PRAIRIE CREEK MINE ALL SEASON ROAD

TECHNICAL SESSION June, 2019

PRAIRIE CREEK MINE ALL SEASON ROAD

TECHNICAL SESSION June, 2019

1

• Phase 1 Winter Road
• Winter 2019/2020 construction, partial ROW
• Geotechnical Investigation Program
• Limited road operation (2-4 weeks)
• Phase 2 All Season Road
• Fall 2020 construction start, eastern and western ends

2

Camp 65 (Ram) Camp 23 (Drum) Camp 42 (Cat)

Stn 35 Stn 30 Stn 45 Stn 50 Stn 10 Stn 40 Stn 70 Stn 60 Stn 55 Stn 65 Stn 25 Stn 20 Stn 15 Stn 75 Stn 0 Stn 5

Nahanni National Park Reserve

• f Canada

P

• lj

i e La f f e r t y C r eek Tetcel a River S u n d

• g

S un d

• g Cr

e e k

6845000 6840000 6835000 6830000 6825000 6820000 6815000 6810000 6845000 6840000 6835000 6830000 6825000 6820000 6815000 6810000 450000 445000 440000 435000 430000 425000 420000 415000 410000 405000 400000 450000 445000 440000 435000 430000 425000 420000 415000 410000 405000 400000

2 4 6 1 Kilometers

I

Path: C:\17GP0018 Canadian Zinc - Feasibility Asessment\2400-GIS\CanadianZinc\CanadianZinc.aprx

NatGeo_World_Map: Content may

I

Prairie Creek Mine

Access Road Overview Page 1 of 3

Date: 1/28/2019 Projection: NAD 1983 UTM Zone 10N Scale: 1:150,000 Author: Last Modified By: ainglis Checked By: Revision #:

Camp Laydown Mine Site Designed Stations (20181213) Major Stream Crossings (201812) Designed Centerline (20181213) National Park

Camp 87 (Tetcela) Camp 124 (Grainger) Camp 102 (Wolverine Backup)

Stn 85 Stn 70 Stn 130 Stn 80 Stn 125 Stn 140 Stn 115 Stn 120 Stn 90 Stn 95 Stn 75 Stn 105 Stn 135 Stn 110

Nahanni National Park Reserve

• f Canada

F i s h t r a p C re e k W i n d y C r e e k G r a i n g e r R i v e r O v e rf l

• w

Creek G r a inger R i v e r Blu e f i s h C r e e k F i s h t r a p C r e e k T etcel a R i v e r

6820000 6815000 6810000 6805000 6800000 6795000 6790000 6785000 6820000 6815000 6810000 6805000 6800000 6795000 6790000 6785000 495000 490000 485000 480000 475000 470000 465000 460000 455000 450000 445000 495000 490000 485000 480000 475000 470000 465000 460000 455000 450000 445000

2 4 6 1 Kilometers

I

Path: C:\17GP0018 Canadian Zinc - Feasibility Asessment\2400-GIS\CanadianZinc\CanadianZinc.aprx

NatGeo_World_Map: Content may

I

Prairie Creek Mine

Access Road Overview Page 2 of 3

Date: 1/28/2019 Projection: NAD 1983 UTM Zone 10N Scale: 1:150,000 Author: Last Modified By: ainglis Checked By: Revision #:

Camp Laydown Mine Site Designed Stations (20181213) Major Stream Crossings (201812) Designed Centerline (20181213) National Park

"

& & &

Proposed Access Gate F t . S i m p s

• n
• Ft. Nelson

Camp 159 (Liard) Camp 151 (Backup) Camp 178 (Hwy 7)

Stn 165 Stn 155 Stn 150 Stn 140 Stn 160 Stn 170 Stn 145 Nahanni Butte

Nahanni National Park Reserve

• f Canada

B e a v e r W ater C r e e k M a t tso n C r e e k B a y C r e e k O v e rfl

• w

Cr e ek G r a i n g e r Ri v e r B a y C ree k B l u e f i s h C r e e k

6785000 6780000 6775000 6770000 6765000 6760000 6755000 6750000 6785000 6780000 6775000 6770000 6765000 6760000 6755000 6750000 515000 510000 505000 500000 495000 490000 485000 480000 475000 470000 465000 515000 510000 505000 500000 495000 490000 485000 480000 475000 470000 465000

2 4 6 1 Kilometers

I

Path: C:\17GP0018 Canadian Zinc - Feasibility Asessment\2400-GIS\CanadianZinc\CanadianZinc.aprx

NatGeo_World_Map: Content may

I

Prairie Creek Mine

Access Road Overview Page 3 of 3

Date: 1/28/2019 Projection: NAD 1983 UTM Zone 10N Scale: 1:150,000 Author: Last Modified By: ainglis Checked By: Revision #:

Camp Laydown Mine Site Designed Stations (20181213) Major Stream Crossings (201812) Designed Centerline (20181213) National Park

• Phase 1
• Define required management plans
• Agree on Panel members and confirm scope of review
• Define remaining data requirements
• Phase 2
• Confirm road/crossing design Panel review process
• Confirm borrow pit plan approval process
• Define remaining data requirements

4

Prairie Creek Funeral Creek Sundog Creek Polje Creek KP 6.2 KP 20.3 KP 23.3 KP 25.4 KP 28.5 KP39.2 Funeral Creek Sundog Creek Prairie Creek KP = Kilometre Point (KP 0 is the Mine) Pass

Cat Camp

5

KP 53.2 Polje Creek RAM PLATEAU Mosquito Lake Lake 70

6

Fishtrap Creek KP 119.0 KP 121 KP 111.5 KP 95 Grainger River & Gap Un-named creek Wolverine Pass Tetcela River KP 87.0 KP 89.5

7

Bluefish Lake Lake 141 Lake 139

8

Nahanni Butte Liard Hwy Nahanni Access Road Winter Crossing Old Logging Road Summer Crossing KP 156.1 KP 169.5 KP 179.5

9

• KP 23.2
• KP 42*
• KP 65
• KP 87*
• KP 102 Wolverine Pass
• KP 120 Grainger Gap*
• KP 148 (alternate to KP 155)
• KP 155 Liard River

* Retain for Road Maintenance

10

11
