Adapt

Multiple Tools

Protect

With Raised Seawall

Protect

With Structured Wall

57

slide-58
SLIDE 58

Waterfront Road Area

Concepts from Sean Smith, Port MetroVancouver

58

slide-59
SLIDE 59

New Brighton Park

Protect

With Dike

Managed Retreat

59

slide-60
SLIDE 60

Stanley Park

Protect

With Raised Seawall

Adapt

Multiple Tools

60

slide-61
SLIDE 61

Point Grey Road

Protect

With Armouring

61

slide-62
SLIDE 62

↘ Protect land regardless of use ↘ Prioritize maintaining natural shoreline for as long as possible and incorporating green infrastructure solutions where possible. ↘ Enhance amenities where possible ↘ Phase solutions to obtain best value and provide for course correction as more information is available

Phase 2 Conclusions

62

slide-63
SLIDE 63

Next Steps

Immediate Short Term Medium Term Long Term

2015-2020 2020-2030 2100 2030-2050

63

slide-64
SLIDE 64

Immediate Next Steps

Begin Short Term projects: Jericho, Fraser River, Waterfront Road Work with other levels of Government:

  • Lower Mainland Flood Management Strategy, NDMP

funding, First Nations Collaboration

Broad: Education - Build Awareness and Understanding Project-Specific: Deeper dive into area-specific options

Engagement

64

slide-65
SLIDE 65

Engagement ↘ Broad community-wide Education: ↘ Causes and impacts of sea level rise ↘ What to expect in Vancouver ↘ Options for response ↘ Project-specific engagement (e.g. Southlands) ↘ Tell us what you think of the preliminary approaches ↘ Other approaches to consider ↘ Concurrently explore technical feasibility of options

65

slide-66
SLIDE 66

↘ Immediate Next Steps

↘ Develop flood warning systems and flood response plans ↘ Develop an Adaptive Management Strategy and start monitoring ↘ Limit Critical Infrastructure in floodplains ↘ Initiate a Financing Strategy ↘ Preserve Future Options through redevelopment, acquiring space, park planning

66

slide-67
SLIDE 67

Financial Considerations

↘ Funding Sources:

↘ Federal Government Funding ↘ Provincial Government Funding ↘ Regional / local contributions

↘ Potential Sources of Regional / Local Contributions

↘ Regional / Local Development Cost Charges ↘ Local Improvement Tax ↘ New area specific or city-wide fees or levies

↘ Next Steps

↘ Start planning now for long term funding mechanisms including advocacy for reliable and predictable Sr. Gov’t funding ↘ Area-specific projects will include funding strategy

67

slide-68
SLIDE 68

Recommendation

↘ Begin broad community education campaign ↘ Implement immediate next steps ↘ Initiate short term projects by 2017

↘ Concurrent engagement and engineering refinement

↘ In parallel develop a Sea Level Rise Response Strategy to outline medium and long term actions

↘ Project Initiation Dates and Decision Thresholds ↘ Project Team Requirements, Roles and Responsibilities ↘ Project Funding

68

slide-69
SLIDE 69

QUESTIONS?

69
